Pro Series
Wood
Fireplace
Insert
Owners & Installation Manual
French Manual: http://ow.ly/ZudZW
Manuel en Français: http://ow.ly/ZudZW
www.regency-fire.com
MODEL:
CI2700/HI500
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Report #0219WN017S
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
04.09.19
920-047
Advertisement
Table of Contents
Related Manuals for Regency Fireplace Products CI2700
Summary of Contents for Regency Fireplace Products CI2700
- Page 1 Owners & Installation Manual French Manual: http://ow.ly/ZudZW Manuel en Français: http://ow.ly/ZudZW www.regency-fire.com MODEL: CI2700/HI500 Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. Report #0219WN017S FPI FIREPLACE PRODUCTS INTERNATIONAL LTD.
- Page 2 The following statements are required by the Environmental Protection Agency: “This manual describes the installation and operation of the Regency CI2700 and HI500 catalytic equipped wood heater. This heater meets the 2020 U.S. Environmental Protection Agency’s crib wood emission limits for wood heaters. Under specific test conditions this heater has been shown to deliver heat at rates ranging from 8,292 BTU/hr.
-
Page 3: Table Of Contents
CAUTION: To avoid burns or wood splinters, when opening/closing the fuel door or adding wood to the fire, You should always wear appropriate protective gloves to protect your hands from the heat being emitted from this fireplace. CI2700/HI500 | wood insert |... -
Page 4: Copy Of Safety Decal
U.S. ENVIRONMENTAL PROTECTION AGENCY CERTIFIED TO COMPLY WITH 2020 PARTICULATE EMISSION STANDARDS USING CORD WOOD.” TESTED TO ASTM E3053. MODEL REGENCY CI2700/HI500 – 1.3G /HR. THIS WOOD HEATER NEEDS PERIODIC INSPECTION AND REPAIR FOR PROPER OPERATION. CONSULT THE OWNER'S MANUAL FOR FURTHER INFORMATION. IT IS AGAINST FEDERAL REGULATIONS TO OPERATE THIS WOOD HEATER IN A MANNER INCONSISTENT WITH THE OPERATING INSTRUCTIONS IN THE OWNER'S MANUAL. -
Page 5: Dimensions
DIMENSIONS - CONTEMPORARY FACEPLATE 28-7/8" (733mm) 18-1/2" (469mm) 40" (1016mm) 13-3/8" (340mm) 23-3/16" (589mm) 27-3/4" (750mm) ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS. CI2700/HI500 | wood insert |... -
Page 6: Dimensions - Cast Faceplate And Offset Flue Collar
DIMENSIONS - CAST FACEPLATE AND OFFSET FLUE COLLAR " " " " 1045 | CI2700/HI500 | wood insert... -
Page 7: Dimensions - Low Profile Faceplate
DIMENSIONS - LOW PROFILE FACEPLATE 40" [1016mm] 29" [737mm] DIMENSIONS - CAST FACEPLATE 41-3/8" 1051mm Standard Cast Faceplate shown above Oversized Cast Faceplate Dimensions: 44" W x 31" H CI2700/HI500 | wood insert |... -
Page 8: Dimensions - Standard Backing Plate
DIMENSIONS - STANDARD BACKING PLATE DIMENSIONS - OVERSIZED BACKING PLATE | CI2700/HI500 | wood insert... -
Page 9: Installation
ANCE OR AN AIR DISTRIBUTION DUCT. removed. b. The chimney damper may be removed to 8. DO NOT INSTALL IN A SLEEPING ROOM. install the chimney liner. CI2700/HI500 | wood insert |... -
Page 10: Masonry And Factory Built Fireplace Clearances
(hr)(ft (m)(K) (hr)(ft)( R = 1/k x T = 1/0.84 x .75 = 0.893. specified R of 0.893. Since proposed system R is greater than required, the system is Thermal Resistance: acceptable. )(hr)( )(K) 10 | CI2700/HI500 | wood insert... -
Page 11: Installing Your Insert
Remove Fork 4. From inside the firebox - remove 7/16" bolt at back of firebox to remove the flue collar. B- Combustor Flame Shield - loosen 2 x 7/16" bolts to remove. E- Bottom Shield CI2700/HI500 | wood insert |... - Page 12 10. Reinstall "Fork" (removed in Step 4) on the bypass plate. Ensure the letter "F" stamped into the Fork is facing towards the front of the E - Upper Shield - orientation for reinstall 12 | CI2700/HI500 | wood insert...
-
Page 13: Installation Into A Masonry Fireplace
Important: The catalytic monitor probe which is supplied with this appliance must be installed prior to sliding the unit into final position in the masonry or factory built fireplace. See catalytic monitor instructions in this manual for details. CI2700/HI500 | wood insert |... -
Page 14: Digital Catalytic Combustor Monitor
DIGITAL CATALYTIC COMBUSTOR MONITOR 3. Reinstall the plate removed in Step 1 and insert the temperature probe The CI2700/HI500 is equipped with a provision to accept a catalytic tempera- ture monitoring device. Please follow instructions below for the installation of through the plate and into the hole created by removing the bolt in Step 2. -
Page 15: Levelling Bolts
Remove Bricks 2. Remove the three side bricks on each side then remove the corner bottom/side cut brick to gain access to the rear leveling bolts. You can adjust using a 9/16" wrench or socket. CI2700/HI500 | wood insert |... -
Page 16: Optional Cast Grill Installation
Firebrick is included to extend the life of your insert and radiate heat more evenly. Check to see that all firebricks are in their correct positions and have not become misaligned during shipping. 16 | CI2700/HI500 | wood insert 919-400... -
Page 17: Optional Backing Plate Installation
fl ange on unit and secure with 2 screws from the underside as shown below. Proceed with Faceplate install. Backing Plate Screws Diagram 4 Completed backing plate shown with Optional Hampton faceplate CI2700/HI500 | wood insert | 01/28/15 919-324... -
Page 18: Contemporary Faceplate Installation
3. Install the left and right of the fascia panels using four 7/16’’ bolts. Back view of Top Fascia Panel lining up with the brackets installed in Step 1 Fascia side panels installed with Bolts 919-321 04/15/14 18 | CI2700/HI500 | wood insert... - Page 19 7. With door in closed position, take the bottom fascia and line up the wheels and rails with the rails on the unit. Once lined up lift up and into the rail system and slide into position. Rail System 919-321 04/15/14 CI2700/HI500 | wood insert |...
-
Page 20: Low Profile Faceplate Installation
Right Bracket 3. Remove the ring on the bypass rod by turning counter clockwise - pull bypass rod forward to the open position. Install fan switch assembly Remove ring from the bypass rod 919-322a 03/24/14 20 | CI2700/HI500 | wood insert... - Page 21 Push the faceplate towards the unit, ensuring the bolts in Step 2 slide into the brackets installed in Step 1. 9. Tighten the 7/16’’ bolts on the back of the Flat Faceplate 10. Re-install bypass ring and door. Final Install CI2700/HI500 | wood insert | 919-322a 04/15/14...
-
Page 22: Cast Faceplate Installation
If screw holes already present on unit, line up defl ector with corre- sponding screw holes and secure with 2 screws on locations shown below. Cast Panel Shown Fan defl ector screw locations 22 | CI2700/HI500 | wood insert 919-323b 06/25/14... - Page 23 Lift the fascia panel up slightly - push back to engage the brackets installed on Note: If installing optional cast grill - follow installation instructions in this Step 1. manual. Self adhesive gasket CI2700/HI500 | wood insert | 919-323b 06/25/14...
-
Page 24: Oversize Cast Faceplate Installation
2 screws on locations shown below. 3. Identify left and right side panels Left Panel/ Back Side Right Panel/ Back Side Fan defl ector screw locations 919-411 09/15/14 24 | CI2700/HI500 | wood insert... - Page 25 Back view of Top Fascia Panel lining up with the brackets on Side Panels 8. Re-install bypass rod and ring Gasket Completed Optional Hampton Rail System Oversize Cast Faceplate Note: If installing optional cast grill - follow installation instructions in the manual. CI2700/HI500 | wood insert | 919-411 09/15/14...
-
Page 26: Optional Fan/Blower Installation
Cast Faceplate to lower fas- and left sides. cia before sliding faceplate into position. Fan switch assembly NOTE: Avoid disconnecting wires from switch during installation. 26 | CI2700/HI500 | wood insert 919-320b 05.02.18... - Page 27 Label all wires prior directly into a properly grounded to disconnection when servicing three-prong receptacle. Do not controls. Wiring errors can cause cut or remove the grounding improper and dangerous operation. prong from this plug. 919-320b 05.02.18 CI2700/HI500 | wood insert |...
-
Page 28: Removable Door Handle
REMOVABLE DOOR HANDLE The CI2700/HI500 has a removable door handle that can be stored when not in use. All the faceplates have a storage hook on the left side that accommodates the handle. Hook Handle The cool to touch door handle is designed to be inserted from the bot- tom up and slide off when not held in place. -
Page 29: Operating Instructions
Two dry pieces banged together sound hollow; wet pieces sound solid and dull. • Dry wood weighs much less than wet wood. • Split a piece of wood. If the exposed surface feels damp, the wood is too wet to burn. CI2700/HI500 | wood insert |... -
Page 30: Operating Instructions
- slide to the left to open, and to decrease - is for fire start-up only, as unit may These noises will be minimal when your unit slide to the right to close The CI2700/HI500 unit overheat if door is left open for too reaches temperature. -
Page 31: Ash Disposal
Always ensure areas on the the burning season for creosote build-up. hearth are clean and ashes, debris etc. are not pushed towards the bottom of the fascia. Always brush and clean debris away from the unit, not towards. CI2700/HI500 | wood insert |... -
Page 32: Safety Guidelines & Warnings
Burning coal will cause a sulfur-based compound to coat the catalyst. Revert to burning wood and fire the combustor to elevated temperatures for one hour. 32 | CI2700/HI500 | wood insert... -
Page 33: Catalytic Combustor (Part # 106-534)
A clean flue helps prevent chimney flue fires. 14.000 Mass = 4.649 pounds TOTAL AREA FOR AIR FLOW = 37.396 3RD ANGLE PROJECTION NOTE: SCREW METAL WRAP CI2700/HI500 | wood insert | TOGETHER CAREFULLY BY HAND INSIDE B TO PREVENT DAMAGE TO CATALYST. DO NOT UNIT SCALE AVOID USING POWER TOOL. -
Page 34: Combustor Assembly
Bypass Door Gasket Replacement. NOTE: Replacement combustors can be retrieved from Applied Ceramics or Contact your local Regency Dealer for details. DO NOT OPERATE THE APPLIANCE IF COMBUSTOR BECOMES INACTIVE - DO NOT OPERATE WITHOUT COMBUSTOR. 34 | CI2700/HI500 | wood insert... -
Page 35: Bypass Door Gasket Replacement
3. Lift off bypass plate, remove bypass gasket and replace with a new one. A -Primary Air Shield - loosen 2 x 7/16" bolts - slide forward to remove. Bypass plate Bypass gasket B- Combustor Flame Shield - loosen 2 x 7/16" bolts to remove. CI2700/HI500 | wood insert |... -
Page 36: Maintenance
When the shield parts are in place - slide to the back. E - Upper Shield - orientation for reinstall Upper Shield - center between 2 vertical pins 6. Reinstall Combustor/Flame Combustor Shield / Primary Air Shield and Bypass Rod. 36 | CI2700/HI500 | wood insert... -
Page 37: Door Gasket
We highly recommend that the chimney cleaning be done by a professional as they will have the necessary tools such as a proper sized brush and special vacuum cleaner designed to deal with fine particles. CI2700/HI500 | wood insert |... -
Page 38: Secondary Air Tube Removal / Installation
Align tab on right side air channel with notch on right hand end of air tube. Firmly grip center of air tube with vise grips, use hammer to tap vise grips from left to right until the tube bottoms out into the air channel on right. 38 | CI2700/HI500 | wood insert... -
Page 39: Cast Bypass Top Plate Removal / Installation
REMOVE the bolts on the cast bypass prior to supporting the weight to avoid damage and injury. Cast bypass opening Bottom shield View of inside top of stove 7. Remove the cast bypass opening top plate and replace. 8. Reverse steps to reinstall. CI2700/HI500 | wood insert |... -
Page 40: Parts List
* Part not Shown 106-561 Catch Assembly 106-131F 106-131F Door Catch Shims (Each) 106-043 Andirons (ea) 106-042 Andiron Bracket (Each) 106-016 Bypass rod 106-122B Bypass knob (Matt Black) 106-122MJE Bypass knob (Timberline brown) 106-143 Bottom shield 40 | CI2700/HI500 | wood insert... - Page 41 CI2700/HI500 | wood insert |...
-
Page 42: Brick Layout
BRICK LAYOUT 106-960 Brick Set - Complete 42 | CI2700/HI500 | wood insert... - Page 43 CI2700/HI500 | wood insert |...
-
Page 44: Warranty
At all times FPI reserves the right to inspect reported complaints on location in the field claimed to be defective prior to processing or authorizing of any claim. Failure to allow this upon request will void the warranty. Revision Date: July 2019 Regency Wood Products Warranty 44 | CI2700/HI500 | wood insert... - Page 45 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Revision Date: July 2019 Regency Wood Products Warranty CI2700/HI500 | wood insert |...
- Page 46 To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx within ninety (90) days of purchase. 46 | CI2700/HI500 | wood insert Revision Date: July 2019 Regency Wood Products Warranty...
- Page 47 For fireplace care and tips and answers to most common questions please visit our Customer Care section on our Web Site. Please feel free to contact your selling dealer if you have any questions about your Regency product. CI2700/HI500 | wood insert |...
- Page 49 NO LABOR WILL APPLY. All warranty claims must be sent to: Regency Fireplace Products By Authorized Regency Dealer * Prices subject to change.
- Page 50 50 | CI2700/HI500 | wood insert...
- Page 51 CI2700/HI500 | wood insert |...
- Page 52 Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency is a trademark of FPI Fireplace Products International Ltd. Printed in Canada © Copyright 2019, FPI Fireplace Products International Ltd. All rights reserved.
