5.7

GPIOs

Table 11
Signal Name
FCH_GPIO0
FCH_GPIO1
FCH_GPIO3
FCH_GPIO4
FCH_GPIO5
FCH_GPIO6
FCH_GPIO7
FCH_GPIO8
FCH_GPIO9
FCH_GPIO10
FCH_GPIO11
FCH_GPIO12
FCH_GPIO54
FCH_GPIO57
FCH_GPIO58
FCH_GPIO182
FCH_GPIO201
FCH_GPIO202
FCH_GPIO204
FCH_GPIO205
FCH_GPIO129_OD
FCH_GPIO130_OD
FCH_GPIO144_OD
FCH_GPIO145_OD
FCH_GPIO146_OD
FCH_GPIO147_OD
FCH_GPIO149_OD
FCH_GPIO150_OD
FCH_PWM0_GPIO197
FCH_PWM1_GPIO198
NOTE: GPIO numbering corresponds with GPIO numbering in the A55E controller hub
documentation.
5.8

Power

Table 12
Signal Name
GND
5V_S5
VCC_12V
Revised December 2011
GPIO Signals
Pin # Type
PX2-B4
PX2-B10
PX2-B16
PX2-B12
PX2-B14
PX2-B15
PX2-B17
PX2-B18
I/O
PX2-B20
PX2-B21
PX2-B23
PX2-B24
PX1-A46
PX2-A42
PX2-A43
PX1-A22
PX2-A20
PX2-A21 I/O
PX2-A23
PX2-A24
PX2-A17
PX2-A18
PX2-A14
PX2-A4
I/OD
PX2-A10
PX2-A15
PX2-A16
PX2-A22
PX2-B44
I/O
PX2-B47
Power Signals
Pin #
PX1-A1, PX1-B1, PX1-A7,
PX1-A23, PX1-B25, PX1-A29,
PX1-A34, PX1-A40, PX1-B40,
PX2-A1, PX2-B1, PX2-A7,
PX2-B7, PX2-A13, PX2-B13,
PX2-A25, PX2-B25, PX2-A32,
PX2-B32, PX2-A38, PX2-B41,
PX2-A44, PX2-A50
PX1-B7, PX1-A13, PX1-B13,
PX1-B19, PX2-A19, PX2-B19
PX1-A47, PX1-A48, PX1-A49,
PX1-A50, PX1-B47, PX1-B48,
PX1-B49, PX1-B50, PX2-B48,
PX2-B49, PX2-B50
SBC-FITPC3
Description
S0-domain General Purpose I/O
S5-domain General Purpose I/O
General Purpose I/OD
S5-domain General Purpose I/O
Type Description
P Main GND rail
P S5-domain 5V power rail
P Main 12V power rail
FACE MODULE interfaces
Notes
GPIO state is
not preserved
in sleep mode
GPIO state is
preserved in
sleep mode
GPIO state is
not preserved
in sleep mode
GPIO state is
preserved in
sleep mode
Notes
18
