Summary of Contents for Summit SWC1875
- Page 1 WINE CELLAR Instruction Manual Model No.: SWC1875 BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Felix Storch, Inc. Write Serial No. (on back of unit) here: 770 Garrison Avenue Bronx, NY 10474 ________________________________ www.summitappliance.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Appliance Safety Important Safeguards Location of Parts Installation Instructions Before Using Your Appliance Installation of Your Appliance Built-in Cabinet Instructions Electrical Connection Extension Cord Reversing the Door Swing of Your Appliance Installing the Stainless Steel Handles Operating Your Appliance 9-11 Recommended Temperature Settings Control Panel... -
Page 3: Appliance Safety
APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. - Page 4 • Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in this manual. All other servicing should be referred to a qualified technician. FOLLOW WARNING CALLOUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL •...
-
Page 5: Location Of Parts
LOCATION OF PARTS Cabinet Digital Control Panel Upper Door Full Shelves (Total 12) Handle Upper Zone Security Lock Lower Door Lower Zone Half Shelves (Total 2) Adjustable Legs INSTALLATION INSTRUCTIONS BEFORE USING YOUR APPLIANCE • Remove the exterior and interior packing. •... -
Page 6: Built-In Cabinet Instructions
BUILT-IN CABINET INSTRUCTIONS This unit is designed for either built-in or free-standing installation. If you plan to use the unit in a built-in application, use the following dimensions for the enclosure: Model SWC1875 23 ⅝” / 60 cm Width Depth ¼... -
Page 7: Extension Cord
The appliance should always be plugged into its own individual electrical outlet which has a voltage rating that matches the rating label on the appliance. This provides the best performance and also prevents overloading house wiring circuits that could cause a fire hazard from overheating. Never unplug the appliance by pulling on the power cord. -
Page 8: Installing The Stainless Steel Handles
3. Remove the lower door hinge (2) and then install it at the designated position on the opposite side. And install the door shaft assembly (3) accordingly. (Fig. 2) 4. Remove the center hinge (4) by unscrewing the two fixing bolts. Be careful to hold the glass door firmly after removing the bolts. -
Page 9: Operating Your Appliance
OPERATING YOUR APPLIANCE It is recommended you install the appliance in a place where the ambient temperature is between 72º and 78ºF (23º-26ºC). If the ambient temperature is above or below the recommended temperatures, the performance of the unit may be affected. For example, placing your unit in extreme cold or hot conditions may cause interior temperatures to fluctuate. -
Page 10: Interior Lights
It is recommended to set the LOWER ZONE to 55º - 65ºF (13º - 18ºC) which is ideal for storing white and red wines and the UPPER ZONE to 40º - 55ºF (5º - 13ºC) which is ideal for storing sparkling and white wines. -
Page 11: Wine Shelves
WINE SHELVES To prevent damaging the door gasket, make sure to have the door all the way open when pulling the shelves out of a rail compartment. • For easy access to the stored bottles, you can pull a shelf approximately halfway out of the rail compartment. -
Page 12: Moving Your Appliance
MOVING YOUR APPLIANCE 1. Remove all items. 2. Securely tape down all loose items (shelves) inside your appliance. 3. Turn the adjustable legs up to the base to avoid damage. 4. Tape the doors shut. 5. Be sure the appliance stays secure in the upright position during transportation. Also, protect the outside of the appliance with a blanket or similar item. -
Page 13: Troubleshooting
TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. Troubleshooting Guide PROBLEM POSSIBLE CAUSE The unit does not operate. Not plugged in. -
Page 14: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship.
