Table 23
Pin
A1 GND
A2 RESERVED
A3 RESERVED
A4 FCH_GPIO145_OD
A5 RESERVED
A6 RESERVED
A7 GND
A8 NC
A9 NC
A10 FCH_GPIO146_OD
A11 NC
A12 NC
A13 GND
A14 FCH_GPIO144_OD
A15 FCH_GPIO147_OD
A16 FCH_GPIO149_OD
A17 FCH_GPIO129_OD
A18 FCH_GPIO130_OD
A19 5V_S5
A20 FCH_GPIO201
A21 FCH_GPIO202
A22 FCH_GPIO150_OD
A23 FCH_GPIO204
A24 FCH_GPIO205
A25 GND
A26 NC
A27 NC
A28 NC
A29 NC
A30 NC
A31 NC
A32 GND
A33 NC
A34 NC
A35 RESERVED
A36 NC
A37 NC
A38 GND
A39 SMBUS_P2_CLK
A40 SMBUS_P2_DAT
A41 PCIE_CLKREQ#
A42 FCH_GPIO57
A43 FCH_GPIO58
A44 GND
A45 USB_P13_P
A46 USB_P13_N
A47 USB_P5_P13_OVC
A48 USB_P5_P
A49 USB_P5_N
A50 GND
Table 24
Manufacturer
FCI
6.15

Power Button (SW2)

The Fit-PC3 power button SW2 controls the system power state. For additional details, please refer to
section 4.1.3
Revised December 2011
PX2 connector pin-out
Signal Name
PX1, PX2 connector data
Mfg. P/N
61082-10260[2|6]LF
of this document.
SBC-FITPC3
Pin Signal Name
B1
GND
B2
RESERVED
B3 PCIE_P2_TX_N
B4 FCH_GPIO0
B5 RESERVED
B6 RESERVED
B7 GND
B8 NC
B9 NC
B10 FCH_GPIO1
B11 NC
B12 FCH_GPIO4
B13 GND
B14 FCH_GPIO5
B15 FCH_GPIO6
B16 FCH_GPIO3
B17 FCH_GPIO7
B18 FCH_GPIO8
B19 5V_S5
B20 FCH_GPIO9
B21 FCH_GPIO10
B22 NC
B23 FCH_GPIO11
B24 FCH_GPIO12
B25 GND
B26 PCIE_CLK2_P
B27 PCIE_CLK2_N
B28 RESERVED
B29 RESERVED
B30 RESERVED
B31 RESERVED
B32 GND
B33 RESERVED
B34 RESERVED
B35 RESERVED
B36 RESERVED
B37 RESERVED
B38 RESERVED
B39 SMBUS_THRM_CLK
B40 SMBUS_THRM_DAT
B41 GND
B42 RESERVED
B43 RESERVED
B44 FCH_PWM0_GPIO197
B45 RESERVED
B46 RESERVED
B47 FCH_PWM1_GPIO198
B48 VCC_12V
B49 VCC_12V
B50 VCC_12V
Mating connector
61083-10460[2|6]LF
