Speco HT-7715DNV Specification Sheet

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Color Day/Night Weatherproof Camera
• 1/3" SONY ExView* CCD sensor - 470 lines of resolution • Split Glass Technology to avoid IR reflections
• Auto iris DC Vari-Focal Lens (4mm-9mm)
• LUX level dip switch adjusts day/night settings to your requirements
• Dual voltage operation • Built-in 11 IR LEDs (60' Range**) & CDS sensor for day/night performance
• Controls for BLC, ELC, F/L and L/L • Video Test Connector for easy installation
• Built-in heater extends operating range and avoids condensation • Weatherproof operation
• Excellent low light level performance - 0.03 Lux in existing light, 0.0 Lux with IR LEDs

Specifications

Image Sensor . . . . . . . . . . . . . . . . . .
Resolution . . . . . . . . . . . . . . . . . . . .
Minimum Illumination . . . . . . . . . . . .
Lens . . . . . . . . . . . . . . . . . . . . . . . .
CDS Sensor . . . . . . . . . . . . . . . . . . .
Electronic Shutter . . . . . . . . . . . . . . .
Video Output . . . . . . . . . . . . . . . . . .
TV System . . . . . . . . . . . . . . . . . . . .
Scanning System . . . . . . . . . . . . . . . .
Sync System. . . . . . . . . . . . . . . . . . .
S/N Ratio . . . . . . . . . . . . . . . . . . . .
Gamma Characteristic . . . . . . . . . . . .
Power Supply . . . . . . . . . . . . . . . . . .
Power Consumption . . . . . . . . . . . . . .
Operating Temperature . . . . . . . . . . . .
Dimensions . . . . . . . . . . . . . . . . . . .
Weight . . . . . . . . . . . . . . . . . . . . . .
*ExView is a trademark of the Sony Corporation
**Depending on scene reflection
HT-7715DNV Camera
Mounting Hardware
For more information contact us at:
HT-7715DNV
Features
1/3" Sony ExView* CCD
470 lines
.0.03 lux (IR off) 0.00 lux (IR on)
DC Auto iris, 4mm-9mm (Varifocal)
Photoconductive cells - adjustable
1/60 - 1/100,000 seconds
1.0 Vp-p into 75 ohms composite
NTSC
2:1 Interlace
Line locked/ adjustable V-phase
Line lock/internal on-off
More than 60 dB
0.45
24 Volts AC, 12 Volts DC- dual voltage
600mA
-20˚F to 122˚F - RH 95%
2.4"W x 2.25"H x 7"L
1 lb.
Package Includes:
Instructions
Warranty card
Video Test Cable
