Icom IC-PW1 Service Manual Addendum page 81

[CONNECT UNIT]
REF ORDER
NO. NO.
C1 4030010210 S.CER C3216 JB 1C 105M-T
C2 4030010210 S.CER C3216 JB 1C 105M-T
C3 4030010210 S.CER C3216 JB 1C 105M-T
C4 4030010210 S.CER C3216 JB 1C 105M-T
C5 4030010210 S.CER C3216 JB 1C 105M-T
C6 4030010210 S.CER C3216 JB 1C 105M-T
C7 4030010210 S.CER C3216 JB 1C 105M-T
C8 4030010210 S.CER C3216 JB 1C 105M-T
J1 6510017650 CON 52045-1045
J2 6510003411 CON B05B-EH-S(LF)(SN)
J3 6510003411 CON B05B-EH-S(LF)(SN)
[L-NET UNIT]
REF ORDER
NO. NO.
WS1 8600035830 EX1900 P01*J01L
D1 1710000051 DIO 1SS53-AZ
D2 1710000051 DIO 1SS53-AZ
L1 6180000990 COI LAL 04NA 101K
L2 6180000990 COI LAL 04NA 101K
L3 6110003360 COI LA-530
L4 6110003500 COI LA-543
L5 6110003490 COI LA-542
C1 4020000970 CYL UP050B 472K Z
C2 4020000970 CYL UP050B 472K Z
C3 4010008840 CER DSTB90SJYR104K 1
C4 4010008840 CER DSTB90SJYR104K 1
RL1 6330000571 REL AR322173FC01
RL2 6330000571 REL AR322173FC01
EP1 6910011340 TER OT-010 M3
DESCRIPTION
DESCRIPTION
[H-NET UNIT]
REF ORDER
NO. NO.
WS1 8600035841
D1 1710000051 DIO
D2 1710000051 DIO
D3 1710000051 DIO
D4 1710000051 DIO
D5 1710000051 DIO
D6 1710000051 DIO
D7 1710000051 DIO
D8 1710000051 DIO
D9 1710000051 DIO
D10 1710000051 DIO
L1 6180000990 COI
L2 6180000990 COI
L3 6180000990 COI
L4 6180000990 COI
L5 6180000990 COI
L6 6180000990 COI
L7 6180000990 COI
L8 6180000990 COI
L9 6180000990 COI
L10 6180000990 COI
L11 6110003410 COI
L12 6110003400 COI
L13 6110003510 COI
L14 6110003380 COI
L15 6110003370 COI
C1 4010008840 CER
C2 4010008840 CER
C3 4010008840 CER
C4 4010008840 CER
C5 4010008840 CER
C6 4010008840 CER
C7 4010008840 CER
C8 4010008840 CER
C9 4010008840 CER
C10 4010008840 CER
C11 4020000970 CYL
C12 4020000970 CYL
C13 4020000970 CYL
C14 4020000970 CYL
C15 4020000970 CYL
C16 4020000970 CYL
C17 4020000970 CYL
C18 4020000970 CYL
C19 4020000970 CYL
C20 4020000970 CYL
RL1 6330000571 REL
RL2 6330000571 REL
RL3 6330000571 REL
RL4 6330000571 REL
RL5 6330000571 REL
RL6 6330000571 REL
RL7 6330000571 REL
RL8 6330000571 REL
RL9 6330000571 REL
RL10 6330000571 REL
EP2 6910011340 TER
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
11
DESCRIPTION
EX1900 P01*J01H-1
1SS53 -AZ
1SS53-AZ
1SS53-AZ
1SS53-AZ
1SS53-AZ
1SS53-AZ
1SS53-AZ
1SS53-AZ
1SS53-AZ
1SS53-AZ
LAL 04NA 101K
LAL 04NA 101K
LAL 04NA 101K
LAL 04NA 101K
LAL 04NA 101K
LAL 04NA 101K
LAL 04NA 101K
LAL 04NA 101K
LAL 04NA 101K
LAL 04NA 101K
LA-535
LA-534
LA-544
LA-532
LA-531
DSTB90SJYR104K 1
DSTB90SJYR104K 1
DSTB90SJYR104K 1
DSTB90SJYR104K 1
DSTB90SJYR104K 1
DSTB90SJYR104K 1
DSTB90SJYR104K 1
DSTB90SJYR104K 1
DSTB90SJYR104K 1
DSTB90SJYR104K 1
UP050B 472K Z
UP050B 472K Z
UP050B 472K Z
UP050B 472K Z
UP050B 472K Z
UP050B 472K Z
UP050B 472K Z
UP050B 472K Z
UP050B 472K Z
UP050B 472K Z
AR322173FC01
AR322173FC01
AR322173FC01
AR322173FC01
AR322173FC01
AR322173FC01
AR322173FC01
AR322173FC01
AR322173FC01
AR322173FC01
OT-010 M3
S.=Surface mount
