Summit SWC1545 Instruction Manual

Wine cellar
Hide thumbs
Table of Contents

Advertisement

Quick Links

BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Serial No. (on back of unit) here:
________________________________
WINE CELLAR
Model SWC1545
Model No.: SWC1545
Instruction Manual
Felix Storch, Inc.
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWC1545 and is the answer not in the manual?

Questions and answers

Related Manuals for Summit SWC1545

Summary of Contents for Summit SWC1545

  • Page 1 WINE CELLAR Model SWC1545 Model No.: SWC1545 Instruction Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Felix Storch, Inc. Write Serial No. (on back of unit) here: 770 Garrison Avenue Bronx, NY 10474 ________________________________ www.summitappliance.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Appliance Safety ................. Important Safeguards ..............Location of Parts ................ Installation Instructions ............. Before Using Your Appliance ..........Installation of Your Appliance ..........Electrical Connection .............. Extension Cord ............... Installing the Stainless Steel Handle ........Operating Your Appliance ............7-10 Recommended Temperature Settings ........

  • Page 3: Appliance Safety

    APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others.
  • Page 4  Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in this manual. All other servicing should be referred to a qualified technician. FOLLOW WARNING CALLOUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL ...

  • Page 5: Location Of Parts

    LOCATION OF PARTS Hinge Control panel Activated charcoal filter Upper zone Cabinet Glass door Sliding shelf Lower zone Ventilation hole Sliding shelf Front ventilation base Adjustable foot (4) INSTALLATION INSTRUCTIONS BEFORE USING YOUR APPLIANCE  Remove the exterior and interior packing. ...

  • Page 6: Electrical Connection

    the appliance is never covered or blocked in any way.  Do not install the appliance near an oven, radiator or other heating source. Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption. Do not install in a location where the temperature will fall below 60°F (16°C).

  • Page 7: Installing The Stainless Steel Handle

    If the unit is unplugged, or power is lost or turned off, you must wait at least 5 minutes before restarting the unit. If you attempt to restart before this time delay, the unit will not start. The SWC1545 defrosts itself automatically. RECOMMENDED TEMPERATURE SETTINGS Conservation 49 ~ 57ºF...

  • Page 8: Control Panel

    CONTROL PANEL Digital Digital Display 2 Display 1 ON/OFF Key turns the wine cellar on and off. It should be in the OFF position when the unit is being plugged in to a power source or disconnected from that source. Digital Display 1 shows the current temperature or preset temperature of the upper zone of the cabinet.

  • Page 9: Setting The Temperature Controls

    SETTING THE TEMPERATURE CONTROLS  The temperature-setting ranges of the upper zone (54°F to 72°F, or 12°C to 22°C) and lower zone (41°F to 54°F, or 5°C to 12°C) are effective when the ambient temperature is less than or equal to 90°F, or 32°C.

  • Page 10: Door Lock

    Any servicing of the electrical circuit must only be performed by a qualified electrician. Whatever the case, if your appliance does not seem to be operating normally, unplug it and call for service. SUMMIT's Customer Help number is 1-800-932-4267.

  • Page 11: Care And Maintenance

     Replace the activated charcoal filter in the cabinet's upper ventilation hole every six months. These filters are available from SUMMIT through our website, www.summitappliance.com/support, or by calling Customer Service at 1-800-932-4267.

  • Page 12: Troubleshooting

    Display shows E8. Buzzer sounds. The lower zone is becoming too cold. If display message does not return to normal temperature reading within an hour or two, call for service*. * Call SUMMIT Customer Service at 1-800-932-4267 weekdays between 8:00AM and 5:00PM (ET).

  • Page 13: Limited Warranty

    LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship.
