8
RS232
Remote Control Protocol
The unit supports two different communication types:
•
Remote Front Panel Button Emulation
•
Remote Configuration and Status

8.1 Front Panel Button Emulation

Data Structure
Byte 1: 0xFF
Byte 2: 0x55
Byte 3: Front Panel Button Code
Description
Byte 1 and 2 are header bytes.
Byte 3 contains the code for a specific front
panel button.
The different buttons and their corresponding
codes are as follows.
No Button Pressed
Record
Play
Stop
Alarm
Freeze
Zoom
Sequence
16 Way Multiscreen
Camera 1
Camera 2
Camera 3
Camera 4
Camera 5
Camera 6
Camera 7
Camera 8
Camera 9
Camera 10
Camera 11
Camera 12
Camera 13
Camera 14
Camera 15
Camera 16
Reserved
Menu
Enter
0150-0198B
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25 - 40
41
42
59
Reserved
Macro
Reserved
Monitor B
Reserved
Left Arrow
Right Arrow
Up Arrow
Down Arrow
Reserved
Alarm and Sequence
Alarm and Camera 1
Alarm and Camera 2
Alarm and Camera 3
Alarm and Camera 4
Alarm and Camera 5
Alarm and Camera 6
Alarm and Camera 7
Alarm and Camera 8
Alarm and Camera 9
Alarm and Camera 10
Alarm and Camera 11
Alarm and Camera 12
Alarm and Camera 13
Alarm and Camera 14
Alarm and Camera 15
Alarm and Camera 16
Reserved
Search
Frame Reverse
Frame Forward
Play Reverse
Stop
Play Forward
Monitor A
2 Way Multiscreen
4 Way Multiscreen
6 Way Multiscreen
7 Way Multiscreen
9 Way Multiscreen
10 Way Multiscreen
13 Way Multiscreen
Calibur DVMR
43
44
45-49
50
51-63
64
65
66
67
68-74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92-110
111
112
113
114
115
116
130
131
132
133
134
135
136
137
e
Triplex eZ
