QuickSpecs
Overview
Front View:
Front View:
Front View:
Front View:
1. Five removable media bays
2. Front display panel; includes power button, UID, two USB 2.0
ports, and system status LED's
3. CD-ROM Drive (Dual-Core models), DVD-ROM Drive
(Quad-Core models)
4. Eight SFF (2.5") (shown) or six LFF (3.5") SAS or SATA Hot
Plug drive bays
5. Six expansion slots (three PCI Express, three PCI-X)
6. Two system fans standard with support for optional redundant
system fans
7. Support for two Intel Dual-Core or Quad-Core Xeon 5000
sequence processors
8. Eight PC2-5300 FB-DIMM (DDR2 667) memory sockets
9. Single Hot-Plug power supply standard, optional second
redundant supply for availability
What's New
What's New
What's New
What's New
Intel's latest Quad-Core Xeon 5300 series processors with 8MB (2x4MB) L2 cache and up to 1333 MHz FSB
Enhanced memory support on Quad-Core models for a maximum of 32 GB of FB-DIMM memory
PCI-X expander cage option kit provides 2 additional full length 64-bit PCI-X slots from a single PCI Express slot
Support for the expanded portfolio of Hot Plug 2.5" (SFF) and 3.5" (LFF) SAS and SATA hard disks.
At A Glance
At A Glance
At A Glance
At A Glance
Building on a tradition of excellence, the HP ProLiant family introduces the fifth generation HP ProLiant ML350 server. The HP
ProLiant ML350 G5 server provides Multi-Core performance, enterprise level management, and highly available redundant options
in a modular server form factor. New for this generation is a smaller and quieter chassis, embedded Smart Array E200i Controller
and 5 media bays.
DA - 12475
Canada — Version 15 — July 25, 2007
HP ProLiant ML350 Generation 5 (G5)
HP ProLiant ML350 Generation 5 (G5)
HP ProLiant ML350 Generation 5 (G5)
HP ProLiant ML350 Generation 5 (G5)
Rear View:
Rear View:
Rear View:
Rear View:
1. Monitor port
2. Serial port
3. USB ports
4. Integrated Lights-Out 2 (iLO2) port
5. Network port
6. PCI Express x4
7. PCI-X 64/100
8. PCI-X 64/133
9. Access to add 2nd redundant power supply
10. Mouse port
11. Keyboard port
12. Power
Page 1
