WINE and BEVERAGE COOLER
Beverage Coolers:
ASDG1521
ASDG2411
DBGR1563ASD
DBGR2464ASD
CL181WBV
CL24BV1
DBGR1834
DBGR2435
Wine Coolers:
ASDW1522
ASDW2412
DBWC1542ASD
DBWC2443ASD
CL18WC
CL244WC2
DBWC1846
DBWC2447
Wine/Beverage Coolers:
ALFD24WBV
CLFD243WBV
DBFD2495ADA
DBFD2496
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Serial Nos. (on lower left corner of
inside cabinet) here:
MODELS:
SDHG1533
DBGR1565SD
ALBV15
DBGR1562ADA
SDHW1532
DBWC1544SD
ALWC15
DBWC1541ADA
User Manual
An ISO 9001:2015 registered company
SDHG2443
CL156BV1
DBGR2466SD
DBGR1569
AL57GPNR
DBGR2461ADA
SDHW2442
CL155WC1
DBWC2445SD
DBWC1549
SDHWC98
LWC2472
DBWC2472
Felix Storch, Inc.
770 Garrison Ave
Bronx, New York 10474
www.summitappliance.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the DREAMBILT CL156BV1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Summit DREAMBILT CL156BV1

  • Page 1 WINE and BEVERAGE COOLER MODELS: Beverage Coolers: ASDG1521 ASDG2411 SDHG1533 SDHG2443 CL156BV1 DBGR1563ASD DBGR2464ASD DBGR1565SD DBGR2466SD DBGR1569 CL181WBV ALBV15 AL57GPNR CL24BV1 DBGR1834 DBGR1562ADA DBGR2461ADA DBGR2435 Wine Coolers: ASDW1522 ASDW2412 SDHW1532 SDHW2442 CL155WC1 DBWC1542ASD DBWC2443ASD DBWC1544SD DBWC2445SD DBWC1549 CL18WC CL244WC2 ALWC15 SDHWC98 LWC2472 DBWC1846...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Appliance Safety Important Safeguards Disposal Location of Parts Installation Instructions 10-17 Before Using your Appliance Installation of your Appliance 11-12 Electrical Connection 12-13 Reversing the Door Swing of your Appliance 13-14 Adjusting the Kick Plate Installing the Stainless Steel Handle Full Overlay Panel Installation Instructions 15-17 Operating your Appliance...
  • Page 3: Appliance Safety

    APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others.
  • Page 4 • In the event of any damage: - Avoid open flames and anything which creates a spark, - Disconnect from the power supply, - Air the room in which the appliance is located for several minutes and - Contact the Service Department for advice. •...
  • Page 5: Disposal

    or discolor the interior. • Use this appliance only for its intended purpose as described in this Instruction Manual. • Keep fingers out of the “pinch point” areas. Clearances between the door and cabinet are necessarily small. Be careful closing the door when children are in the area. - SAVE THESE INSTRUCTIONS - DISPOSAL Dispose of your appliance packaging properly.
  • Page 6: Location Of Parts

    LOCATION OF PARTS Wine Cooler ALWC15 / CL155WC1 / CL18WC / DBWC1541ADA / DBWC1549 / DBWC1846 Digital Control Panel Handle LED Light Door Shelves (5) Security Lock Ventilation Adjustable Grille Legs Beverage Cooler ALBV15 / AL57GPNR / CL156BV1 / CL181WBV / CL24BV1 / DBGR1562ADA / DBGR2461ADA / DBGR1569 / DBGR1834 / DBGR2435 Digital Control Panel...
  • Page 7 Wine Cooler ASDW1522 / SDHW1532 / ASDW2412 / SDHW2442 / DBWC1542ASD / DBWC1544SD / DBWC2443ASD / DBWC2445SD Shelves Handle LED Light Door Digital Control Panel Grille Adjustable Security Lock Legs Beverage Cooler ASDG1521 / SDHG1533 / ASDG2411 / SDHG2443 / DBGR1563ASD / DBGR1565SD / DBGR2464ASD / DBGR2466SD Shelves (3) Handle...
  • Page 8 Wine Cooler CL244WC2 / DBWC2447 Door Shelves (5) Digital Control Handle Panel Kick-plate Plinth Light (If available) Plinth Light Switch Security Adjustable (If available) Lock Legs Wine/Beverage Cooler ALFD24WBV / CLFD243WBV / DBFD2495ADA / DBFD2496 LED Light Shelves (6) Shelves (2) Handle Digital Control Panel...
  • Page 9: Wine Cooler

    Wine Cooler SDHWC98 / DBWC2472 / LWC2472 Shelves (16) Door Digital Control Handle Panel Security Kick-plate Lock Adjustable Legs...
  • Page 10: Installation Instructions

    INSTALLATION INSTRUCTIONS Before Using your Appliance Remove the exterior and interior packing. • CAUTION: After unpacking you MUST allow this appliance to stand upright for at least 2 hours to allow the lubricant and refrigerant to drain back into the compressor and stabilize. Failure to do so may adversely affect performance and the lifetime of this unit.
  • Page 11 Built-in Under-Counter Instructions Make sure your installation does not block the front ventilation grille. The unit is designed to fit under worktops, using the height-adjustable ventilation grille to ensure that the feet are concealed from front view. If the unit is fully integrated to be installed for fitting kitchen plinth, make sure that the ventilation gaps in the plinth are at least 300 square centimeters and remove the ventilation grilles, so that warm air can disperse unhindered.
  • Page 12: Electrical Connection

    NOTE: To ensure proper service access and ventilation:  A must be at least ¼" (5mm) greater than a.  B must be at least ¼" (5mm) greater than b. C must be at least ¼" (5mm) greater than c. ...
  • Page 13: Extension Cord

    This appliance should be properly grounded for your safety. The power cord of this appliance is equipped with a three-prong plug which mates with standard three-prong wall outlets to minimize the possibility of electrical shock. Do not under any circumstances cut or remove the third (ground) prong from the power cord supplied.
  • Page 14: Adjusting The Kick Plate

    WARNING Use extreme caution with the articulated hinges. The hinge is self-closing, and many pinch points exist prior to built-in installation. 1. Remove the cover caps (3) and then remove the glass door by unscrewing the four screws (1) and (2). Be careful to hold the glass door firmly after removing the screws and place it on a padded surface to avoid the risk of damage.
  • Page 15: Full Overlay Panel Installation Instructions

    Full Overlay Panel Installation Instructions These models are designed for field-installed overlay panel. The overlay panel covers the stainless steel to give a built-in appearance. The overlay panel and appropriate hardware are not included with the unit and the end user needs to prepare them themselves. Please follow the instructions below for installation: Door Panel Preparation Prepare the overlay panel to the dimensions shown below.
  • Page 16: Door Panel Installation

    Door Panel Installation NOTE: This design will leave a 3mm gap between the panel and the unit door. If you do not want the 3mm gap, you will have the option to route the wood according to the bracket’s dimensions. Then proceed to install the bracket following the instructions below. Installing the handle on the overlay panel If reusing the handle that came with the unit: 1.
  • Page 17 5. Prepare the unit for panel installation, by removing the lock bracket (8) and magnetic activator (5) from the bottom of the door and remove the magnetic activator (4) & hole plugs (6) from the top of the door. This is done by removing the screws that attach the lock bracket and magnetic activators to the door.
  • Page 18: Operating Your Appliance

    OPERATING YOUR APPLIANCE It is recommended that you install the appliance in a place where the ambient temperature is between 72º and 78ºF (23º to 26ºC). If the ambient temperature is above or below the recommended temperatures, the performance of the unit may be affected. For example, placing your unit in extremely cold or hot conditions may cause interior temperatures to fluctuate.
  • Page 19 Setting the Temperature Control You can set the temperature by touching the UP and DOWN keys. When you push the two • buttons at the same time, the LED readout will show the original temperature set previously. (The temperature preset at the factory is 54°F or 12°C for wine cooler and 38°F or 3°C for beverage cooler.) The temperature you are setting will increase by one degree each time you touch the Up •...
  • Page 20 ºF/ºC Selector Select the temperature display setting in Fahrenheit or Celsius degree. To change the temperature from Fahrenheit to Celsius or from Celsius to Fahrenheit, press and hold the LIGHT key for 5 seconds. Display is for the UPPER temperature zone and is for the LOWER temperature zone.
  • Page 21 ºF/ºC Selector Set the temperature to be displayed in degree Fahrenheit or degree Celsius. LIGHT To turn the interior light on/off, lightly touch and hold the key for 5 seconds. Used to increase (warm) the set temperature by 1°C/1ºF. DOWN Used to decrease (cool) the set temperature by 1°C/1ºF.
  • Page 22  The temperature will increase 1°C/1ºF if you touch the UP key once, or the temperature will decrease 1°C/1ºF if you touch the DOWN key once. The display flashes while you make the setting.  The set temperature will temporarily flash in the display for 5 seconds after the temperature has been set.
  • Page 23 Wifi connection signal Anti-condensation mode Relative humidity display (Only display the humidity, cannot control it) Multi-key Function To perform the multi-key function, lightly touch and hold the first key, then touch the rest key for at least 5 seconds and then release all the keys. Child Lock If in 2 minutes or longer without touching any key, the child lock will be activated automatically for models with the control outside of cabinet.
  • Page 24: Settings Mode

    Settings Mode Certain settings on the wine cabinet can only be selected in settings mode. In Settings mode only the UP and DOWN keys of lower/right zone are functional for dual zone LED display units. Touch and hold the UP key for 5 seconds to enter and leave Settings mode. The appliance will leave Settings mode automatically after approximately one minute.
  • Page 25: Interior Light

    Interior Light The interior light makes it easy to view your wine labels and enhances the display of your collection. Touching and holding the LIGHT key for 5 seconds allows you to toggle between 2 modes of operation for the internal lights: functional (default) mode and showcase mode. If you are in functional (default) mode (also named energy saving mode), the lights will turn on only when the door is open.
  • Page 26: Dynamic Cooling And Silent Mode

    Mode LIMA ILENT The appliance has two different running modes. In Silent mode once the required temperature is reached, the appliance will run without the fan. In DynaClima mode the fan cycles on and off to circulate the air even after the required temperature is reached. This ensures consistent humidity and temperature distribution in the wine cooler, creating perfect conditions for long term storage.
  • Page 27: Defrosting

    to the position where the notch of the shelf is exactly under the plastic post and lift the shelf. To replace the shelf, repeat the steps described above in reverse. CAUTION: When removing or replacing the shelf, use caution not to scratch the sides of the unit. Rail Shelves To prevent damaging the door gasket, make sure to have the door all the way open when pulling the...
  • Page 28 • Keep small gaps between the walls and the bottles to allow air to circulate. As in an underground cellar, air circulation is important to prevent mold and for a more homogeneous temperature within the cellar. • To facilitate air circulation, do not overload your wine cellar. •...
  • Page 29: Care And Maintenance

    CARE AND MAINTENANCE Cleaning your Appliance CAUTION: Failure to unplug the appliance during cleaning could result in electrical shock or other personal injury. • Turn off the power, unplug the appliance, and remove all items, including shelves. Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of •...
  • Page 30: Troubleshooting

    TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. PROBLEM POSSIBLE CAUSE REMEDY Appliance is not connected to a power Connect the appliance.
  • Page 31 “E5”, “E6” or temperature sensor has failed. “E7”. “E3” or “E4” indicates that the defrost sensor in the evaporator has failed. “E5” indicates a defrost heater failure. “E6” indicates a solenoid valve failure. “E7” indicates a door switch failure. Has the appliance door been open for If yes, close the door.
  • Page 32: Limited Warranty

    LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship.
