Inner Range CONCEPT IQ User Manual page 27

Version 2.02 December-2002
4.2) To Control an Auxiliary Output:
a) Select Auxiliary Control Mode:
b) Toggle the Auxiliary On or Off:
e.g. To Turn Auxiliary 3 On.
c) Logout of Aux Control Mode:
The Control Module will then reply with a Status message:
- A series of Beeps of the same tone to indicate Auxiliary On.
- A series of Beeps of 2 different tones to indicate Auxiliary Off.
- A series of Beeps of 8 different tones to indicate the operation could not be performed.
4.3) To Isolate a Zone Input:
a) Select Zone Isolate Mode:
b) Toggle the Zone Isolated/De-Isolated:
e.g. To change the Status of Zone 6.
c) Logout of Zone Isolate Mode:
The Control Module will then reply with a Status message:
- A series of Beeps of the same tone to indicate Zone Isolated.
- A series of Beeps of 2 different tones to indicate Zone De-isolated.
- A series of Beeps of 8 different tones to indicate the operation could not be performed.
4.4) To Control User Auxiliary A or B:
a) At Step 3, simply Key in the User Auxiliary A PIN Code, or the User Auxiliary B PIN Code.
This will Toggle the state of the Auxiliary.
The Control Module will then reply with a Status message:
- A series of Beeps of the same tone to indicate Auxiliary On.
- A series of Beeps of 2 different tones to indicate Auxiliary Off.
- A series of Beeps of 8 different tones to indicate the operation could not be performed.
NOTE: There is a 2 minute delay required between dial-in attempts. This enhances protection against
unauthorized access into the system. Once you have hung-up the Telephone following a Telephone remote
control operation, please wait at least 2 minutes before attempting to connect again.
Press <9>, then 24 (Auxiliary Control & Test Mode)
Press <Auxiliary Number>, <#>
Press: 3, <#>.
Press <*>. (If this is not done before hanging up, you must wait
at least 30 seconds before calling the system again)
Press <9>, then 21 (Zone Isolate Mode)
Press <Zone Number>, <#>
Press: 6, <#>.
Press <*>. (If this is not done before hanging up, you must wait
at least 30 seconds before calling the system again)
27
