3.3 U
SING
Veri•Fire™ Tools is supplied on CD-ROM. To install the application onto the PC or laptop, follow these steps:
1. Insert the CD-ROM into the CD-ROM drive.
2. From Windows Explorer or the Run command, execute setup.exe from the root directory of the CD-ROM.
3. This will execute the install application. Follow the directions on screen to install Veri•Fire™ Tools.
4. Once it is installed, it can be launched from the Start menu by selecting Programs, VeriFire Tools, VeriFire
Tools.
Veri•Fire™ Tools can communicate with the Web Server in one of two ways:
1. Direct communication by connecting Veri•Fire's PC to the web server's serial port - this connection, using
DB9-DB9, is used for the Web Server's initial setup to be able to communicate over the NFN network.
2. Communication over the NFN network by connecting Veri•Fire's PC to the second NUP port of an NCM that
is on the same network as the Web Server.
T S
HE ERIAL
To activate communications between the PC and the NFN Web Server, use the Serial Port Configuration Utility,
accessed from the Start menu by selecting Start, Programs, VeriFire Tools, Serial Port Configuration Utility. The
NUP Serial Port Auto Configuration dialog will appear (seen in Figure 3.3-1).
PC D
IRECTLY
For a PC directly connected to the NFN Web Server, click on the Auto Configuration button to establish communica-
tions. When finished, exit by clicking on the x button in the top right corner.
IMPORTANT: When the NFN Web Server is first being configured, you must use this direct serial connection to
initially establish communication between the Web Server and the PC.
PC C
OMMUNICATING TO
NOTE: T
HIS OPTION IS ONLY USED WHEN IT IS NECESSARY TO RE
For a PC Communicating to NFN Web Server Via the NCM, run the Serial Port Configuration Utility to establish
communications.
NFN Web Server User's Manual PN 51990:A2 12/02/03
www.PDF-Zoo.com
V •F ™ T
ERI IRE

OOLS FOR

!
P C U
ORT

ONFIGURATION

C NFN W
ONNECTED TO
NFN W S
EB

Figure 3.3-1: Serial Port Configuration Utility

NOTES: If the Web Server is to be connected via an NCM, you must specify the node
number being used for the NFN Web Server by accessing Veri•Fire™ Tools.
!
If the NFN Web Server does not yet have a node number, the PC must be connected
directly to the Web Server first to give it one.
NOTE: To configure the NWS via an NCM, you must have
!
a NUP-to-DB9 cable (P/N 75554, sold separately).
C
ONFIGURATION
NOTE: The NFN Web Server is
compatible with Veri•Fire™ Tools
version 3.00 or later.
TILITY
S
EB ERVER
V NCM
ERVER IA
-
CONFIGURE THE
W S .
EB ERVER SETTINGS
