Inner Range CONCEPT IQ User Manual page 25

Version 2.02 December-2002
3. Enter the current Time.
The <A1> Lamp will flash to indicate the system is ready for the Time entry.
Enter the Time data:
The time is stored in the following order:
e.g. TIME:
1) 07:24 AM
2) 05:15 PM
4. Enter the current Date.
The <A2> Lamp will flash to indicate the system is ready for the Date entry.
Enter the Date data:
The date is stored in the following order:
i.e. Day (01 - 31); Month (01 - 12); Year (00 - 99).
e.g. DATE:
Monday, June 5, 2002
5. Enter the current Day of the Week.
The <A3> Lamp will flash to indicate the system is ready for the Day-of-the-week entry.
Enter the Day data:
Sunday 1
Monday 2
Tuesday 3
Wednesday 4
6. View the Current Time and Date or Exit Time and Date programming.
When the Day-of-the-week has been keyed in and the <ENTER> key is pressed, the system will automati-
cally return to the Time entry.
To View or Change the Time and Date return to Step 2.
To Exit Time and Date programming; Press
(4 digits), then
hh : mm
DATA STRING:
0, 7, 2, 4, <ENTER>
1, 7, 1, 5, <ENTER>
DD : MM : YY ; d
DATA STRING:
0, 5, 0, 6, 0, 2, <ENTER>
(1 digit), then
Thursday
Friday
Saturday
i.e. Hour (00 - 23); Minute (00 - 59).
(6 digits), then
5
6
7
.
25
