Please refer to the table below for the LAN interface mapping to check the MAC address
through either BIOS or Web interface.
BMC LAN Interface Mapping Table
I/O Panel
LAN1 Port (NCSI)

IPMI Port

BIOS Menu
Server Mgmt
tab
IPMI Web Page
Coniguration
> Network
Settings
For more instructions on how to set up remote control environment and use the IPMI man-
agement platform, please refer to the IPMI Coniguration User Guide or go to the Support
website at: http://www.asrockrack.com/support/ipmi.asp
70
BIOS Menu
Lan Channel 1
Lan Channel 2
IPMI Web Page
eth0
eth1
(Example image only)
(Example image only)
