Telematrix SP-300 Spectrum PLUS User Manual page 27

Headset Feature
TM
The SpectrumPLUS
separate port for plugging in an optional
headset. The port is located o n the bottom of
the base unit. The TeleMatrix FreeSpeech
Talk Feature is a unique TeleMatrix feature that
allows the user the freedom to "toggle" between
the headset and handset modes during a
conversation.
The headset can be purchased from a
TeleMatrix distributor. There are many varieties
of headset models available.
Installing a Headset
?
The headset port is located on the bottom
side of the telephone base.
?
Plug the modular end of the headset cord
into the modular port of the telephone
labeled "HEADSET" (figure 1).
?
Press the "HEADSET ON/OFF" key to
activate the headset. The LED above the
key will illuminate to indicate that the
headset is on (figure 2).
is equipped with a
TM
27
NOTE: An external amplifier is NOT
!
recommended. The phone has a built
in amplifier.
Figure 1
Figure 2
