Owners &
Installation
LISTINGS AND CODE APPROVALS
These gas appliances have been tested in
accordance with AS4553-2000, NZS 5262
and have been certifi ed by the Australian Gas
Association for installation and operation as
described in these Installation and Operating
Instructions.
Your unit should be serviced annually by
an authorised service person.
Zero Clearance Room Sealed
Gas Fireplace
STYLE
See Thru
P121-NG
Left Corner
P121LC-NG
Right Corner P121RC-NG
Pier
P131-NG
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper installation, adjustment, altera-
tion, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional in-
formation consult an authorized installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other fl am-
mable vapours and liquids in the vicinity of
this or any other appliance.
Installation and service must be performed
by an authorized installer, service agency or
the gas supplier.
918-536a
MODEL
P121-LPG
P121LC-LPG
P121RC-LPG
P131-LPG
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appli-
ance
Do not touch any electri-
cal switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the fi re
department.
09/11/12
Advertisement
Table of Contents
Related Manuals for Regency Fireplace Products P121-NG
Summary of Contents for Regency Fireplace Products P121-NG
- Page 1 Owners & Installation Zero Clearance Room Sealed Gas Fireplace STYLE MODEL See Thru P121-NG P121-LPG Left Corner P121LC-NG P121LC-LPG Right Corner P121RC-NG P121RC-LPG Pier P131-NG P131-LPG PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, altera-...
- Page 2 To the New Owner: Congratulations! ® You are the owner of a state-of-the-art Gas Fireplace by REGENCY . The P121/P121LC/P121RC/ P131 is a hand crafted appliance and has been designed to provide you with all the warmth and charm of a wood fi replace at the fl ick of a switch. The model P121/P121LC/P121RC/P131 has been approved by the Australian Gas Association for both safety and effi...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Safety Label Operating Instructions Safety Label..............4 Operating Instructions ..........30 Lighting Procedure ........... 30 Installation Shutdown Procedure ..........30 First Fire ..............30 Important Message ............. 5 Normal Operating Sounds of Before You Start ............5 Gas Appliances .......... -
Page 4: Safety Label
Regency Gas Fireplace Distributed by: Model Western Australia: Gas Type Air Group Australia 28-30 Division St P121-NG P121-LPG P131-NG P131-LPG Model Welshpool, WA 6106 41mj. 38mj. 41mj. -
Page 5: Installation
INSTALLATION IMPORTANT: 14) The appliance area must be kept clear and YOUNG CHILDREN SHOULD BE free of combustible materials, (gases and CAREFULLY SUPERVISED WHEN SAVE THESE other fl ammable vapours and liquids). THEY ARE IN THE SAME ROOM AS INSTRUCTIONS Emissions from burning wood or gas could THE APPLIANCE. -
Page 6: Specifi Cations
INSTALLATION SPECIFICATIONS P121 - See Thru Note: These units are non-load bearing. P131 - Pier ® Regency P121/P121LC/P121RC/P131 Zero Clearance Room Sealed Gas Fireplace... - Page 7 INSTALLATION P121LC - Left Corner Unit Note: These units are non-load bearing. P121RC - Right Corner Unit ® Regency P121/P121LC/P121RC/P131 Zero Clearance Room Sealed Gas Fireplace...
-
Page 8: Locating Your Gas Fireplace
INSTALLATION LOCATING YOUR GAS FIREPLACE A) P121 - See Thru 1) When selecting a location for your stove, ensure that the clearances are met as outlined on page 9. 2) Provide adequate clearances for servic- ing. 3) The appliance must be installed on a fl at, solid, continuous surface (e.g. -
Page 9: Clearances
INSTALLATION CLEARANCES The clearances listed below are Minimum distances unless otherwise stated (refer to diagrams on page 8): Clearance to Combustibles from: Back 0" (0mm) Side 0" (0mm) WARNING: Floor 0" (0mm) Fire hazard is an extreme risk if these clearances (air space) CAUTION REQUIREMENTS: The top, back and sides of the fi... -
Page 10: Framing And Finishing
INSTALLATION FRAMING AND FINISHING 1) For ease of installation, frame your fi replace after it is positioned and Framing Dimensions the fl ue system is installed. Remember to install the top standoffs. See page 11 for assembly. Use 2x4's and frame to local building P121 (See Thru) P131 (Pier) P121LC / P121RC... -
Page 11: Facing And Finishing Requirements
INSTALLATION FACING & FINISHING REQUIREMENTS This fi replace is supplied with a 3" metal extension trim above the fi replace. The extension trim may be replaced if the framing is faced with a non- combustible material placed fl ush with the front and side face of the unit and extending from the top of the unit. (ie. tile, slate, etc.) FLUEING UNIT ASSEMBLY PRIOR TO... -
Page 12: Exterior Flue Termination Locations
INSTALLATION EXTERIOR FLUE TERMINATION LOCATIONS Minimum clearances required for balanced fl ue terminals or the fl ue terminals of outdoor appliances according to AG 5601-2004 (AGA gas installation code) or NZS 5261 (New Zealand) Minimum Clearance (mm) Below eaves, balconies or other projections: - Appliances up to 50 MJ/h input - Appliances over 50 MJ/h input From the ground or above a balcony... -
Page 13: Flueing: Direct Vent System (Flex)
INSTALLATION FLUEING ARRANGEMENT - HORIZONTAL TERMINATIONS ® Regency Direct Vent System (Flex) Horizontal Terminations Only These fl ueing systems, in combination with the P121/P121LC/P121RC/P131 Direct Vent Gas Fireplace, have been tested and listed as a direct fl ue heater system by Warnock Hersey. The location of the termination cap must conform to the requirements in the Vent Terminal Locations diagram on page 12. -
Page 14: Flueing: Simpson Dura-Vent Direct Vent Gs
INSTALLATION SIMPSON DURA-VENT FLUEING Horizontal or Vertical Terminations The Simpson Dura-Vent Direct Vent System offers a complete line of component parts for installation of both horizontal and vertical installations. Many items are offered in decorative black, as well as galvanized fi nish. We recommend using the galvanized fi nish for installation with the P121/ P121LC/P121RC/P131. -
Page 15: Flueing Arrangements Horizontal Terminations
INSTALLATION FLUEING ARRANGEMENTS - HORIZONTAL TERMINATIONS SIMPSON DURA-VENT DIRECT VENT GS SYSTEM (LPG & NG) The diagram below shows examples of horizontal termination arrangements using one, two, or three 90 elbows (two 45 elbows equal one 90 elbow). Note: 1) A maximum of three 90 elbows are permitted. - Page 16 INSTALLATION Horizontal Flueing with Three (3) 90 Elbows Horizontal Flueing with Two (2) 90 Elbows Option H + H1 + H2 Option H + H1 2' (610mm) Min. 1' (305mm) Max. 3' (914mm) Max. 1' (305mm) Minimum 2' (610mm) Maximum 2' (610mm) Minimum 5' (1.5m) Maximum 3' (914mm) Min.
-
Page 17: Vertical Terminations
INSTALLATION FLUEING ARRANGEMENTS - VERTICAL TERMINATIONS SIMPSON DURA-VENT DIRECT VENT GS SYSTEM (LPG & NG) • Flue must be supported at offsets Maintain clearances to combustibles as listed on page 9. • Firestops are required at each fl oor level and whenever passing through a wall. •... - Page 18 INSTALLATION Vertical Flueing with Two (2) 90 Elbows Vertical Flueing with Two (2) 90 Elbows Option Option H + H1 1' (305mm) Minimum 4' (1.22m) Maximum 1' (305mm) Minimum 2' (610mm) Maximum 2' (610mm) Minimum 6' (1.86m) Maximum 2' (610mm) Minimum 4' (1.22m) Maximum 3' (914mm) Minimum 9' (2.7m) Maximum...
-
Page 19: Flueing - Dura-Vent Horizontal Installations
INSTALLATION Vertical Flueing with Three (3) 90 Elbows Option V + V1 H + H1 2' (610mm) Minimum 3' (914mm) Maximum 3' (914mm) Minimum 6' (1.86m) Maximum 4' (1.22m) Minimum 9' (2.7m) Maximum 5' (1.5m) Minimum 12' (3.6m) Maximum With the above options, maximum total pipe length if 37 feet with mini- mum of 5 feet total vertical and maximum 12 feet total horizontal. -
Page 20: Flueing - Dura-Vent Vertical Termination
INSTALLATION 4) Assemble the desired lengths of pipe and VERTICAL elbows. Ensure that all pipes and elbow con- TERMINATION nections are in the fully twist-locked position and sealed. 1) Maintain the 1-1/4" clearances 5) Cut a hole in the roof centered on the small (air spaces) to combustibles when drilled hole placed in the roof in Step 2. -
Page 21: System (Flex)
INSTALLATION steep roof pitches, the vertical height must 5) Slip the assembled liner and termination be increased. A poor draft, or down drafting assembly through the thimble making sure can result from high wind conditions near the termination cap faces up (there are big trees or adjoining roof lines, in these Note: To make the markings on the cap that show which way... -
Page 22: Converion To Lpg
INSTALLATION Conversion Kit #360-968 from NG to LPG THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! 7) Unscrew the pilot orifi ce with the allen key 4) Remove the burner assembly by remov- Each LPG Conversion Kit and replace with the LPG pilot orifi... - Page 23 INSTALLATION 14) Check that the WARNING! screw is clean and if necessary remove dirt. Also check that the pilot and main burner injectors are 15) Flip the screw (Fig. 3). appropriate for the gas type. 19) Reverse steps 4) to 1). Fig.3 20) Attach the label "This unit has been converted to LPG"...
-
Page 24: System Data
INSTALLATION Important: Always check for gas leaks with a Note: To properly check gas pressure, both P121/P121LC/P121RC/P131-NG soap and water solution or gas leak detector. inlet and manifold pressures should System Data Do not use open fl ame for leak testing. be checked using the valve pressure ports on the valve. -
Page 25: Log Set Installation
INSTALLATION LOG INSTALLATION 1) Carefully remove the logs from the box and unwrap them. The logs are fragile, handle with care - do not force into position. Read the instructions below carefully and refer to the diagrams. If 2) Place Log 326 on the front right side of the burner. Ensure that the logs are broken do not use the unit until they are replaced. - Page 26 INSTALLATION Repeat step 3 on the opposite side of the burner. Repeat step 5 on the opposite side of the burner. 4) Embers should be placed in front of Log 326 and Log 327 and also down the middle between the logs as shown in the image below. 6) Place Log 328 on the middle right side of the burner.
-
Page 27: Glass Door Removal
INSTALLATION GLASS DOOR LOUVERS & GRILLS FINISHING TRIM REMOVAL 1) Attach the screws provided to the top left 1) Slide the Side Finishing Trim up into the and right corners. slot in the top fl ange of the fi replace. Push 1) Remove the 8 screws that secure the glass tight against the magnet at the base of the door. -
Page 28: Remote Control (Optional)
INSTALLATION Option 1: Option 3: Option 2: REMOTE CONTROL WALL THERMOSTAT WALL SWITCH A wall thermostat may be installed if desired, 1) Run the supplied 4.5m of wire through the ® Use the Regency Remote Control Kit approved connect the wires as per the wiring diagram. back gas inlet opening. -
Page 29: Wiring Diagram
INSTALLATION WIRING DIAGRAM Caution: Ensure that the wires do No electrical power supply is required for the (Do not cut the ground terminal off under gas control to operate. any circumstances.) not touch any hot surfaces and are away from sharp edges. ON-OFF SWITCH Lockwasher (910-138) BLACK... -
Page 30: Operating Instructions
OPERATING INSTRUCTIONS SHUTDOWN OPERATING NORMAL OPERATING INSTRUCTIONS PROCEDURE SOUNDS OF GAS APPLIANCES 1) Read and understand these instructions 1) Turn OFF the fl ame switch. before operating this appliance. It is possible that you will hear some sounds 2) Push in gas control knob slightly and turn to 2) Check to see that all wiring is correct and from your gas appliance. -
Page 31: Lighting Plate Instructions
OPERATING INSTRUCTIONS MAINTENANCE COPY OF THE LIGHTING PLATE INSTRUCTIONS INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING 1) Always turn off the gas valve before cleaning. For relighting, refer to lighting instructions. Keep the burner and control compartment This appliance must be installed in accordance with local codes, if any; if not, follow the current CAN1-B149/ANSI Z 223.1 (Australia: AS5601-2004, New Zealand: NZS 5261) clean by brushing and vacuuming at least once a year. -
Page 32: Log Replacement
MAINTENANCE 2) Remove the Cap, and shine a fl ashlight REMOVING VALVE GLASS GASKET down the Flue. Remove any bird nests, or other foreign material. 1) Shut off the gas supply. If the glass gasket requires replacement use a tadpole glass gasket (Part # 936-155). 3) Check for evidences of excessive condensa- 2) Remove the louvers and trim kit. -
Page 33: Installing Valve
MAINTENANCE 8) Remove the Side Base Brick Panels and 13) Undo the pilot tube from the valve with a INSTALLING VALVE fi nally the Long Base Brick Panels. 7/16" spanner. 1) Attach the valve to the valve bracket with 14) Undo the quick drop out thermocouple nut the 6 (m5x8 metric) screws provided. -
Page 34: Parts List
PARTS LIST P121 (SEE THRU) MAIN ASSEMBLY Part # Description Part # Description 360-528 Door Assy Front - Tempered 151) 904-258 Magnet 360-538 Door Assy Front - Ceramic (Optional) 168) 360-068 Door Cover Assembly - Side 360-529 Door Assy Side - Tempered 171) 360-920 Louver Front - Black (set) 360-539... - Page 35 PARTS LIST P131 (PIER) MAIN ASSEMBLY Part # Description Part # Description Part # Description 146) 360-035 Finishing Trim 360-528 Door Assy Front - Tempered 204) 360-940 Dec. Grill Front - Black (set) 360-946 Door Assy Front - Ceramic 206) 910-172 Fan Axial 240V (Optional) 149) 360-122...
- Page 36 PARTS LIST P121RC (RIGHT CORNER) MAIN ASSEMBLY Part # Description Part # Description Part # Description 360-528 Door Assy Front - Tempered 224) 360-942 Dec. Grill Side - Black (set) 146) 360-035 Finishing Trim - Left Side 360-538 Door Assy Front - Ceramic (Optional) 225) 948-216 Regency...
- Page 37 PARTS LIST P121LC (LEFT CORNER) MAIN ASSEMBLY Part # Description Part # Description Part # Description 204) 360-940 Dec. Grill Front - Black (set) 360-528 Door Assy Front - Tempered 138) 360-069 Heat Shield - Front 206) 910-172 Fan Axial 240V 360-538 Door Assy Front - Ceramic 224) 360-942...
- Page 38 PARTS LIST P121/P121LC/P121RC/P131 BURNER ASSEMBLY & LOG SET Part # Description 360-930 Log Set 41) * Front Right Log 42) * Front Left Log 43) * Middle Left Log 44) * Middle Right Log 360-574/P Valve Assembly 56) 360-378/P Valve S.I.T. - NG 57) 360-090 Gasket - Valve Tray 58) *...
-
Page 39: Warranty
Regency Fireplace Products, shall in no event be liable for any special, indirect consequential damages of any nature whatsoever which are in excess of the original purchase price of the product. Any alteration to the unit which causes sooting or carboning that results in damage to the exterior facia is not the responsibility of Regency. - Page 40 Printed in Canada © Copyright 2012, FPI Fireplace Products International Ltd. All rights reserved.
