Icom IC-PW1 Service Manual Addendum page 133

[DET BOARD]
REF ORDER
NO. NO.
IC1 1110001850 IC
IC2 1110001860 IC
IC3 1120002250 S.IC
IC4 1120002240 S.IC
IC5 1180000320 IC
Q1 1560000870 S.FET
D3 1790000620 S.DIODE
D4 1790000620 S.DIODE
D5 1790000620 S.DIODE
D6 1790000620 S.DIODE
D7 1750000270 S.DIODE
D8 1750000270 S.DIODE
D11 1710000980 DIODE
D12 1710000980 DIODE
D13 1790001530 DIODE
D14 1790001530 DIODE
L1 6180000960 COIL
L3 6140002660 COIL
L4 6180000960 COIL
L5 6140002660 COIL
L8 6180000990 COIL
L9 6200003260 S.COIL
L10 6200003260 S.COIL
L11 6140002220 COIL
L12 6180000990 COIL
R1 7030003400 S.RESISTOR
R2 7030000080 S.RESISTOR
R3 7030003400 S.RESISTOR
R4 7030008320 S.RESISTOR
R5 7030003400 S.RESISTOR
R6 7030000080 S.RESISTOR
R7 7030003400 S.RESISTOR
R8 7030003280 S.RESISTOR
R9 7030003480 S.RESISTOR
R11 7030003280 S.RESISTOR
R12 7030003480 S.RESISTOR
R13 7030003560 S.RESISTOR
R14 7030009330 RESISTOR
R15 7030003560 S.RESISTOR
R16 7030003800 S.RESISTOR
R17 7030003560 S.RESISTOR
R18 7030003560 S.RESISTOR
R19 7030003450 S.RESISTOR
R20 7030003520 S.RESISTOR
R21 7030009330 RESISTOR
C1 4010005570 CERAMIC
C2 4010005370 CERAMIC
C3 4010005370 CERAMIC
C4 4030006880 S.CERAMIC
C5 4030006880 S.CERAMIC
C6 4510005600 S.ELECTROLYTIC ECEV1CS100SR
C7 4030011600 S.CERAMIC
C8 4030006880 S.CERAMIC
C9 4010005740 CERAMIC
C10 4030011600 S.CERAMIC
C11 4030011600 S.CERAMIC
C12 4030006880 S.CERAMIC
C13 4030006880 S.CERAMIC
C14 4030006880 S.CERAMIC
C15 4010005540 CERAMIC
C16 4010005880 CERAMIC
C17 4010005850 CERAMIC
C18 4030006860 S.CERAMIC
C19 4010005780 CERAMIC
C20 4030006880 S.CERAMIC
C21 4030006860 S.CERAMIC
C22 4030006880 S.CERAMIC
C23 4030006860 S.CERAMIC
C24 4030006880 S.CERAMIC
C25 4030006880 S.CERAMIC
C26 4030006880 S.CERAMIC
C27 4030006880 S.CERAMIC
DESCRIPTION
MC10116 L
MC10125 L
TC74ACT32F
TC74AC112F
NJM79L05A
2SK515-T1B (X33)
MA77 (TX)
MA77 (TX)
MA77 (TX)
MA77 (TX)
1SS301 (TE85R)
1SS301 (TE85R)
MBD701
MBD701
1SS286
1SS286
LAL 03NA 102K
LR-299
LAL 03NA 102K
LR-299
LAL 04NA 101K
NL 322522T-101J
NL 322522T-101J
LR-270 (TR6X3X2 3A9)
LAL 04NA 101K
ERJ3GEYJ 471 V (470 Ω)
MCR10EZHJ 3.3 Ω (3R3)
ERJ3GEYJ 471 V (470 Ω)
ERJ1WYJ6R8U (6.8 Ω)
ERJ3GEYJ 471 V (470 Ω)
MCR10EZHJ 3.3 Ω (3R3)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ1WYJ300U
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ1WYJ300U
HM60SJ SL 060D 500V
HM11SJ SL 331J 500V
HM11SJ SL 331J 500V
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
HM60SJ SL 560J 500V
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
HM60SJ SL 030C 500V
HM95SJ SL 271J 500V
HM95SJ SL 181J 500V
C1608 JB 1H 102K-T-A
HM60SJ SL 101J 500V
C1608 JB 1H 472K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
[DET BOARD]
REF ORDER
NO. NO.
C29 4510005600 S.ELECTROLYTIC ECEV1CS100SR
C30 4030011600 S.CERAMIC
C33 4010005110 CERAMIC
C34 4030006880 S.CERAMIC
C35 4010005850 CERAMIC
C36 4030006900 S.CERAMIC
C37 4030011600 S.CERAMIC
C38 4030011600 S.CERAMIC
C39 4030006900 S.CERAMIC
C40 4030011600 S.CERAMIC
C41 4030011600 S.CERAMIC
C42 4010005110 CERAMIC
C43 4010005050 CERAMIC
C44 4510005600 S.ELECTROLYTIC ECEV1CS100SR
C45 4030006880 S.CERAMIC
WS1 8970022630 OTHER
WS2 8600035821 OTHER
EP5 6910011330 TERMINAL
EP6 6910011330 TERMINAL
EP7 6910011330 TERMINAL
EP8 6910011330 TERMINAL
EP9 0910048738 PCB
[CONNECT BOARD]
REF ORDER
NO. NO.
C1 4030010210 S.CERAMIC
C2 4030010210 S.CERAMIC
C3 4030010210 S.CERAMIC
C4 4030010210 S.CERAMIC
C5 4030010210 S.CERAMIC
C6 4030010210 S.CERAMIC
C7 4030010210 S.CERAMIC
C8 4030010210 S.CERAMIC
J1 6510017650 CONNECTOR
J2 6510003410 CONNECTOR
J3 6510003410 CONNECTOR
EP1 0910048814 PCB
[L-NET BOARD]
REF ORDER
NO. NO.
D1 1710000050 DIODE
D2 1710000050 DIODE
L1 6180000990 COIL
L2 6180000990 COIL
L3 6110003360 COIL
L4 6110003500 COIL
L5 6110003490 COIL
C1 4040000150 BARRIERLAYR UAT 05X 472K
C2 4040000150 BARRIERLAYR UAT 05X 472K
C3 4040000260 BARRIERLAYR UZE 08X 104M
C4 4040000260 BARRIERLAYR UZE 08X 104M
RL1 6330000570 RELAY
RL2 6330000570 RELAY
5 - 10
DESCRIPTION
C1608 JB 1C 104KT-N
DE0910 SL 220J 6KV
C1608 JB 1H 472K-T-A
HM95SJ SL 181J 500V
C1608 JB 1E 103K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
DE0910 SL 220J 6KV
DE0707 SL 270J 3KV
C1608 JB 1H 472K-T-A
EX1900 TEFLON COAXIAL TUBE (2)/DE
EX1900 P01*J01DE-1
OT-009 M3
OT-009 M3
OT-009 M3
OT-009 M3
B 4887H
DESCRIPTION
C3216 JB 1C 105M-T-A
C3216 JB 1C 105M-T-A
C3216 JB 1C 105M-T-A
C3216 JB 1C 105M-T-A
C3216 JB 1C 105M-T-A
C3216 JB 1C 105M-T-A
C3216 JB 1C 105M-T-A
C3216 JB 1C 105M-T-A
52045-1045
B05B-EH-S
B05B-EH-S
B 4941D
DESCRIPTION
1SS53
1SS53
LAL 04NA 101K
LAL 04NA 101K
LA-530
LA-543
LA-542
AR-39251
AR-39251
S.=Surface mount
