Identifying server components

Front panel components

Item Component
1 NIC LED
2 Hard Disk Drive LED
3 Power Button
4 USB Ports
Item Component
5 Health LED
6 Panel door lock

Rear panel components

Item Component
1 Power Supply Outlet
3 PCI Holder
4b PCI Bracket 2
6 Rear USB 2.0 Ports
8 Embedded NIC Port
10 Kensington Lock

System board components

Item Designator
1 J16
2 J15
3 J23
4 J6
2
Item Component
2 PSU Fan
4a PCI Bracket 1
5 e-SATA Connector
7 VGA Port
9 Rear System Fan
Description
VGA connector
NIC1/USBx2 connector
e-SATA Connector
PCIe x1 slot
