ASROCK EP2C622D16FM User Manual

ASROCK EP2C622D16FM User Manual

Server/workstation motherboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EP2C622D16FM
EP2C621D16FM
User Manual
Version 1.0
Published January 2018
Copyright©2018 ASRock Rack INC. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EP2C622D16FM and is the answer not in the manual?

Questions and answers

Related Manuals for ASROCK EP2C622D16FM

Summary of Contents for ASROCK EP2C622D16FM

  • Page 1 EP2C622D16FM EP2C621D16FM User Manual Version 1.0 Published January 2018 Copyright©2018 ASRock Rack INC. All rights reserved.
  • Page 2 In no event shall ASRock Rack, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock Rack has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 3 Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you may contact your dealer for further information. ASRock Rack Incorporation 6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,...

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Unique Features Motherboard Layout Onboard LED Indicators I/O Panel Block Diagram Chapter 2 Installation Screw Holes Pre-installation Precautions Installing the CPU and Heatsink Installation of Memory Modules Expansion Slots (Mezzanine Card Slot) Jumper Setup Onboard Headers and Connectors LED/Switches Driver Installation Guide...
  • Page 5 Main Screen Advanced Screen 3.3.1 CPU Configuration 3.3.2 DRAM Configuration 3.3.3 Chipset Configuration 3.3.4 Storage Configuration 3.3.5 ACPI Configuration 3.3.6 USB Configuration 3.3.7 Super IO Configuration 3.3.8 Serial Port Console Redirection 3.3.9 H/W Monitor 3.3.10 Runtime Error Logging 3.3.11 Intel SPS Configuration 3.3.12 Intel®...
  • Page 6 Exit Screen Chapter 4 Software Support Install Operating System Support CD Information 4.2.1 Running The Support CD 4.2.2 Drivers Menu 4.2.3 Utilities Menu 4.2.4 Contact Information Chapter 5 Troubleshooting Troubleshooting Procedures Technical Support Procedures Returning Merchandise for Service...

  • Page 7: Chapter 1 Introduction

    In case any modifications of this manual occur, the updated version will be available on ASRock Rack website without further notice. You may find the latest memory and CPU support lists on ASRock Rack website as well. ASRock Rack’s Website: www.ASRockRack.com If you require technical support related to this motherboard, please visit our website for specific information about the model you are using.

  • Page 8: Specifications

    1.2 Specifications EP2C622D16FM / EP2C621D16FM MB Physical Status Form Factor SSI CEB Dimension 12'' x 10.5'' (30.5 cm x 26.7 cm) Processor System Intel® Xeon® Scalable Processors Socket Dual Socket LGA-3647 EP2C622D16FM: Chipset Intel® C622 EP2C621D16FM: Intel® C621 System Memory...
  • Page 9 EP2C622D16FM / EP2C621D16FM Graphics Controller ASPEED AST2500 VRAM DDR4L 256Mb Output Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz Rear Panel I/O USB 3.0 Port LAN Port LAN Ports with LED (ACT/LINK LED and SPEED LED), dedicate for IPMI...
  • Page 10 Support OS Microsoft® Windows® (Server OS) - Server 2012 R2 (64 bit) - Server 2016 (64 bit) Linux® - RedHat Enterprise Linux Server 6.8 (64 bit) / 7.4 (64 bit) - CentOS 6.8 (64 bit) / 7. 4 (64 bit) - SUSE Enterprise Linux Server 11 SP4 (64 bit) /12 SP3 (64 bit) - FreeBSD 11 (64 bit) - Ubuntu 16.04/15.10 (64 bit)

  • Page 11: Unique Features

    POST or the <F2> key to enter into the BIOS setup menu to access ASRock Rack Instant Flash. Just launch this tool and save the new BIOS file to your USB flash drive, floppy disk or hard drive, then you can update your BIOS only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.

  • Page 12: Motherboard Layout

    1.4 Motherboard Layout EP2C622D16FM / EP2C621D16FM 26.7 cm (10.5 in) DDR4_C1 (64 bit, 288-pin module, Blue) MAIN_PWR UID1 DDR4_B1 (64 bit, 288-pin module, Blue) FRONT_LED_LAN34 DDR4_A1 (64 bit, 288-pin module, Blue) PWR_PMB DDR4_A2 (64 bit, 288-pin module, White) BPB_SMB MEZZ_B1...
  • Page 13 EP2C622D16FM / EP2C621D16FM Description PWR PMBus Header (PWR_PMB1) BPB SMBus Header (BPB_SMB) ATX Power Connector (MAIN_PWR) Front Lan LED Connector (FRONT_LED_LAN34) 3 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, DDR4_C1) 1 x 288-pin DDR4 DIMM Slot (DDR4_A2) CPU1 ATX 12V Power Connector (CPU1_PWR)
  • Page 14 Description Auxiliary Panel Header (AUX_PANEL1) Non Maskable Interrupt Button (NMI_BTN1) NCSI Mode Jumper (NCSI_SEL1) VGA Header (VGA) ME Recovery Jumper (ME_RECOVERY1) TPM Header (TPM1) Mezzanine Card Slot (MEZZ_A2) M.2 Socket (M2_2) (Type 2242 / 2280) M.2 Socket (M2_1) (Type 2242 / 2280) SATA3 Connector (SSATA_0) Clear CMOS Pad (CLRMOS1) MINI-SAS HD Connector (SATA_0_7)

  • Page 15: Onboard Led Indicators

    EP2C622D16FM / EP2C621D16FM 1.5 Onboard LED Indicators DDR4_C1 (64 bit, 288-pin module, Blue) DDR4_B1 (64 bit, 288-pin module, Blue) DDR4_A1 (64 bit, 288-pin module, Blue) DDR4_A2 (64 bit, 288-pin module, White) MEZZ_B1 MEZZ_C1 CPU1 RoHS MEZZ_A1 DDR4_D2 (64 bit, 288-pin module, White)
  • Page 16 Item Status Description Power Supply Power Good Green Power supply ready CPU1_FAN1 Error LED Amber CPU1_FAN1 failed FRNT_FAN1 Error LED Amber FRNT_FAN1 failed FRNT_FAN2 Error LED Amber FRNT_FAN2 failed CPU2_FAN1 Error LED Amber CPU2_FAN1 failed FRNT_FAN3 Error LED Amber FRNT_FAN3 failed FRNT_FAN4 Error LED Amber FRNT_FAN4 failed...

  • Page 17: I/O Panel

    EP2C622D16FM / EP2C621D16FM 1.6 I/O Panel No. Description No. Description UID Switch (UID1) NMI Button (NMI1) LAN RJ-45 Port (IPMI_LAN) System Stats LED (SYS_LED1) USB 3.0 Ports (USB3_1_2) System Stats LED Indications System Event LED Status Description Running or normal operation...

  • Page 18: Block Diagram

    1.7 Block Diagram...

  • Page 19: Chapter 2 Installation

    EP2C622D16FM / EP2C621D16FM Chapter 2 Installation This is a SSI CEB form factor (12'' x 10.5'', 30.5 cm x 26.7 cm) motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it.

  • Page 20: Installing The Cpu And Heatsink

    2.3 Installing the CPU and Heatsink 1. Before you insert the CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 21 EP2C622D16FM / EP2C621D16FM 1. Before you installed the heatsink, you need to spray thermal interface material between the CPU and the heatsink to improve heat dissipation. 2. Illustration in this documentation are examples only. Heatsink or fan cooler type may differ.
  • Page 23 EP2C622D16FM / EP2C621D16FM Tighten the two Corner Plunger to 12 IN.LB. Two turns at a time. Tighten the two Middle Nuts to 12 IN.LB. Two turns at a time.

  • Page 24: Installation Of Memory Modules

    2.4 Installation of Memory Modules This motherboard provides sixteen 288-pin DDR4 (Double Data Rate 4) DIMM slots in two groups, and supports Six and Dual Channel Memory Technology. Capacity CPU1 CPU2 DDR4_A1, B1, C1, D1, E1, F1 (Blue) DDR4_G1, H1, I1, J1, K1, L1 (Blue) 256GB / 512GB DDR4_A2, D2 (White)
  • Page 25 EP2C622D16FM / EP2C621D16FM The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.
  • Page 26 Recommended Memory Configurations A single memory module should be installed in the BLUE socket which is nearest to the CPU. 1 CPU Configuration CPU1 1 DIMM 2 DIMMS 4 DIMMS 6 DIMMS 8 DIMMS 2 CPU Configuration CPU1 1 DIMM 2 DIMMS 4 DIMMS 8 DIMMS...

  • Page 27: Expansion Slots (Mezzanine Card Slot)

    EP2C622D16FM / EP2C621D16FM 2.5 Expansion Slots (Mezzanine Card Slot) There are five Mezzanine Card slots on this motherboard. Mezzanine Card slots: The mezzanine card slots are used for mezzanine cards. (This Connector follows Open Compute Mezzanine Card pin definition, which provides further 10G Ethernet sup- port capability.)

  • Page 28: Jumper Setup

    2.6 Jumper Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short” when a jumper cap is placed on these 2 pins.
  • Page 29 EP2C622D16FM / EP2C621D16FM Chassis ID0 Jumper (3-pin CHASSIS_ID1) (see p.6, No. 32) Chassis ID1 Jumper (3-pin CHASSIS_ID2) (see p.6, No. 31) Chassis ID2 Jumper (3-pin CHASSIS_ID3) (see p.6, No. 30) Board Level SKU (Default) 1U12XL-C622 RPSU Chassis ID0 Jumper (3-pin CHASSIS_ID1) (see p.6, No.

  • Page 30: Onboard Headers And Connectors

    2.7 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header Connect the power switch, PLED+ PLED-...
  • Page 31 EP2C622D16FM / EP2C621D16FM Auxiliary Panel Header This header supports multiple (18-pin AUX PANEL_1) functions on the front panel, (see p.6, No. 35) i nc lud i ng t he f ront pa nel SMB, internet status indicator and chassis intrusion pin.
  • Page 32 3-Pin CPU fan, (see p.6, No. 16) please connect it to Pin 1-3. *For more details, please refer to the Cooler QVL list on the ASRock Rack website. Front a Fan Connectors Please connect fan cables to...
  • Page 33 EP2C622D16FM / EP2C621D16FM ATX Power Connector This motherboard provides a (24-pin MAIN_PWR) 24-pin ATX power connector. (see p.6, No. 3) To use a 20-pin ATX power supply, please plug it along Pin 1 and Pin 13. ATX 12V Power Connectors...
  • Page 34 LAN3_LINK LAN LED Connector These 4-pin connectors LED_PWR (FRONT_LED_LAN34) are used for the front LED_PWR (see p.6, No. 4) LAN status indicator. LAN4_LINK RRXD1 Serial Port Header This COM header supports a DDTR#1 DDSR#1 (9-pin COM) serial port module. CCTS#1 (see p.6, No.
  • Page 35 EP2C622D16FM / EP2C621D16FM Virtual RAID On CPU This connector supports Intel® Header Virtual RAID on CPU and (4-pin RAID_1) +3VSB NVME/AHCI RAID on CPU (see p.6, No. 27) PCIE. VROC RAID KEY (SLIMLIN2) (see p.6, No. 24) VGA Header Please connect either end...

  • Page 36: Led/Switches

    2.8 LED/Switches Unit Identification When the UID button on the purpose LED/Switch front or rear panel is pressed, (UID1) the front/rear UID blue LED indicator will be truned on. Press the UID button again to turn off the indicator. NMI (Nonmaskable Press the NMI button to Interrupt) Button generate a nonmaskable...

  • Page 37: M.2_Ssd (Ngff) Module Installation Guide

    EP2C622D16FM / EP2C621D16FM 2.10 M.2_SSD (NGFF) Module Installation Guide The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Ultra M.2 Socket (M2_1 / M2_2) supports a M.2 SATA3 6.0 Gb/s module or a M.2 PCI Express module up to Gen3 x4(32Gb/s).
  • Page 38 Step 3 Move the standoff based on the module type and length. Skip Step 3 and 4 and go straight to Step 5 if you are going to use the NUT80 NUT42 default nut. Otherwise, release the standoff by hand. Step 4 Peel off the yellow protective film on the nut to be used.

  • Page 39: Chapter 3 Uefi Setup Utility

    EP2C622D16FM / EP2C621D16FM Chapter 3 UEFI Setup Utility 3.1 Introduction Th is section explains how to use the UEFI SETUP UTILITY to confi gure your system. Th e UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer.

  • Page 40: Navigation Keys

    3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Tab>...

  • Page 41: Main Screen

    EP2C622D16FM / EP2C621D16FM 3.2 Main Screen Once you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. The Main screen provides system overview information and allows you to set the system time and date.

  • Page 42: Advanced Screen

    3.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, DRAM Configuration, Chipset Configuration, Storage Configuration, ACPI Configura- tion, USB Configuration, Super IO Configuration, Serial Port Console Redirection, H/ W Monitor, Runtime Error Logging, Intel SPS Configuration, Intel(R) VMD Technology, Intel(R) Virtual RAID on CPU and Instant Flash.

  • Page 43: Cpu Configuration

    EP2C622D16FM / EP2C621D16FM 3.3.1 CPU Configuration Intel SpeedStep Technology Intel SpeedStep technology allows processors to switch between multiple frequencies and voltage points for better power saving and heat dissipation. CPU turbo ratio can be fixed when Intel SpeedStep Technology set Disabled and Intel Turbo Boost Technology set En- abled.
  • Page 44 Limit is exceeded. Short Duration Power Limit Configure Package Power Limit 2 in watts. When the limit is exceeded, the CPU ratio will be lowered immediately. A lower limit can protect the CPU and save power, while a higher limit may improve performance. Intel Hyper Threading Technology Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performance on threaded software is improved.
  • Page 45 EP2C622D16FM / EP2C621D16FM Package C State Support Enable CPU, PCIe, Memory, Graphics C State Support for power saving. CPU C6 State Support Enable C6 deep sleep state for lower power consumption. Enhanced Halt State(C1E) Enable Enhanced Halt State (C1E) for lower power consumption.

  • Page 46: Dram Configuration

    3.3.2 DRAM Configuration Enforce POR Enable to enforce POR restrictions for DDR4 frequency and voltage programming. DRAM Frequency If [Auto] is selected, the motherboard will detect the memory module(s) inserted and assign the appropriate frequency automatically. Numa Use this item to enable or disable Non Uniform Memory Access (NUMA). IMC Interleaving Select IMC Interleaving settings.
  • Page 47 EP2C622D16FM / EP2C621D16FM Memory Rank Sparing Enable or disable Memory Rank Sparing.

  • Page 48: Chipset Configuration

    3.3.3 Chipset Configuration MMCFG Base Use this item to select MMCFG Base. MMIO High Base Use this item to select MMIO High Base. MMIO High Size Use this item to select MMIO High Size. Above 4G Decoding Enable or disable 64bit capable Devices to be decoded in Above 4G Address Space (only if the system supports 64 bit PCI decoding).
  • Page 49 EP2C622D16FM / EP2C621D16FM MEZZ_C1 This allows you to enable or disable MEZZ Type-C. VT-d Intel Virtualization Technology for Directed I/O helps your virtual machine monitor bet- ter utilize hardware by improving application compatibility and reliability, and providing additional levels of manageability, security, isolation, and I/O performance.
  • Page 50 SLIMLIN2-2 ASPM Support This option enables or disables the ASPM support for all CPU downstream devices. SR-IOV Support If system has SR-IOV capable PCIe Devices, this option Enables or Disables Single Root IO Virtualization Support. Restore on AC/Power Loss Select the power state after a power failure. If [Power Off] is selected, the power will remain off when the power recovers.

  • Page 51: Storage Configuration

    EP2C622D16FM / EP2C621D16FM 3.3.4 Storage Configuration Hard Disk S.M.A.R.T. Use this item to enable or disable the S.M.A.R.T. (Self-Monitoring, Analysis, and Reporting Technology) feature. Configuration options: [Disabled] and [Enabled]. SATA Controller Use this item to enable or disable SATA Controllers.
  • Page 52 SSATA ALPM Use this item to enable or disable SALP.

  • Page 53: Acpi Configuration

    EP2C622D16FM / EP2C621D16FM 3.3.5 ACPI Configuration PCIE Devices Power On Use this item to enable or disable PCIE devices to turn on the system from the power-soft- off mode. Ring-In Power On Use this item to enable or disable Ring-In signals to turn on the system from the power- soft-off mode.

  • Page 54: Usb Configuration

    3.3.6 USB Configuration Legacy USB Support Use this option to enable or disable legacy support for USB devices. The default value is [Enabled].

  • Page 55: Super Io Configuration

    EP2C622D16FM / EP2C621D16FM 3.3.7 Super IO Configuration Serial Port 1 Configuration Use this item to set parameters of Serial Port 1 (COM1). Serial Port Use this item to enable or disable the serial port. Change Settings Use this item to select an optimal setting for Super IO device.

  • Page 56: Serial Port Console Redirection

    3.3.8 Serial Port Console Redirection COM1 Console Redirection Use this option to enable or disable Console Redirection. If this item is set to Enabled, you can select a COM Port to be used for Console Redirection. Console Redirection Settings Use this option to configure Console Redirection Settings, and specify how your computer and the host computer to which you are connected exchange information.
  • Page 57 EP2C622D16FM / EP2C621D16FM Bits Per Second Use this item to select the serial port transmission speed. The speed used in the host computer and the client computer must be the same. Long or noisy lines may require lower transmission speed. The options include [9600], [19200], [38400], [57600] and [115200].
  • Page 58 computer and the host computer to which you are connected exchange information. Legacy Serial Redirection Port Use this item to select a COM port to display redirection of Legacy OS and Legacy OPROM Messages. Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) Console Redirection Use this option to enable or disable Console Redirection.

  • Page 59: H/W Monitor

    EP2C622D16FM / EP2C621D16FM 3.3.9 H/W Monitor In this section, it allows you to monitor the status of the hardware on your system, includ- ing the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage.
  • Page 60 FRNT_FAN 4 This allows you to set the front fan 4’s speed. The default value is [Smart Fan]. Smart Fan Control This allows you to set the Smart fan’s level speed. Smart Fan Duty Control Smart Fan Duty x (x means 1 to 11 stage) This allows you to set duty cycle for each stage.

  • Page 61: Runtime Error Logging

    EP2C622D16FM / EP2C621D16FM 3.3.10 Runtime Error Logging WHEA Support Use this item to enable or disable Windows Hardware Error Architecture. System Error Use this item to enable or disable System Error feature. When it is set to [Enabled], you can configure Memory Error and PCIE Error log features.
  • Page 62 PCIE Uncorrected Error Enable Use this item to enable or disable PCIe Uncorrectable errors. PCIE Fatal Error Enable Use this item to enable or disable PCIe Ftal errors.

  • Page 63: Intel Sps Configuration

    EP2C622D16FM / EP2C621D16FM 3.3.11 Intel SPS Configuration ME Subsystem screen displays the Intel ME Subsystem Configuration information, such as Operational Firmware Version and Firmware State.

  • Page 64: Intel® Vmd Technology

    3.3.12 Intel® VMD technology ® Press <Enter> to bring up the Intel VMD for Volume Management Device Configuration menu. ® Intel VMD for Volume Management Device on Socket 1 ® Intel VMD for Volume Management Device Technology Use this item to enable or disable Intel(R) Volume Management Device Technology in this Stack.
  • Page 65 EP2C622D16FM / EP2C621D16FM VMD port 3D Use this item to enable or disable Intel(R) Volume Management Device Technology on specific root port. Hot Plug Capable Use this item to enable or disable Hot Plug for PCIe Root Ports 3A-3D.

  • Page 66: Intel® Virtual Raid On Cpu

    3.3.13 Intel® Virtual RAID on CPU Intel VROC Managed Volumes (Available after the RAID has been created.) Select to see more information about the RAID Volume. All Intel VMD Controllers Select to see more information about the Intel VMD Controllers.
  • Page 67 EP2C622D16FM / EP2C621D16FM Create RAID Volume This page allows you to create a RAID volume. Non-RAID Physical Disks (Available when no RAID is created.) Select to see more information about the disk. RAID Volumes (Available after the RAID has been created.) Select to see more information about the RAID Volume.
  • Page 68 Name Enter an unique volume name that has no special characters and is 16 charaters or less. RAID Level Select RAID Level. Enable RAID spanned over VMD Controllers Select [X] to enable RAID spanned over VMD Controllers. Select Disks Select [X] to select disks. Strip Size Select strip size.

  • Page 69: Instant Flash

    EP2C622D16FM / EP2C621D16FM 3.3.14 Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. This convenient UEFI update tool allows you to update system UEFI without entering operating systems ® first like MS-DOS or Windows . Just save the new UEFI file to your USB flash drive,...

  • Page 70: Security

    3.4 Security In this section, you may set or change the supervisor/user password for the system. For the user password, you may also clear it. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 71: Key Management

    EP2C622D16FM / EP2C621D16FM 3.4.1 Key Management In this section, expert users can modify Secure Boot Policy variables without full authenti- cation. Provision Factory Defaults Allow to provision factory default Secure Boot keys when System is in Setup Mode. Install Default Secure Boot Keys Please install default secure boot keys if it’s the first time you use secure boot.
  • Page 72 d) EFI_CERT_SHA256, 384, 512 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Default, External, Mixed, Test Key Exchange Keys Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER encoded) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHA256, 384, 512 2.
  • Page 73 EP2C622D16FM / EP2C621D16FM a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER encoded) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHA256, 384, 512 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Default, External, Mixed, Test Authorized TimeStamps Enroll Factory Defaults or load certificates from a file: 1.

  • Page 74: Boot Screen

    3.5 Boot Screen In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. Boot Option #1 Use this item to set the system boot order. Boot Option Filter This option controls Legacy/UEFI ROMs priority.
  • Page 75 EP2C622D16FM / EP2C621D16FM [Enabled]. Configuration options: [Enabled] and [Disabled]. The default value is [Enabled].

  • Page 76: Csm Parameters

    3.5.1 CSM Parameters Enable to launch the Compatibility Support Module. Please do not disable unless you’re running a WHCK test. If you are using Windows 10 64-bit and all of your devices support UEFI, you may also disable CSM for faster boot speed. Launch Other Storage OpROM Policy Select UEFI only to run those that support UEFI option ROM only.
  • Page 77 EP2C622D16FM / EP2C621D16FM SLIMLIN1-1 Slot OpROM To select slot Storage and Network Option ROM policty. In Auto option, the default is Disabled with NVMe device, but it is LEgacy with other devices. (This item can't select Video Option ROM policy.) SLIMLIN1-2 Slot OpROM To select slot Storage and Network Option ROM policty.

  • Page 78: Event Logs

    3.6 Event Logs Change Smbios Event Log Settings This allows you to configure the Smbios Event Log Settings. When entering the item, you will see the followings: Smbios Event Log Use this item to enable or disable all features of the SMBIOS Event Logging during system boot.
  • Page 79 EP2C622D16FM / EP2C621D16FM entries which utilize a multiple-event counter. The value ranges from 0 to 99 minutes. View Smbios Event Log Press <Enter> to view the Smbios Event Log records. All values changed here do not take effect until computer is restarted.

  • Page 80: Server Mgmt

    3.7 Server Mgmt Wait For BMC Wait For BMC response for specified time out. In PILOTII, BMC starts at the same time when BIOS starts during AC power ON. It takes around 30 seconds to initialize Host to BMC interfaces.

  • Page 81: System Event Log

    EP2C622D16FM / EP2C621D16FM 3.7.1 System Event Log SEL Components Change this to enable ro disable all features of System Event Logging during boot. Erase SEL Use this to choose options for earsing SEL. When SEL is Full Use this to choose options for reactions to a full SEL.

  • Page 82: Bmc Network Configuration

    3.7.2 BMC Network Configuration Lan Channel (Failover) Manual Setting IPMI LAN If [No] is selected, the IP address is assigned by DHCP. If you prefer using a static IP address, toggle to [Yes], and the changes take effect after the system reboots. The default value is [No].
  • Page 83 EP2C622D16FM / EP2C621D16FM The default login information for the IPMI web interface is: Username: admin Password: admin For more instructions on how to set up remote control environment and use the IPMI man- agement platform, please refer to the IPMI Configuration User Guide or go to the Support...

  • Page 84: Exit Screen

    3.8 Exit Screen Save Changes and Exit When you select this option, the following message “Save configuration changes and exit setup?” will pop-out. Press <F10> key or select [Yes] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, the following message “Discard changes and exit setup?”...

  • Page 85: Chapter 4 Software Support

    4.2.4 Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, welcome to visit ASRock Rack’s website at http://www.ASRockRack.com; or you may contact your...

  • Page 86: Chapter 5 Troubleshooting

    Chapter 5 Troubleshooting 5.1 Troubleshooting Procedures Follow the procedures below to troubleshoot your system. Always unplug the power cord before adding, removing or changing any hardware com- ponents. Failure to do so may cause physical injuries to you and damages to motherboard components.
  • Page 87 1. Verify if the battery on the motherboard provides ~3VDC. Install a new battery if it does not. 2. Confirm whether your power supply provides adaquate and stable power. Other problems... 1. Try searching keywords related to your problem on ASRock Rack’s FAQ page: http://www.asrockrack.com/support...

  • Page 88: Technical Support Procedures

    5.2 Technical Support Procedures If you have tried the troubleshooting procedures mentioned above and the problems are still unsolved, please contact ASRock Rack’s technical support with the following information: 1. Your contact information 2. Model name, BIOS version and problem type.
  • Page 89 EP2C622D16FM / EP2C621D16FM Appendix Mezzanine Card Support List This motherboard supports the following ASRock Rack mezzanine cards. Mezz Card Type Mezz Slot Type Model LAN Card Mezz Type A M350 LAN Card Mezz Type A M350R LAN Card Mezz Type A...
