Erver To; Onnect ); Odem; Onnection - Notifier NOTI-FIRE-NET Installation & Operation Manual

2.6 DB-9
TO
Connecting the NFN Web Server to an NCM-W/F allows the Web Server to communicate with devices on the
NOTI•FIRE•NET™ network. Use the NCM-W with twisted pair wire and the NCM-F with fiber-optic cable. The
NFN Web Server can also connect directly to an NFS-640 or NFS-3030 panel via the NUP port on the CPU-640 or
CPU-3030. Make connections according to Figure 2.6-1 below:
connection to an NCM-W/F or
an NFS-640 or NFS-3030
2.7 M C

ODEM

You can connect the NFN Web Server to a modem, allowing communication between the server and the browser via
telephone lines. The modem must be supplied by the customer; the cable comes with the NFN Web Server PC board.
NOTE: The modem used must be ITE listed
!
equipment.
Modem cable supplied with Web Server
assembly. NOTE: Make sure the red line on the
ribbon lines up with the top of the modem
connector.
Figure 2.7-1: 10-Pin to DB-9 Connection (Modem Connection)
18
www.PDF-Zoo.com
NUP C
(NFN W

ONNECTION

NUP end - connect to
outer NUP port J2
DB9 to NUP cable
P/N 75554

Figure 2.6-1: DB-9 to NUP Connection

(NFN W
ONNECTION
red line on this end
S NCM-W/F
EB

ERVER TO

DB-9 end - connect
to EIA-232 port on
Web Server
S M
EB ERVER TO ODEM
Modem connector (J4)
NFN Web Server User's Manual PN 51990:A2 12/02/03
NUP D
OR IRECT
NFN Web Server
PC Board
)
NFN Web Server
PC board
C )
ONNECT
