Installation and commissioning

CauTIOn!
Machine at risk!
CauTIOn!
Machine at risk!
CauTIOn!
Machine at risk!
DanGEr!
Electrocution!
BASCV - EN
Version 02 12.2009
Installation and commissioning
Observe the safety notes and the "Safety" chapter in this Operating instructions!

Setup conditions

Location

► Do not set up the coffee machine on hot surfaces or close to ovens.
► Set up the coffee machine on a stable and level surface.
The surface on which the coffee machine is placed must not warp under the machine's weight!
► Do not set up the coffee machine on surfaces on which a water jet might be used.
Danger from incorrect operation! Operation of the coffee machine must be monitored by trained
personnel!

ambient conditions

The following ambient conditions must be met:
• Ambient temperature: 10°C – 40°C (50°F – 104°F)
• Maximum relative humidity: 80% rH
► Never expose the coffee machine to external weather conditions such as rain, snow, frost, etc.
Danger from weather conditions! The device is not designed for outdoor use.Only use indoors!
► Protect the device from frost! If the coffee machine was exposed to negative temperatures, contact
service partner before using.

Electrical connection

The device must be electrically connected according to the applicable regulations (VDE 0100) as well as
national stipulations. Type of power cable at least H 07 RN-F. The voltage specified on the serial plate must
match the supply voltage at the installation location.
Model Power rating
Standard
England,
Ireland
220 - 240 V
australia, new
Zealand, China
Denmark
uSa 120 V
Japan 200 V
Danger of electric shock! The following instructions absolutely must be complied with:
• The phase must have fuse protection of 10 A / 15 A (amperes)! It must be possible to disconnect the de-
vice from the mains power supply at all poles.
• Never lift or pull the device by the power cord!
• Never pull the plug out of the socket by its cord.
• Never touch the power cord or plug with wet hands!
• Never insert a wet plug into a power socket!
• Never operate a device with a damaged power cord. Have a defective power cord or plug replaced im-
mediately by a qualified service technician.
Generally, use of an extension cord is discouraged! If an extension cord is used anyway, the following rules
must be complied with:
• Minimum cable cross section: 1.5 mm2
Fuse (instal-
lation site)
10-16 A
13 A
2000 -
AC 50/60 Hz
2200 W
15 A
10 A
AC 50/60 Hz 1700 W 15 A
2 AC 50/60 Hz 2000 W 15 A
www.schaerer.com
Connection cable con-
ductor cross-section
1.5 mm
2
1.5 mm
2
1 mm
2
1 mm
2
AWG14
2.5 mm
2
