Installation Manual for the

E-Z GATE OPENER

This equipment is similar to other gate or door equipment and meets or exceeds

Underwriters Laboratory Standard 325 (UL 325). However, gate equipment has

hazards associated with its use and therefore by installing this product the installer

and user accept full responsibility for following and noting the installation and

safety instructions. Failure to follow installation and safety instructions can result

in hazards developing due to improper assembly. You agree to properly install this

product and that if you fail to do so GTO, Inc. shall in no event be liable for direct,

indirect, incidental, special or consequential damages or loss of proﬁts whether

based in contract tort or any other legal theory during the course of the warranty

or at any time thereafter. The installer and/or user agree to assume responsibility

for all liability and use of this product releasing GTO, Inc. from any and all

liability. If you are not in agreement with this disclaimer or do not feel capable

of properly following all installation and safety instructions you may return this

product for full replacement value.

READ ALL INSTRUCTIONS CAREFULLY AND COMPLETELY before

attempting to install and use this automatic gate opener. This gate opener

produces a high level of force. Stay clear of the unit while it is operating and

exercise caution at all times.

All automatic gate openers are intended for use on vehicular gates only.

This product meets and exceeds the requirements of UL 325, the standard which regulates gate opener safety,

as established and made effective March 1, 2000, by Underwriters Laboratories Inc.

Telephone GTO Sales: 1-800-543-GATE (4283) or (850) 575-0176 • Fax (850) 575-8912

or GTO Technical Service: 1-800-543-1236 or (850) 575-4144 • Fax (850)575-8950

500

E-Z GATE OPENER

UL325 SERIES

1-800-543-GATE (4283) • www.mightymule.com

WARNING

MOVING GATE

Can Cause Injury or Death

1. KEEP CLEAR! Gate may move at any time.

2. Do not allow children to operate gate or play in gate area.

3. This gate is for vehicles only. Pedestrians must use separate entrance.

SINGLE GATE SYSTEM

WARNING!

3121 Hartsﬁ eld Road • Tallahassee, Florida, USA 32303

www.mightymule.com

500

UL325 SERIES

2002 GTO, Inc.

Table of Contents

Need help?

Do you have a question about the Mighty Mule 500 and is the answer not in the manual?

Questions and answers

Summary of Contents for GTO Mighty Mule 500

Page 1 You agree to properly install this product and that if you fail to do so GTO, Inc. shall in no event be liable for direct, indirect, incidental, special or consequential damages or loss of proﬁts whether based in contract tort or any other legal theory during the course of the warranty or at any time thereafter.
Page 2: Conversion Chart
Please record the product serial number (located on the control box cover), and the date and place of purchase in the spaces provided below. Refer to this information when calling GTO for service or assistance with your automatic gate opener. Serial Number ____________________ Date of Purchase ____________________ Place of Purchase ____________________ Remember to keep all receipts for proof of purchase.
Page 3: Table Of Contents
Table of Contents Gate Opener Class Categories -------------------------------------------------------------inside cover Units and Standards Conversion Chart --------------------------------------------------- Units and Standards Conversion Chart --------------------------------------------------- Units and Standards Conversion Chart inside cover PLEASE READ THIS FIRST! -------------------------------------------------- page iii Important Safety Instructions -------------------------------------------------- page 1 Disconnecting the Opener ------------------------------------------------------------- Disconnecting the Opener ------------------------------------------------------------- Disconnecting the Opener...
Page 4: Please Read This First
E-Z GATE OPENERS PLEASE READ THIS FIRST! Thank you for purchasing a Mighty Mule® E-Z Gate Opener—GTO's "do-it-yourself" automatic gate opener! When correctly installed and properly used, your Mighty Mule® E-Z Gate Opener will give you many years of reliable service. Please read the following information and watch the enclosed videotape to ensure you have the correct system for your particular needs.
Page 5: Important Safety Instructions
Because GTO automatic gate openers are only part of the total gate operating system, it is the responsibility of the part of the total gate operating system, it is the responsibility of the part consumer to ensure that the total system is safe for its intended use.
Page 6: Important Safety Instructions For The Consumer Important Safety Instructions For The Consumer
IMPORTANT SAFETY INSTRUCTIONS For The Consumer WARNING: To reduce the risk of injury or death: READ AND FOLLOW ALL INSTRUCTIONS. Failure to meet the requirements set forth in the instruction manual could cause severe injury and/or death, for which the manufacturer cannot be held responsible. When designing a system that will be entered from a highway or main thoroughfare, make sure the system is placed far enough from the road to prevent trafﬁc congestion.
Page 7 IMPORTANT SAFETY INSTRUCTIONS Entrapment Zones for a proper Pull-To-Open installation: Zone 1 – leading edge of the gate and the fence post. Zone 2 – between the gate and the gate post. Zone 3 – the path of the gate. Zone 4 –...
Page 8 If any of these signs or warning decals become damaged, illegible or missing, replace them immediately. Contact GTO for free replacements. The gate is automatic and could move at any time, posing a serious risk of entrapment. No one should be in contact with the gate when it is moving or stationary.
Page 9: Secondary Means Of Protection Against Entrapment Secondary Means Of Protection Against Entrapment
IMPORTANT SAFETY INSTRUCTIONS Secondary Means of Protection Against Entrapment As speciﬁed by Gate Opener Safety Standard, UL 325 (30A.1.1), automatic gate openers shall have an inherent entrapment sensing system, and shall have provisions for, or be supplied with, at least one independent secondary means to protect against entrapment.
Page 10: Required Safety Precautions For Gates
(recommended, not included) Entrapment Protection GTO’s inherent obstruction settings, even when properly adjusted, may not be sensitive enough to prevent bodily injury in some circumstances. For this reason, safety devices such as safety edge sensors (or photoelectric sensors), which stop and reverse gate direction upon sensing an obstruction, are suggested for enhanced protection against entrapment.
Page 11: Warning Signs And Labels
IMPORTANT SAFETY INSTRUCTIONS These warning labels should be found at the locations speciﬁed below. If any of them are missing, immediately contact GTO for replacements. DC SWING SERIES / 500 Conforms to UL 325 STANDARDS Maximum Gate: 500 lb. (226.7 kg); 16 ft. (4.8 m) Voltage: 12 Vdc;...
Page 12: Installation
Single Gate Opener Parts List Opener and Mounting Hardware ® �� ...
Page 13 (continued) Control Box and Electrical Components Battery (1) WARNING Receiver (1) GTO Transmitter(1) Moving Gate Can Cause Injury Or Death KEEP CLEAR! Gate may move at any time. Do not allow children to operate gate or play in gate area.
Page 14: Technical Speciﬁcations
/ " • Battery charge is maintained by a GTO Solar Panel Charger: ﬂoat voltage of 14.5 Vdc output is from a 19 " x 8 silicon alloy panel.
Page 15: Installation Overview
Installation Overview Pull-to-Open Gates (Gate Opens into the Property) The diagram shown below is an example of a pull-to-open installation on a chain link fence and single gate. Mounting the opener on a masonry column requires special procedures; see Column Installation Information on page 36 if you intend on page 36 if you intend on page 36 to mount the opener on a column.
Page 16: Installation Of The Mounting Hardware
Installation of Mounting Hardware The position of the post bracket determines the leverage and efﬁciency of the opener. The post bracket position also sets the clearance between the opener and gate in the open and closed positions (minimum 2 inches for safety reasons). The curved design of the post bracket works well for installations on round and square fence posts.
Page 17: Determining The Mounting Position
Determining the Mounting Position of the Post Bracket Assembly and the Gate Bracket Step 3 NOTE: The following steps are 3/8" x 2" Bolt Insert the " x 2" bolt through intended for pull-to-open gate the center hole of the post installations.
Page 18 IMPORTANT: While determining the mounting point for the post pivot bracket assembly, be sure that the position allows for a minimum of 2 inches of clearance between the gate and the opener in both the open and closed positions, as shown in the diagrams below.
Page 19 Installing the Post Bracket Assembly and Gate Mark fence post through  middle of bracket slots Step 7 and drill 3/8" holes Mark reference points for bolt holes on the fence post through middle of bracket slots. Marking reference points in this manner allows room for adjustment when mounting the post bracket assembly and gate bracket.
Page 20: Mounting The Opener Mounting The Opener
Mounting the Opener Step 11 Attach the opener to the securely bolted post bracket assembly and gate bracket using clevis pins, bushings, and hairpin clips, or optional Pin Locks (see Accessory Catalog). Verify that the opener is level and adjust the post bracket assembly if necessary.
Page 21: Mounting The Control Box
At this stage of the installation, the opener should be installed on the gate and the closed position stop should be in place. Check List • The gate is plumb, level, and swings smoothly on its hinges. • A plate or support was added for the gate bracket (if necessary). •...
Page 22: Connecting The Power Cable
Connecting Opener Power Cable Step 14 BLACK Make sure the control box power switch is in the OFF position. The ON/OFF Switch is located on the bottom of the control box. Remove the control box cover and slide the battery into position with its terminals to the RIGHT (see illustration).
Page 23: Powering The System
Powering the System Installation of the Transformer IMPORTANT: • The transformer is designed and intended for indoor use. If the transformer can be plugged only into indoor use. If the transformer can be plugged only into indoor an outside electrical outlet, a weatherproof cover or housing (available at local electrical supply stores) must be used.
Page 24 IMPORTANT INFORMATION ABOUT LOW VOLTAGE WIRE The only wire acceptable for use with GTO products is 16 gauge multi-stranded, low voltage, PVC sheathed wire. This particular gauge enables the transformer to provide an adequate charge through the control board to the battery at distances up to 1000 ft.
Page 25: Connecting The Transformer Connecting The Transformer
Step 6 Strip " of insulation from the ends of the low voltage wire. Attach these stripped ends to the transformer terminals. A dab of household petroleum jelly on each terminal will help prevent corrosion. Make sure the exposed wires do not touch each other! Step 7 Plug the transformer into the electrical outlet.
Page 26: Control Board Settings
CONTROL BOARD SETTINGS DIP Switches 1 2 3 4 5 6 7 Main DIP Switch Settings (MODES) DIP Switch #1 - Soft Start/Stop The Soft Start/Stop feature slowly starts the gate as it begins to open and slows the gate as it comes to the closed position.
Page 27: Setting The Closed Position
Setting the Closed Position Limit TURN CONTROL BOX ON Your Mighty Mule® has two Limit Settings 1) OPEN Limit setting: (Gate in the OPEN POSITION / the limit is FACTORY SET and NOT ADJUSTABLE) The open limit setting is the fully open position. 2) CLOSED Limit setting: (Gate in the CLOSED POSITION) To achieve optimum closed position, you are required to complete the following FOUR STEPS: Step 1...
Page 28: Obstuction Sensitivity
Obstruction Sensitivity Potentiometer IMPORTANT: For safety reasons the obstruction setting or For safety reasons the obstruction setting or Stall Force Stall Force on the Mighty Mule® control board comes from the factory set at on the Mighty Mule® control board comes from the factory set at MIN (minimum).
Page 29: Setting Your Personal Transmitter Code
Setting Your Personal Transmitter Code All GTO transmitters are set to a standard code at the factory and are ready to operate your Mighty Mule® Gate Opener ® For your safety and security, however, we strongly recommend that you replace the factory setting with your own personal...
Page 30: Installing The Receiver
• Standard receiver cable length is 10 feet (receivers with a longer cable are available as special order items; call the GTO Sales Department). NEVER splice receiver cable! • Run the cable through PVC conduit to protect it from damage.
Page 31: Connecting Additional Safety Devices
To augment your protection against entrapment, GTO recommends using some form of additional safety device. When installed, contact sensors must be mounted in compliance with UL 325, Underwriters Laboratories safety standard for gate openers. Review page 5 for infor- mation about mounting requirements for safety edges ("contact sensors").
Page 32 Non-Contact Sensors (photo beams) If not installing a non-contact sensor skip to next section. PLEASE NOTE: Non-contact sensors are not included with Non-contact sensors are not included with Non-contact sensors are not the Mighty Mule® 500. The Mighty Mule® 500 can also accept "Safety" input from normally open "dry-contact" output devices such as photo beams connected to the SAFETY input terminal.
Page 33: Connecting Accessories
Connecting Accessories If not connecting accessories skip to next section. The Mighty Mule® 500 can accept NORMALLY OPEN CONTACT accessories, such as; Push Button Entry Devices and Key Pads. Refer to the sensor manufacturer’s instructions for information about installing these devices on a vehicular gate. Make sure the power to the opener is turned STALL FORCE off before connecting safety device wiring to the...
Page 34: Push To Open Installation
Push to Open Installation Determining The Mounting Position of The Post Bracket Assembly Swinging gates shall not open into public access areas! 3/8" x 2" Bolt A "Push-to-Open" gate opens out from the property. out from the property. A Push-to-Open Bracket is required for this type of installation (see Accessory Catalog).
Page 35 Step 3 With the gate in the fully closed position and the opener retracted, swing the opener to the gate. Mark reference points for bolt holes on gate cross member through middle of gate bracket slots. The opener must be level. (Some vertical adjustment is possible by sliding the post bracket assembly up and down.) Drill "...
Page 36 Step 3 With the gate in the desired open position PRESS & HOLD the “SET LIMIT" button on the control board for 5 seconds. Step 4 Press the transmitter button and allow the gate to return to the closed position. YOUR GATE’S OPEN POSITION LIMIT IS NOW PROGRAMMED.
Page 37: Maintenance & Troubleshooting Guide
Maintenance & Troubleshooting Guide If your gate opener does not function properly after it is installed, use this guide before calling the GTO Service Department. • On all gates weighing 250 lb. or more, routinely grease the ball bearing hinges at least 4 times a year; more frequently if the gates are near a coastal area.
Page 38: If The Opener Is Working
12 V Battery ________________________________12.0 to 13.5 Vdc 7.0 Ah Charging circuit _____________________________12.0 to 14.8 Vdc measure voltage with battery connected The GTO, Inc. Technical Service Department is open Monday – Friday 8:00 – 5:00 (Eastern Time) A.M.
Page 39: Repair Service
1. First use the procedures found in the Maintenance & Troubleshooting Guide (see page 33). 2. If you are unable to solve the problem, call the GTO Service Department at (800) 543-1236, or (850) 575-4144. Refer to the serial number (located on the control box cover) and date of purchase when calling for assistance.
Page 40: Column Installation Information
Column Installation Information F THIS OPENER WILL BE USED WITH GATES THAT ARE MOUNTED ON MASONRY, BRICK, OR ROCK (etc.) COLUMNS: READ THE FOLLOWING CAREFULLY BEFORE PROCEEDING The simplest solution is to install the opener in a push-to-open conﬁguration (requires Push-To-Open Bracket, see Accessory Catalog).
Page 41: Accessory Catalog
® E-Z GATE OPENERS ACCESSORIES Accessories are Available From Your Retail Store Solar Panel (FM121) Not Compatible with Mighty Mule® 250 The Solar Panel is a 5 watt solar powered battery charger for use with the FM500 & FM502 gate opener systems. Particularly suited for remote installations, each Solar Panel comes with tubular steel support, mounting clips, wire connectors, and 8 ft.
Page 42 1-800-543-GATE! The contents of all material available on this installation manual are copyrighted by GTO, Inc. (“GTO”), unless otherwise indicated. All rights are reserved by GTO, and content may not be reproduced, downloaded, disseminated, published, or transferred in any form or by any means, except with the prior, written permission of GTO. Any reprinting of GTO publications is by permission only. Copyright infringement is a violation of federal law.
