VIESMANN
Service instructions
for contractors
Vitosol-F
For applicability, see the last page
VITOSOL-F
Please keep safe.
5692 887 GB
10/2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VITOSOL-F and is the answer not in the manual?

Questions and answers

Related Manuals for Viessmann VITOSOL-F

Summary of Contents for Viessmann VITOSOL-F

  • Page 1 VIESMANN Service instructions for contractors Vitosol-F For applicability, see the last page VITOSOL-F Please keep safe. 5692 887 GB 10/2012...
  • Page 2 Observe the following when working on tem. this system: Replace faulty components only ■ National installation requirements with original Viessmann spare ■ Legal instructions regarding the pre- parts. vention of accidents ■ Legal instructions regarding environ- mental protection ■...
  • Page 3 Installing non-author- ised components and making non-approved modifications or conversions can compromise safety and may invalidate our warranty. For replacements, use only orig- inal spare parts supplied or approved by Viessmann.

  • Page 4: Table Of Contents

    Index Index Commissioning, inspection, maintenance Steps - commissioning, inspection and maintenance.......... Further details regarding the individual steps............Scope of inspection................... 13 Parts lists Ordering parts...................... 14 Specification Vitosol 100-F......................16 Vitosol 200-F......................16 Vitosol 200-F, type SVE..................16 Vitosol 300-F......................16 Certificates Declaration of conformity..................

  • Page 5: Commissioning, Inspection, Maintenance

    Commissioning, inspection, maintenance Steps - commissioning, inspection and maintenance For further information regarding the individual steps, see the page indicated Commissioning steps Inspection steps Maintenance steps Page • 1. Checking pressure conditions and changing the pre- charge pressure of the expansion vessel if necessary •...

  • Page 6: Further Details Regarding The Individual Steps

    Commissioning, inspection, maintenance Further details regarding the individual steps Checking pressure conditions and changing the pre-charge pressure of the expansion vessel if necessary This process may not be carried out 4. Check pre-charge pressure and while the solar thermal system is in oper- adjust if required.
  • Page 7 Commissioning, inspection, maintenance Further details regarding the individual steps (cont.) System pressure of the solar thermal system Supplement, static head 0.1 bar/m ....bar/m System pressure (pressure gauge) ....Pressure reserve for ventilation + 0.1 Charge pressure ....Pre-charge pressure of expansion vessel 5 Note ....

  • Page 8: Checking Electrical Connections

    Commissioning, inspection, maintenance Further details regarding the individual steps (cont.) Checking electrical connections Check the tightness of the electrical plug-in connectors and cable grom- mets; check cables for damage. Flushing, checking for leaks and charging the solar thermal sys- Please note ■...
  • Page 9 Commissioning, inspection, maintenance Further details regarding the individual steps (cont.) A Shut-off valve D Container for heat transfer medium B Drain valve E Pressure gauge C Fill valve F Fill pump 1. Open shut-off tap or valves. 4. Connect hoses from the flushing and filling facility.

  • Page 10: Determining And Adjusting The Flow Rate If Required

    Commissioning, inspection, maintenance Further details regarding the individual steps (cont.) 8. Open shut-off valve A. 5. Observe the fluid level in con- tainer D and top up with heat trans- fer medium if necessary to prevent 9. Vent the circulation pumps. Select any air entering the solar circuit.

  • Page 11: Commissioning The System

    Commissioning, inspection, maintenance Further details regarding the individual steps (cont.) High flow operation, 40 l/(h·m Low flow operation, 15 l/(h·m Number of Flow rate in l/min Number of Flow rate in l/min collectors collectors 10.5 12.5 15.5 18.5 10.5 21.5 11.5 23.5 Vitosol 200-F, type 5DIA...
  • Page 12 Commissioning, inspection, maintenance Further details regarding the individual steps (cont.) In some cases the manufacturer of the heat transfer medium can carry out a laboratory test of the medium, subject to arrangement. ■ Manufacturer: TYFOROP CHEMIE GmbH Anton-Rée-Weg 7 D - 20537 Hamburg Email: info@tyfo.de Internet: www.tyfo.de 1.

  • Page 13: Scope Of Inspection

    Scope of inspection Scope of inspection The solar thermal system should be inspected once a year to ensure opera- tional reliability. In addition to this, a visual inspection of all essential components (e.g. collectors and pipework) is recommended every 3 to 5 years.

  • Page 14: Parts Lists

    Parts lists Ordering parts The following information is required: 0009 Mounting plate ■ Serial no. (see type plate) 0012 O-rings ■ Position of the part (from this parts list) 0014 Profile clamp 0016 Support sleeve Standard parts are available from your 0020 Special valve grease local supplier.
  • Page 15 Parts lists Ordering parts (cont.) 0001 0002 0003 0004 0005 0006 0007 0008 0009 0012 0014 0016 0020 0021 0022 0023 0025 0026 0027...

  • Page 16: Specification Vitosol 100-F

    Specification Vitosol 100-F Type SV1A/SH1A SV1B/SH1B Absorber area 2.32 2.32 Aperture area 2.33 2.33 Thermal capacity c kJ/(m ·K) Max. stagnation temperature °C Permiss. operating pressure Content, heat transfer medium litre 1.48/233 1.67/2.33 Vitosol 200-F Type SV2A/ SV2B/ 5DIA SH2A SH2B Absorber area 2.32...
  • Page 17 Specification Vitosol 300-F (cont.) Type SV3A/SH3A SV3B/SH3B Thermal capacity c 5.0/4.6 kJ/(m ·K) Max. stagnation temperature °C Permiss. operating pressure Content, heat transfer medium litre 1.83/2.48 1.83/2.48...

  • Page 18: Certificates

    Certificates Declaration of conformity We, Viessmann Werke GmbH&Co KG, D-35107 Allendorf, confirm as sole respon- sible body that the product Vitosol-F complies with the following standards: DIN 1055-1: 2002-06 DIN 1055-4: 2005-03 DIN 1055-5: 2005-07 EN 12975 to Solar KEYMARK...
  • Page 20 7417762 7417763 7417764 7417765 7417766 7417767 7417768 7439235 7514374 Viessmann Werke GmbH&Co KG Viessmann Limited D-35107 Allendorf Hortonwood 30, Telford Telephone: +49 6452 70-0 Shropshire, TF1 7YP, GB Fax: +49 6452 70-2780 Telephone: +44 1952 675000 www.viessmann.com Fax: +44 1952 675040...
