TEST NOTES
Running Individual Tests
7.01
In order to run an individual test the login level must be Technician or Developer.
Change the PENNRDR.INI or PittRdr.ini file's Login field to one of these if nec-
essary or enter the password T or D at the login window, which appears when the
test program is first loaded. To run an individual test simply double click on the
test (in the test status window) that you want to run. You may also highlight the
test and click on the Run Test button of the main test screen.
To run an individual test multiple times in succession, highlight the test that you
want to run and click on the Loop Test button of the main test screen.
7.02
Help Screens
To select help on any of the tests in the test status window simply place the cursor
over the test and press the mouse's right button (right click). There is also a main
help screen available by selecting the Options button of the main test screen fol-
lowed by the Main Help button.
Options Menu
7.03
Fixture Control
This allows you to manually control and monitor many of the functions of the test
station. Use this if you are a technician who is familiar with the functions of the
Penn Reader or Pitt Reader.
Test Results
This displays all of the readings taken in the last test that was run. It also shows
the Min and Max test limits for each reading.
Edit/Display System Files
This allows you to choose one of the important system files of the test program
(such as the INI files) and open them for editting with the Notepad program.
WARNING!! DO NOT CHANGE THE RFCONFIG.TXT FILE!
PCB Drawing
If you have the appropriate Mentor Graphics CAD file on your system then this
option allows you to display the assembly drawing of one of the Penn Reader
boards. Note that the DSP and 915MHz boards were designed outside of the
Mentor Graphics system so they cannot be shown here.
Main Help
Displays the main help screen.
869 RFID Reader Service Instruction Manual
