4.3.3 S
YSTEM
Selecting System Administration, System Settings allows you to make NFN Web Server browser configuration settings.
S S
ITE ETTINGS
Site Name - This is a user defined field designed to facilitate a unique descriptive name for the NFN Web Browser.
Site Link - This is a user defined field that allows you to add a shortcut to the link list at the left of the NFN Web
Browser window. This link can be to a graphic image of the network site or a company homepage.
Site Link Name - This is the name that will be displayed in the browser header when the Site Link address is accessed.
G S
ENERAL ETTINGS
Non-Admin User Access - This setting defines whether or not operators will have access to the NFN Web Server.
Network Update - Select Yes to have the NFN Web Server auto detect points daily.
Network Update Time - If the Web Server is configured to auto detect points daily, this field is used to select the time
you want the Web Server to perform this action.
Trouble Reminder - If there is an active trouble on the network, every 24 hours at 11:00 AM, a trouble reminder
message will be generated across the network.
Event Refresh Time - This field is used to specify a refresh rate (between 3 and 90 seconds) for the Multiple Event
List. The NWS will automatically refresh itself at the specified interval. Any new system event will be displayed in
the Multiple Event List. To disable this feature, set the time to 0.
Unacknowledged Beep - Check this option to enable an audible reminder of unacknowledged events. When this is
checked, the Web Server will beep at 3-second intervals and will continue until no unacknowledged events are shown
in the Multiple Events List.
NCM S
ETTINGS
Node Address - The node where the NCM is located on the NOTI•FIRE•NET™ network.
Channel A/B Threshold - Threshold settings are used according to the amount of network noise present; changing the
threshold settings will initialize the NCM board itself.
Style 7 - Select Yes if style 7 is being used.
NFN Web Server User's Manual PN 51990:A2 12/02/03
www.PDF-Zoo.com
S
ETTINGS
Figure 4.3.3-1 System Settings
NOTE: Only alphanumeric characters are supported for the Site Settings fields, with
!
the exception of the colon, forward slash and period.
35
