Installation Manual for the
ACCESS
SYSTEMS
PROFESSIONAL RESIDENTIAL
3000XLS
3000XLS
NCB
SINGLE Gate Operator System
PROFESSIONAL INSTALLATION RECOMMENDED!
WARNING!
This equipment is similar to other gate or door equipment and meets or exceeds
Underwriters Laboratory Standard 325 (UL 325). However, gate equipment has
hazards associated with its use and therefore by installing this product the installer
and user accept full responsibility for following and noting the installation and
safety instructions. Failure to follow installation and safety instructions can result
in hazards developing due to improper assembly. You agree to properly install this
product and that if you fail to do so GTO Access Systems, ("GTO") shall in no event
be liable for direct, indirect, incidental, special or consequential damages or loss of
profits whether based in contract tort or any other legal theory during the course
of the warranty or at any time thereafter. The installer and/or user agree to assume
responsibility for all liability and use of this product releasing GTO Access Systems,
from any and all liability. If you are not in agreement with this disclaimer or do not
feel capable of properly following all installation and safety instructions you may
return this product for full replacement value.
READ ALL INSTRUCTIONS CAREFULLY AND COMPLETELY before attempting to
install and use this automatic gate operator. This gate operator produces a high level
of force. Stay clear of the unit while it is operating and exercise caution at all times.
All automatic gate operators are intended for use on vehicular gates only.
This product meets and exceeds the requirements of UL 325, the standard which
regulates gate operator safety, by Underwriters Laboratories Inc.
For more information on the GTO ACCESS SYSTEMS full line of automatic gate
operators and access controls visit our website at www.linearproaccess.com.
©2016 GTO Access Systems
Printed in China for GTO
R4815 06-03-16
Advertisement
Table of Contents
Related Manuals for GTO Linear Pro Access SW3000XLS
Summary of Contents for GTO Linear Pro Access SW3000XLS
- Page 1 You agree to properly install this product and that if you fail to do so GTO Access Systems, (“GTO”) shall in no event be liable for direct, indirect, incidental, special or consequential damages or loss of profits whether based in contract tort or any other legal theory during the course of the warranty or at any time thereafter.
-
Page 2: Class Rating
Please record the following information product serial number (located on right side of control box), be sure to keep all receipts for proof of purchase. Refer to this information when calling GTO for service or assistance with your automatic gate opener. -
Page 3: Table Of Contents
Table of Contents Class Rating ........................inside cover Please Read This First ..........................ii Important Safety Instructions......................iii Technical Specifications ........................1 Before You Begin..........................2 Determine Charging Option for Battery: Transformer OR Solar ......... 2 Solar Panel and Gate Activity Chart ..................2 Check Direction of Gate Swing .................... -
Page 4: Please Read This First
You must read the installation manual for detailed instructions on gate operator safety and proper use of the gate operator. 24/7 Troubleshooting Wizard: http://support.gtoinc.com GTO Accessories are noted with this symbol in this Installation Manual. Information about accessories can be found on page 28 and at www.linearproaccess.com. -
Page 5: Important Safety Instructions
Clevis Pin 3. Remove the operator from the mount. Gate Bracket CAUTION: Because the GTO gate operator is battery powered, Bushing disconnect the operator ONLY when the power switch on the control box is turned OFF. Unplugging the transformer does not turn power Hairpin Clip to the operator OFF. - Page 6 IMPORTANT SAFETY INSTRUCTIONS For The Consumer WARNING: To reduce the risk of injury or death: 1. READ AND FOLLOW ALL INSTRUCTIONS. Failure to meet the requirements set forth in the instruction manual could cause severe injury or death, for which the manufacturer cannot be held responsible. 2.
- Page 7 If any of these signs or warning decals become damaged, illegible or missing, replace them immediately. Contact GTO for free replacements. 2. The gate is automatic and could move at any time, posing a serious risk of entrapment. No one should be in contact with an activated gate when it is moving or stationary.
- Page 8 Install Warning Signs Warning signs alert people of automatic gate operation and are required when installing the GTO Gate Operator. The Warning Signs included must be installed on both sides of each gate. Furthermore, a walk-through gate must be installed for pedestrian traffic.
- Page 9 A wireless contact sensor shall function under the intended end-use conditions. You may want to consider adding photo beams to your installation. GTO Photo Beams [R4222] provide a “non contact” means of entrapment protection.
- Page 10 Disconnect operator ONLY when the control box power switch is OFF and the gate is NOT moving. MMDDYY GTO Access Systems, LLC - Tallahassee, Florida USA Product identification and manual operation instruction Warning signs (2 enclosed) to be installed on each side label (1) installed on right side of control box.
-
Page 11: Technical Specifications
GTO/ACCESS SYSTEMS 3000XLS AUTOMATIC GATE OPERATOR DRIVE • Low friction screw drive (linear actuator) rated for -5 ºF to +160 ºF (-21 ºC to +71 ºC). Use of GTO battery heater FM316 (Not solar compatible) is recommended in extreme cold temperatures. -
Page 12: Before You Begin
[FM123]. Refer to the Solar Panel and Gate Activity chart below. • All low voltage wire used with the GTO Gate Operator must be 16 gauge dual conductor, stranded, [RB509]. Do not run more than 1000 ft. of wire. direct burial wire... -
Page 13: Check Direction Of Gate Swing
2. Check Direction of Gate Swing The 3000XLS is designed for PULL-TO-OPEN installations. PUSH-TO-OPEN installations require a Push-To-Open Bracket [R4388]. Please refer to specific Push-To-Open Installation Information on page 22. Your Property Your Property Pull-To-Open Push-To-Open 3. Prepare the Gate (arm retracts to open) (arm extends to open) •... -
Page 14: 3000Xls Parts List
5. 3000XLS Parts List Customer Support Card (1) Master Operator Arm (1) 6’ Power Cable PRO3000ARMXLS BRACKET BOX - HB301 Closed Position Gate Bracket (1) Stop Plate (1) Post Bracket (1) Post Pivot Bracket (1) HARDWARE BAG - H301P 3/8" x 8" Bolt (4) 3/8"... -
Page 15: Tools Needed
Battery (1) WARNING Receiver (1) GTO Transmitter(1) Moving Gate Can Cause Injury Or Death KEEP CLEAR! Gate may move at any time. Do not allow children to operate gate or play in gate area. This gate is for vehicles only. Pedestrians must use a separate entrance. -
Page 16: Installation Overview
8. Installation Overview Pull-To-Open Gates (Gate Opens into the Property) The diagram shown below is an example of a Pull-To-Open installation on a chain link fence and single gate. Mounting the operator on a masonry column requires special procedures; see Column Installation Information on page 24. - Page 17 Step 1: Close the gate and place your level against the horizontal cross member. Position the level so that the top should be in the center of the cross member and overlaps the post. Scribe a line across the cross member and post. You will use this line to help determine position of post and gate brackets.
-
Page 18: Check Clearance
Step 5: Position the operator rear mount between post pivot bracket. 3/8” x 2-1/2” Clevis Pin Place a ” bushing above the rear mount and a ” bushing under the rear mount. Align the hole in rear mount, bushings and post pivot bracket and secure with the 2 ”... -
Page 19: Install Gate Bracket
Step 8 Remove the clevis pin from the front mount and while supporting the gate operator, swing the gate and gate operator to the closed position. With the gate and gate operator in the closed position check the clearance and be sure Gate in the that the gate operator is not binding at Clamp... -
Page 20: Install Closed Position Stop Plate
The closed position stop plate helps Gate Hinge to stabilize the gate leaf in the closed position. To further enhance the stability and security of your gate, install the optional GTO Automatic Gate Lock Closed Position [FM144] Stop Plate Step 11... -
Page 21: Mount Battery Box And Control Box
Mount the Battery Box and Control Box Step 1 Remove the Control box from the Battery Box by removing four screws as shown in Illustration A. Step 2 Mount the Battery Box using the screws (provided) or another secure mounting method as shown in Illustration B. - Page 22 (see illustration). The receiver cable: • Cable length is 10 ft. (receivers with longer cables are available as special order items; call the GTO Sales Department). • NEVER splice receiver cable! • Run the receiver cable through PVC conduit to protect it from damage.
-
Page 23: Connect Operator Power Cable
Connect Operator Power Cable Step 1 Loosen sealing nut on strain relief hub at bottom of control box. Insert power cable into control box through strain relief. Thread approximately 6” of the power cable into the control box and re-tighten sealing nut until the power cable locks into place. -
Page 24: Connect The Power Input
(available at local electrical supply stores) must be used. • The only wire acceptable for use with GTO products is 16 gauge stranded, low voltage, direct burial wire [RB509]. This gauge enables the transformer to provide an adequate charge through the control board to the battery at distances up to 1000 ft. - Page 25 Step 5 Strip the ends of the low voltage wire and BLACK BLACK twist tightly. Attach these ends to the 18 VAC OR SOLAR terminals located on the Low Voltage Wire from AC Transformer POWER INPUTS terminal block. Be certain or Solar Panel not to let the exposed wires touch each other!
-
Page 26: Control Board Settings
Control Board Settings Set Closed Position Limit (for Pull-To-Open Applications) Step 1 Step 2 Gate in Gate OPEN Closing Power switch is on, gate Press the transmitter to Position is in the OPEN position, activate operator arm. Control Control operator arm The gate will begin to CLOSE. -
Page 27: Adjust The Stall Force Setting
Adjust the Stall Force Setting The Stall Force potentiometer on the control board controls the obstruction sensitivity (or the amount of force the operator will apply to an obstruction for two (2) seconds before it automatically AUTO CLOSE TIME AUTO CLOSE TIME STALL FORCE STALL FORCE STALL FORCE... -
Page 28: Program Your Personal Transmitter Setting
Program Your Personal Transmitter Setting All GTO transmitters are set to a standard code at the factory and are ready to operate your GTO gate operator. For your safety and security, we strongly recommend that you replace the factory setting with your own personal setting. Follow the... -
Page 29: Dip Switch Settings
DIP Switch Settings DIP Switches AUTO CLOSE TIME STALL FORCE DIP Switch Settings (MODES) STATUS DIP Switch #1: Soft Start/Stop ON– Soft start enabled (factory LEARN RMT preset). SOFT START OFF SOFT START OFF OFF– Soft start disabled. WARNING WARNING LEARN OPEN PULL... -
Page 30: Connecting Accessories
Connecting Accessories Input Connections • All control inputs are dry-contact, normally open, inputs. DO NOT apply external voltage sources to these inputs. • All inputs are connected with respect to COMMON terminal. • The status LED will blink once when its corresponding input is activated. 1 COM: Circuit common (reference for all logic input) •... -
Page 31: Wiring Accessories
LOCK CONTROL INPUTS 2ND OPERATOR INPUT MASTER OPERATOR 2ND OPERATOR CONTROL INPUTS MASTER OPERATOR RECEIVER GTO 18 VOLT TRANSF. OR GTO RCVR. SOLAR PANEL According to Application Automatic Gate Lock (FM144 & FM142) Edge Sensor Push Button Control (RB101) Photo Beams (R4222) -
Page 32: Push-To-Open Installation
Push-To-Open Installation Information Swinging gates shall not open into public access areas! A “Push-to-Open” gate opens out from the property (operator arm extends to open the gate). A Push-To- Open installation requires the purchase of a Push-To-Open Bracket [R4388]. In a Push-To-Open installation the operator is installed while the gate is in the CLOSED POSITION. Install the Operator Follow directions for installing the 3000XLS beginning on page 7. -
Page 33: Setting The Open Position Limit (Push-To-Open Installations)
Set Control Board for Push-To-Open Make sure the control box power switch is OFF. Use a small screwdriver to move the Number 3 DIP switch from the ON DIP 1 2 3 4 1 2 3 4 factory setting (OFF / Pull-To-Open) to ON for Push-To-Open. Turn power switch ON. -
Page 34: Column Installation
Column Installation If this operator will be used with gates that are mounted on masonry, brick, or rock (etc.) columns, read the following carefully before proceeding The simplest solution is to install the operator in a push-to-open configuration. The minimum clearance is easier to achieve and clearance is no longer a problem, since the operator will be pushing the gate away from the column instead of pulling it toward the column. -
Page 35: Troubleshooting Guide
Troubleshooting Guide If your gate operator does not function properly after it is installed, use this guide before calling the GTO Service Department. Generation 3 Audible Feedback SYMPTOM DIAGNOSIS CHECK: 1 short beep upon Circuit Board • Normal Operation power up Powered Up &... -
Page 36: Voltage Readings
Generation 3 Visual Feedback SYMPTOM DIAGNOSIS CHECK: Status (clear)1 blink Cycle Terminal • Disconnect the push button, keypad, intercom keypad, or Shorted any other accessory wired to this terminal. • Try the remote. If the remote works, then the problem is the accessory. -
Page 37: Repair Service
Write the RGA number issued to you on the outside of the package in LARGE BOLD PRINT. Ship the package(s) freight prepaid to: GTO, 3121 Hartsfield Road, Tallahassee, Florida, USA 32303. NOTE: Products returned to GTO without a Return Goods Authorization (RGA) number in LARGE BOLD PRINT on the outside of the package WILL NOT be accepted. -
Page 38: Accessories
Solar Panel Kits [FM122/FM123] If your gate operator is more than 1000 ft. away from an AC power outlet, you can choose to maintain the battery charge with the GTO Solar Panel Kit. • 10 Watt Solar Panel Charging Kit [FM123] •... - Page 39 Automatic Gate Lock [FM144/FM142] The #1 Accessory For Swing Gate Operators! Designed for added security in conjunction with GTO Automatic Gate Operators. The gate lock unlocks and locks automatically when the gate opens and closes. The perfect solution for high wind conditions.
- Page 40 ADDITIONAL ACCESSORIES Photo Beams [R4222] Primary “through beam” photo beam device. Provides “non-contact” entrapment protection. Pin Lock [FM345] Use as a substitute for the clevis pin at the front mount of the 3000XLS to prevent theft of the operator. • Pin Lock 10-pack: ten Pin Locks keyed alike [FM345KA]. Push Button Control [RB101] Wire this unlit push button directly to your gate operator for simple open/close/stop operation from up to 1000 ft.
