Icom IC-PW1 Service Manual Addendum page 77

[MAIN UNIT]
REF ORDER
NO. NO.
C214 4030011600 S.CER C1608 JB 1E 104K-T
C215 4030011600 S.CER C1608 JB 1E 104K-T
C216 4030011600 S.CER C1608 JB 1E 104K-T
C219 4030011600 S.CER C1608 JB 1E 104K-T
C220 4030011600 S.CER C1608 JB 1E 104K-T
C221 4030011600 S.CER C1608 JB 1E 104K-T
C222 4030006860 S.CER C1608 JB 1H 102K-T
C223 4030006860 S.CER C1608 JB 1H 102K-T
C224 4030006860 S.CER C1608 JB 1H 102K-T
C225 4030006860 S.CER C1608 JB 1H 102K-T
C226 4030008920 S.CER C1608 JB 1H 473K-T
C227 4030008920 S.CER C1608 JB 1H 473K-T
C228 4030006860 S.CER C1608 JB 1H 102K-T
C229 4030006860 S.CER C1608 JB 1H 102K-T
C230 4030011600 S.CER C1608 JB 1E 104K-T
C231 4030011600 S.CER C1608 JB 1E 104K-T
C232 4030011600 S.CER C1608 JB 1E 104K-T
C233 4510008490 S.ELE EEE1CS100SR
C234 4030011600 S.CER C1608 JB 1E 104K-T
C235 4030006860 S.CER C1608 JB 1H 102K-T
C236 4510003860 ELE 50 ME 3R3 SWB
C239 4030006860 S.CER C1608 JB 1H 102K-T
C240 4030011600 S.CER C1608 JB 1E 104K-T
C241 4030011600 S.CER C1608 JB 1E 104K-T
C242 4030006860 S.CER C1608 JB 1H 102K-T
C245 4510008540 S.ELE EEE1CA100SR
C246 4030011600 S.CER C1608 JB 1E 104K-T
C247 4030011600 S.CER C1608 JB 1E 104K-T
C248 4510008820 S.ELE EEE1CA330WR
C249 4510003790 ELE 16 ME 10 SWB
C260 4030006880 S.CER C1608 JB 1H 472K-T
C261 4030017810 S.CER C1608 CH 1H 102J-T
C262 4030017810 S.CER C1608 CH 1H 102J-T
C263 4030017810 S.CER C1608 CH 1H 102J-T
C271 4030008650 S.CER C1608 JB 1H 332K-T
RL2 6330001320 REL AHY103
RL3 6330001320 REL AHY103
CP1 6910009670 S.CHE HK3-S-T
J2 6510022091 S.CON 52610-1271(1290)
J3 6510003461 CON B10B-EH-S(LF)(SN)
J4 6510003481 CON B12B-EH-S(LF)(SN)
J6 6510003411 CON B05B-EH-S(LF)(SN)
J8 6510003491 CON B13B-EH-S(LF)(SN)
J9 6510003411 CON B05B-EH-S(LF)(SN)
J10 6510003451 CON B09B-EH-S(LF)(SN)
J14 6510017650 CON 52045-1045
J17 6510003391 CON B03B-EH-S(LF)(SN)
J18 6510003411 CON B05B-EH-S(LF)(SN)
J19 6510003421 CON B06B-EH-S(LF)(SN)
J20 6510003431 CON B07B-EH-S(LF)(SN)
J21 6510003441 CON B08B-EH-S(LF)(SN)
J22 6510003391 CON B03B-EH-S(LF)(SN)
J23 6910005801 CON IMSA-9210B-1-03ZA043-PT1
P1 6910007600 CON IMSA-9215H-T
S3 2260002220 SWI S-1010A
S4 2260002220 SWI S-1010A
S5 2220000530 S.SWI SW-161 (SSSS822-A-0)
DESCRIPTION
[JACK-1 UNIT]
REF ORDER
NO. NO.
L1 6200003261 S.COI NLV32T-101J
L2 6200003261 S.COI NLV32T-101J
L3 6200003261 S.COI NLV32T-101J
L4 6200003261 S.COI NLV32T-101J
L5 6200003950 S.COI HF50ACC 322513-T
L6 6200003950 S.COI HF50ACC 322513-T
R1 7310003820 TRI EVN-D2AA03 B14
R2 7310003820 TRI EVN-D2AA03 B14
C1 4030006880 S.CER C1608 JB 1H 472K-T
C2 4030006880 S.CER C1608 JB 1H 472K-T
C3 4030006880 S.CER C1608 JB 1H 472K-T
C4 4030006880 S.CER C1608 JB 1H 472K-T
C5 4030006880 S.CER C1608 JB 1H 472K-T
C6 4030006880 S.CER C1608 JB 1H 472K-T
J1 6510024541 CON TCS5073-2741577
J3 6450001130 CON JPJ2042-01-110
J4 6450000140 CON HSJ0807-01-010
J5 6510024541 CON TCS5073-2741577
J7 6450001130 CON JPJ2042-01-110
J8 6450000140 CON HSJ0807-01-010
J9 6510022091 S.CON 52610-1271(1290)
J10 6510003461 CON B10B-EH-S(LF)(SN)
J11 6510003461 CON B10B-EH-S(LF)(SN)
J12 6510018961 S.CON B2B-PH-SM4-TB(LF)(SN)
S1 2220000570 SWI HSW1196-01-020 0
[ANT-SW UNIT]
REF ORDER
NO. NO.
WS1 8600035743 EX1900 P01*J01AN-SW-3
D1 1710000051 DIO 1SS53-AZ
D2 1710000051 DIO 1SS53-AZ
D3 1710000051 DIO 1SS53-AZ
D4 1710000051 DIO 1SS53-AZ
L1 6180000900 COI LAL 03NA 101K
L2 6180000900 COI LAL 03NA 101K
L3 6180000900 COI LAL 03NA 101K
L4 6180000900 COI LAL 03NA 101K
R1 7540000190 ABS SRYG-2000L
C1 4010006900 CER HE80SJ YB 472K 50V 1
C2 4010006900 CER HE80SJ YB 472K 50V 1
C3 4010006900 CER HE80SJ YB 472K 50V 1
C4 4010006900 CER HE80SJ YB 472K 50V 1
C6 4010006900 CER HE80SJ YB 472K 50V 1
C7 4010006900 CER HE80SJ YB 472K 50V 1
C8 4010006900 CER HE80SJ YB 472K 50V 1
C9 4010006900 CER HE80SJ YB 472K 50V 1
C11 4010008640 CER DEA1X3A100JC1B
C12 4010008640 CER DEA1X3A100JC1B
C13 4010008640 CER DEA1X3A100JC1B
RL1 6330001460 REL FTR-F1CA012V
RL2 6330001460 REL FTR-F1CA012V
RL3 6330001460 REL FTR-F1CA012V
RL4 6330001460 REL FTR-F1CA012V
EP1 6910011340 TER OT-010 M3
EP2 6910011340 TER OT-010 M3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
9
DESCRIPTION
DESCRIPTION
S.=Surface mount
