Icom IC-PW1 Service Manual Addendum page 153

Including with EP1
MP24
MP95
EP1
MP36
MP96
B
MP96
MP24
EP16
MP25
W2
W1
b
a
MP25
SUB-REG UNIT
MP5 (SR)
MP8 (SR)
MP11
MP13
Note
(SR) : SUB-REG UNIT
B
MP79
MP15
MP15
MP90
MP89
MP25
MP52
MP26
FIL-DC
UNIT
MP11
MP4 (SR)
MP25
MP33
MP34
MP35
MP23
MP11
MP23
MP12
MP38
A
ACT-C UNIT
MP89
MP80
MP14
MP26
MP14
MP52
MP26
MP89
b
MP26
FIL-AC
a
UNIT
MP13
MP32
MP91
MP32
MP32
EP15
MP12
MP12
MP23
EP15
PX-1981 REG UNIT DISASSEMBLY
[REG UNIT-2]
REF NO.
EP2 8930042970 Fan gurd PG-47-02
EP15 6950000410 Super ground (FGA21M-11B)
EP16 6910010950 One touch bush NB-15
MF1 2710000640 MMF-12C12DH-R06
MP11 8810009650 Screw FH BT M3 × 8 NI-ZU
MP12 8810009650 Screw FH BT M3 × 8 NI-ZU
MP13 8810009650 Screw FH BT M3 × 8 NI-ZU
MP14 8810008630 Screw PH BT M3 × 6 NI-ZU
MP15 8810008630 Screw PH BT M3 × 6 NI-ZU
MP23 8810008630 Screw PH BT M3 × 6 NI-ZU
MP24 8810000490 Screw PH M5 ×15
MP25 8810003160 Set screw A M3 × 6
MP26 8810003160 Set screw A M3 × 6
MP31 8810009870 Set screw C M4 × 50
MP32 8830000110 Nut M4
MP33 8810000450 Set screw PH M5 × 8
MP34 8850000590 Tooth lock washer M5
MP35 8110006222 1981 A-bottom cover-2
REG UNIT-1 MP36 8110006212 1981 A-front cover-2
ASSEMBLY
MP37 8110006201 1981 A-rear cover-1
MP38 8110006490 1981 B-top cover
MP52 8810003160 Set screw A M3 × 6
MP79 8810003160 Set screw A M3 × 6
REG-RELAY UNIT
MP80 8810003160 Set screw A M3 × 6
MP89 8810003160 Set screw A M3 × 6
MP90 8810003160 Set screw A M3 × 6
MP91 8930046660 1981 fan plate
MP94 8810009650 Screw FH BT M3 × 8 NI-ZU
MP95 8810009650 Screw FH BT M3 × 8 NI-ZU
MP96 8930047130 1981 terminal plate
MP94
[SUB-REG UNIT]
MP37
REF NO.
A
MP4 8810003170 Set screw A M3 × 8
MP5 8810003180 Set screw A M3 × 10
8810009900 Screw PH M3 × 10 reny screw [EUR-1]
F2
MP8 8930053400 1981 A-sheet (D)
F1
Screw abbreviations: PH: Pan head FH: Flat head
MF1
EP2
MP31
MP31
6 - 11
ORDER
DESCRIPTION QTY.
NO.
1
1
1
1
9
10
17
4
4
11
4
4
4
4
4
1
1
1
1
1
1
4
8
6
4
2
1
4
4
2
ORDER
DESCRIPTION QTY.
NO.
1
[USA, EUR] 1
1
1
MP31
