SECTION ONE: NFN WEB SERVER FEATURES

1.1 P
RODUCT
The NOTI•FIRE•NET™ Web Server is a web-based device that acts as an HTML server that allows remote access
to the NOTI•FIRE•NET™ network via the Internet or an Intranet. With the NFN Web Server interface, the user can
view the history of a fire alarm control panel (FACP), event status, device properties, and other information based on
access permissions defined by the system administrator. All data available on the web server is a "snapshot" of the data
on the NOTI•FIRE•NET™ network at the time the browser requested the information. The NFN Web Server
communicates to NOTI•FIRE•NET™ version 5.0 and later. The NFN Web Server interfaces to the Internet/Intranet
using an IP-based wire Ethernet connection or through a direct dial-up connection using a modem. The Serial Configu-
ration Tool allows you to make the necessary network configuration settings for the web server to be able to communi-
cate with the browser.
1.2 NFN W
Below are some of the features of the NFN Web Server and Serial Configuration Tool
Ability to access NOTI•FIRE•NET™ device and system statuses and properties remotely via the Internet,
•
Intranet or direct dial-up connection.
Compatible with NOTI•FIRE•NET™ version 5.0 and later
•
• Serial Configuration Tool runs on any laptop or PC using Windows™ and having an open COM port
• One web server supports multiple users
• Standard IP over Ethernet connection
• Up to 128 user accounts are supported
• Built-in password security and user access record
• Supports standard Microsoft® Internet Explorer 5
• Intuitive Explorer user interface
• Sends up to 50 emails in response to any system event
1.3 R
ELATED
Below is a list of NOTI•FIRE•NET™ related documentation.
For information on...
Compatible Devices
Cabinets & Chassis
Auxiliary Power Supplies
& Battery Chargers
Offline Programming
Utility
VeriFire-TCDNetworking
Panels and Annunciators
NFN Web Server User's Manual PN 51990:A2 12/02/03
www.PDF-Zoo.com
D
ESCRIPTION
S /S C
EB ERVER ERIAL
D
OCUMENTATION
Refer to...
Device Compatibility Document
CAB-3/CAB-4 Series Installation Document
ACPS-2406 Installation Manual
Veri•Fire™ Tools on-line help file
V eri•Fire™ Medium Systems on-line help file
Veri•Fire™ Tools CD Insert
Noti•Fire•Net™ Manual
NCM-W/F Installation Document
MIB Media Interface Board
NCS Network Control Station
NCA Network Control Annunciator
BACnet Gateway
NFS-640 Installation/Operation/Programming manuals
NFS-3030 Installation/Operation/Programming manuals
Network Control Annunciator (NCA)
Network Control Station (NCS)
AFP-200 Instruction manual
AFP-300/400 Installation/Operation/Programming manuals
AM2020/AFP1010 Installation/Operation/Programming manuals
UniNet Online Instruction Manual
Table 1.3-1: Related Documentation
T
ONFIGURATION OOL
F
EATURES
Part No.
15378
15330
51304
VeriFire-TCD
VeriFire-CD
51871
51584
51533
50255
51095
51482
51659
51332/51334/51333
51330/51344/51345
51482
51095
15511
50253/50260/50259
15088
51994
