5.2

SATA

Table 6
Signal Name
SATA_P1_TX_P
SATA_P1_TX_N
SATA_P1_RX_P
SATA_P1_RX_N
SATA_P2_TX_P
SATA_P2_TX_N
SATA_P2_RX_P
SATA_P2_RX_N
SATA_P3_TX_P
SATA_P3_TX_N
SATA_P3_RX_P
SATA_P3_RX_N
SATA_ACT#
5.3

USB

Table 7
Signal Name
USB_P4_P
USB_P4_N
USB_P5_P
USB_P5_N
USB_P7_P
USB_P7_N
USB_P8_P
USB_P8_N
USB_P12_P
USB_P12_N
USB_P13_P
USB_P13_N
USB_P7_P8_OVC
USB_P4_P12_OVC
USB_P5_P13_OVC
Revised December 2011
SATA Interface Signals
Pin # Type
PX1-B8 O
PX1-B9 O
PX1-B11 I
PX1-B12 I
PX1-A2
O
PX1-A3
O
PX1-A5 I
PX1-A6 I
PX1-A8 O
PX1-A9 O
PX1-A11 I
PX1-A12 I
PX1-B4
OD
PCIe Interface Signals
Pin # Type
P1-A24 I/O
P1-A25 I/O
PX2-A48 I/O
PX2-A49 I/O
PX1-B17 I/O
PX1-B18 I/O
PX1-B14 I/O
PX1-B15 I/O
PX1-A27 I/O
PX1-A28 I/O
PX2-A45 I/O
PX2-A46 I/O
USB Overcurrent
PX1-B16 I/O
PX1-A26 I/O
PX1-A47 I/O
SBC-FITPC3
Description
SATA-1
SATA channel 1 transmit positive
SATA channel 1 transmit negative
SATA channel 1 receive positive
SATA channel 1 receive negative
SATA-2
SATA channel 2 transmit positive
SATA channel 2 transmit negative
SATA channel 2 receive positive
SATA channel 2 receive negative
SATA-3
SATA channel 3 transmit positive
SATA channel 3 transmit negative
SATA channel 3 receive positive
SATA channel 3 receive negative
SATA generic
SATA channel active
Description
USB-4
USB port 4 positive I/O
USB port 4 negative I/O
USB-5
USB port 5 positive I/O
USB port 5 negative I/O
USB-7
USB port 7 positive I/O
USB port 7 negative I/O
USB-8
USB port 8 positive I/O
USB port 8 negative I/O
USB-12
USB port 12 positive I/O
USB port 12 negative I/O
USB-13
USB port 13 positive I/O
USB port 13 negative I/O
USB over current for ports 7 and 8
USB over current for ports 4 and 12
USB over current for ports 5 and 13
FACE MODULE interfaces
Notes
Notes
16
