Before You Begin
Caution –
will remove all data from the system.
Prepare the server module for service.
1
See "Preparing for Service " on page
Insert a filler panel into the empty server slot to reduce the possibility of a system shut down.
2
See "Install Server Module Filler Panels" on page
If you are replacing a REM card, remove the existing card.
3
See "Remove a REM Card" on page
Locate the REM support bracket on the motherboard.
4
For more information, see
Close the REM handle.
5
Slide the REM card under the flanges on the support bracket.
6
The flanges are on the support bracket opposite the REM handle.
Carefully align the connector on the underside of the REM card with the connector on the
7
motherboard.
Gently push down on the connector end of the REM card until the card is fully seated under the
8
REM card retaining spring.
Caution –
aligned, the connectors mate with minimum downward pressure. If not, realign the connectors
slightly and try again. Do not apply excessive force.
An audible click occurs when the spring secures the card.
Data loss. Back up your data to an external site before proceeding. The following steps
"About the Chassis" on page
Component damage. Excessive downward force is not required. When properly
43.
57.
90.
21.
Servicing a RAID Expansion Module (CRU)
91
