2.2 I
NSTALLATION
Use the following checklist as a guideline for assembling the hardware and making necessary cable connections. The
sections that follow provide details on making these connections.
CAUTION: Different sources of power are used in conjunction with the NFN Web Server product. Disconnect all
sources of power before servicing. This device and associated equipment may be damaged by removing and/or
inserting cards, modules or interconnecting cables while this unit is powered. This damage may adversely affect the
operation of this unit, but its effect may not be readily apparent.
14
www.PDF-Zoo.com
O
VERVIEW
NFN Web Browser Assembly Checklist
Install NFN Web Server PC board onto mounting plate
Install power supply onto mounting plate
Install PNET-1 onto mounting plate
Install mounted NFN Web Server assembly into cabinet
Install NCM-W/F - not required for direct connection
Web Server serial connection to NCM-W/F or panel CPU (P/N 75554)
Web Server power connection (P/N 75581)
Web Server network connection
PNET-1 surge suppressor connection (P/N 75585)
NCM-W/F power connection (P/N 75583) - not required for direct connection
NCM-W/F data connection

Figure 2.2-1: NFN Web Server Assembly Checklist

Hardware Assembly
Cable Connections
NFN Web Server User's Manual PN 51990:A2 12/02/03
