Product description
BASCV - EN
Version 02 12.2009

Technical details

Power rating *
Mains connection *
Operating temperature
Permitted operating temperature (T max)
Minimum operating temperature (T min.):
Overpressure
Working overpressure
Permissible operating overpressure
Test overpressure
Water tank
Bean hoppers
Choc container/topping container
External dimensions
Width
Height with bean hopper
Depth
Empty weight
Continuous noise level (Lpa) ***
We reserve the right to make technical changes.
* Special equipment, see Serial plate; specified values refer to standard equipment.
** Depending on machine configuration and model.
*** The A-weighted noise level Lpa (slow) and Lpa (impulse) at the operators' workplace is below 70 dB(A) in every operating mode.

Serial plate

The serial plate is located behind the drip tray on the left side.
► In the event of a fault or warranty claim, specify the information on the serial plate.

EC declaration of conformity

Manufacturer's address

Manufacturer
Schaerer Ltd.
P.O. Box
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 6404
info@schaerer.com
www.schaerer.com
1700-2200 W
220-240 V AC 50/60 Hz
Steam boiler ** Hot water boiler **
192°C 192°C
10°C 10°C
Steam boiler ** Hot water boiler **
2.5 bar 2.5 bar
12 bar 12 bar
24 bar 24 bar
4.5 l
Approx. 1100 g each
Approx. 4.7 l or 2x approx. 2.3 l
329 mm
814 mm
473 mm
Approx. 30-40 kg
< 70 dB (A)
Documentation responsible
Schaerer AG
Hans-Ulrich Hostettler
P.O. Box
Allmendweg 8
CH-4528 Zuchwil
www.schaerer.com
