Series c modular direct vent

Advertisement

Quick Links

INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly, a fire or
explosion may result causing property damage,
personal injury or death.
FOR YOUR SAFETY
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier call
the fire department.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certified kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room.
270313-44
TCWS.54CE3
INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL
TCWS.54CE3
SERIES C
MODULAR DIRECT VENT
TCWS.54CE3
SERIAL #
5056.425215

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TCWS.54CE3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Town & Country Fireplaces TCWS.54CE3

  • Page 1 WHAT TO DO IF YOU SMELL GAS • Do not try to light any appliance. • Do not touch any electrical switch; • Do not use any phone in your building. • Immediately call your gas supplier from a neighbour’s phone. Follow the gas TCWS.54CE3 supplier’s instructions. • If you cannot reach your gas supplier call INSTALLATION the fire department. AND OPERATING Do not store or use gasoline or other flammable...
  • Page 2: Table Of Contents

    Maestro Control System ............... 28 Remote Control Initial Setup ............28 Maestro Control System - Operation ..........29 Maintenance ................. 32 TCWS.54CE3 Replacement Parts ..........33 Replacement Parts – Maestro Control System ......34 Wiring Diagram ................35 Roof Termination Kit ..............36 Vent Pipe Dimensions ..............
  • Page 3: Caution

    This appliance must not be connected to a chimney flue serving a separate solid fuel burning appliance. TCWS.54CE3 270313-44...
  • Page 4: Important Note For The Commonwealth Of Massachusetts

    A copy of all installation instructions for all Product Approved side wall horizontally vented gas fuelled equipment, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. TCWS.54CE3 2/0313-44...
  • Page 5: Fireplace Dimensions

    S T I B L E H C O M B U Mantel support ............4 in. (102 mm) Vertical vent pipe ..........1 3/4" in. (45 mm) UNIT MAY BE RECESSED UP TO 6” WITH NONCOMBUSTIBLE MASONRY TYPE MATERIAL TCWS.54CE3 270313-44...
  • Page 6: Installation Requirements

    To ensure glass is properly latched, grasp the top left and right sides of the glass frame, under moderate pressure it should pull forward and return to original position evenly on both sides. 6. Reinstall Trim Kit if required. TCWS.54CE3 2/0313-44...
  • Page 7: Locating The Fireplace

    The minimum clearances from the fireplace to combustible surfaces must be adhered to and are shown in Fig. #2 and Fig. #3. Fig. #7 EXAMPLES OF COMMON LOCATIONS SEE FIG #11 FOR DIMENSIONS TCWS.54CE3 270313-44...
  • Page 8: Framing And Finishing

    NON-COMBUSTIBLE ZONE. DO NOT INSTALL ANY STEEL STUD FRAMING KIT DIMENSIONS COMBUSTIBLE MATERIAL, ELECTRICAL WIRING, (Supplied with fireplace) INSULATION, PLASTIC VAPOR BARRIER OR GAS PLUMBING WITHIN THE STEEL STUD FRAMING ALL OTHER FRAMING CAN BE DONE WITH CONVENTIONAL LUMBER 74” 55” TCWS.54CE3 2/0313-44...
  • Page 9 MAXIMUM FACING DEPTH Fig. #11 MINIMUM COMBUSTIBLE 80 5/8" FRAMING DIMENSIONS 33" 46 1/4" 74 1/4" INCLUDING SHEETROCK 74 1/4" 55 1/4" 114" 22 1/16" 11 5/16" 5/8" 74 1/4" NOTE: FIREPLACE SHOULD BE IN ITS FINAL LOCATION BEFORE FRAMING. TCWS.54CE3 270313-44...
  • Page 10: Steel Stud Framing Kit

    STUD, SIDES 55” L 8293.2 STUD, OUTER SIDES 55” L 8293 STUD, UPPER/LOWER 75 1/4” L 8293.6 INNER CROSS BRACE 56 5/8” L 8293.8 STUD, CENTER 25” L 8293.9 LOWER CROSS BRACE 56 5/8” L 5049.993 SCREW, DRYWALL 1 1/4” TCWS.54CE3 2/0313-44...
  • Page 11 • Turn the framing kit over and secure all studs from the back. Fig. #12 FRONT VIEW (slightly angled) BEND OUT FRAMING TABS TO FRONT LONG EDGE UP WIDE FACE FORWARD SLOTS UP SCREW INTO SIDE TCWS.54CE3 270313-44...
  • Page 12 FRAMING must be able to move freely. No build- EDGES ing material is permitted to protrude GLASS past the lintel bars attached to the fire- FRAME place under ANY circumstance. NON COMBUSTIBLE FINISH MATERIAL TCWS.54CE3 2/0313-44...
  • Page 13: Adjustable Lintel

    5. The lintel assembly can then be adjusted to align flush with your facing material by sliding in or out approximately 1” . 6. Tighten the securing bolts. (Fig.#23). Re-attach the window trim. TRIM Fig. #18 SECURING BOLT TCWS.54CE3 270313-44...
  • Page 14: Maestro Control

    (Part # 5005.064) available from your Fig. #23A dealer). WARNING: The control box heat shield and access panel must be replaced. Failure to do so will overheat and cause premature failure of the control. Fig. #23B Fig. #23C OUTLET A/C ADAPTER GAS CONNECTION TCWS.54CE3 2/0313-44...
  • Page 15: Standing Pilot Function

    (Fig. #28) This should be depressed with a paperclip, pencil or other thin object. Once activated the pilot will run continuously. Please check with your local inspector to ensure that this is permitted in your area. LEARN BUTTON STANDING PILOT BUTTON TCWS.54CE3 270313-44...
  • Page 16 WILL NOT begin until the 10 second pre-purge delay is complete. • Upon receiving any ON command, the green LED will flash (0.5 seconds ON, 0.5 seconds OFF) for 10 seconds so the user will know that the fireplace is operating. TCWS.54CE3 2/0313-44...
  • Page 17: Gas Supply

    MANIFOLD PRESSURE Correct gas pressure requirement: Natural Gas Propane Min. Pressure 5.0" WC 12.5" WC (For purpose of input adjustment) Max. Pressure 13.9" WC 13.9" WC Manifold Pressure Maximum 3.8" WC 11" WC Minimum 2.1" WC 5.5" WC TCWS.54CE3 270313-44...
  • Page 18: Venting

    THAN 1 3/4 INCHES FROM ANY PART OF THE VENT PIPE. Wall Termination Venting This fireplace can only be wall terminated using the TCVT. PVOC1, TCVT.PVOC2 or TCVT. PVOC3 power vent kit. Please see the instructions supplied with the kit for installation details. TCWS.54CE3 2/0313-44...
  • Page 19: Roof Termination Venting Chart

    1 3/4 inches from any part of the vent pipe. Only 45º elbows can be used in this vent system. Maximum number of elbows is 2. MINIMUM VENT HEIGHT 4' MAX. 18” MIN BEFORE ELBOW TCWS.54CE3 270313-44...
  • Page 20 Rotate the 90° brackets to accom- modate roof pitch. Attach the brackets to the roof joists with nails or building screws. Tighten the band around the vent pipe and secure in place with screws. ROOF SUPPORT BRACKET (TCVT.93915) TCWS.54CE3 2/0313-44...
  • Page 21: Roof Vent Terminal

    (Fig. #34) Seal screw heads and joint with caulking to prevent any moisture entering the venting system. Fig. #34 VERTICAL TERMINATION CAP (TCVT.9365) VENT PIPE MASTIC STORM COLLAR (TC42.90665) FLASHING NOTE: ADJUSTABLE FOR VARIOUS ROOF PITCHES, FROM FLAT ROOF TO 12/12 PITCH ROOF. TCWS.54CE3 270313-44...
  • Page 22: Vent Terminal Clearance

    *A minimum of 1 support every 4’ must be used.* Roof Termination Kit ..........TCVT.RTA Wall Shield/Ceiling Firestop ........TCVT.THIMA Roof Flashing, Adjustable ........TCVT.811FLADJ Roof Flashing, Flat ..........TCVT.811FLFLT Roof Flashing, Steep ..........TCVT.811FLSTP or any flashing that fits 11" pipe TCWS.54CE3 2/0313-44...
  • Page 23: Vent Pipe Sealant

    All outer joints of the vent pipe must be sealed with the approved "High Temperature" self- adhesive aluminium tape provided. Wrap the tape completely around the joint and press firmly in place. Inner pipe does not need to be sealed. TCWS.54CE3 270313-44...
  • Page 24: Vent Restrictor Adjustment

    FULLY OPEN To adjust the restrictor: • Loosen the screw holding the restrictor. 10’ • Move the restrictor to its intended opening. • Re-tighten the screw. Fig. #40 CAUTION: The vent restrictor must be fully open OPENING when using the TCVT.PVB2 or TCVT.FMPV power vent kit to vent this fireplace. VENT RESTRICTOR TCWS.54CE3 2/0313-44...
  • Page 25: Firebox Panels Installation

    (Fig. #45)(Proceed to step #7 if you are installing a TCWS.54NG03.C2 Black Diamond burner with this unit.) Place the other front panel piece at the rear of the firebox with the wide flange facing to the rear against the back panel. TCWS.54CE3 270313-44...
  • Page 26: Finishing Touch Trim Kit Instructions

    Attach the side rails. Even the ends up with the door frame. Attach the top and bottom rails and adjust so mitres are even at the corners. Place TC magnetic logo in bottom right corner. Larger Magnets Top or bottom rail Side rails TCWS.54CE3 2/0313-44...
  • Page 27: Lighting Instructions

    It is normal for fireplaces fabricated of steel to give off some expansion and/or contraction noises during the start up or cool down cycle. Similar noises are found with your furnace ,heat exchanger or cook stove oven. TCWS.54CE3 270313-44...
  • Page 28: Maestro Control System

    6. Use the up and down arrows to set the “minute” value. HOUR: MIN. Press OK and the “day” value will flash. 8. Use the up and down arrows to set the HOLD A2 “day” value 9. Press OK to end initial set up. HOLD A1 TCWS.54CE3 2/0313-44...
  • Page 29: Maestro Control System - Operation

    3. Press the OK button and the timer is set and the control is in countdown timer mode. 4. To exit the timer mode press the Program, Manual or Thermostat buttons. Please note that the first press of the Manual button will turn the fireplace off. TCWS.54CE3 270313-44...
  • Page 30 To switch out of program mode, simply press one of the manual, timer or thermostat mode buttons. Please note that if the manual button is pressed it will turn the fireplace off. TCWS.54CE3 2/0313-44...
  • Page 31 5. The fireplace is now in thermostatic mode. To exit the thermostatic mode press the program, manual or timer buttons. Please note that the first press of the manual button will turn the fireplace off. TCWS.54CE3 270313-44...
  • Page 32: Maintenance

    Viewing glass may be cleaned as necessary with fireplace glass cleaner. b) Exterior finish may be cleaned with mild soap and water. CAUTION: Do not use abrasive cleaners on glass or any other part of the fireplace. Do not clean glass when hot. TCWS.54CE3 2/0313-44...
  • Page 33: Tcws.54Ce3 Replacement Parts

    (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. TCWS BODY ASSEMBLY ......TCWS.54CE3 FINISHING TOUCH TRIM KIT..TCRP.54WSTRIMKIT GLASS ASSEMBLY (c/w gasket) ..GLAS.2062ASSY ORIFICE (2pcs) ........5022.87 FRAMING KIT .........TCWS.54FRKIT MAIN GAS SUPPLY TUBES (3pcs) ..5019.223 PANEL SETS BURNER SUPPORT ........9498...
  • Page 34: Replacement Parts - Maestro Control System

    UTILITY BOX PRESSURE TEST ASSEMBLY ELECTRICAL RECEPTACLE AC ADAPTOR COVER PLATE #8..TEST FITTING PLATE (A) PLATE (B #4..WALL SWITCH ASSEMBLY KIT WING NUTS (2) BATTERY HOLDER 1m MINIMUM RATE SCREW, NG WALL SWITCH COVER PLATE WALL SWITCH TCWS.54CE3 2/0313-44...
  • Page 35: Wiring Diagram

    Wiring Diagram Fig. #60 TCWS.54CE3 270313-44...
  • Page 36: Roof Termination Kit

    Roof Termination Kit TCVT.RTA Fig. #61 16 1/2" VERTICAL TERMINATION CAP TCVT.9365 9" STORM COLLAR TC42.90665 CEILING FIRESTOP ROOF SUPPORT TCVT.THIMA BRACKET TCVT.93915 TCWS.54CE3 2/0313-44...
  • Page 37: Vent Pipe Dimensions

    Fig. #62 11" 12" PIPE ..10 1/4" 18" PIPE ..16 1/4" 24" PIPE ..22 1/4" 48" PIPE ..46 1/4" 10 15/16" 9 1/2" TCVT.811X12ADJ 11 1/8" TCVT.811X _ _ 12 9/16" 13 1/8" TCVT.811XLB45 TCWS.54CE3 270313-44...
  • Page 38: Vent Offset Chart

    13 7/16" 23 1/4" 18" PIPE 17 9/16" 27 5/8" 24" PIPE 21 7/8" 31 3/4" 48" PIPE 38 3/4" 44 7/8" ADDING AN ADJUSTABLE SECTION TO PIPE WILL INCREASE OFFSET BY 2 1/8" TO 6 3/4" 1 1/4” TCWS.54CE3 2/0313-44...
  • Page 39: Quick Panel Removal For Valve Service

    Pg. 13. 6. Reassemble in reverse order. WARNING: The control box shield, access panel and gasket must be replaced. Failure Fig. #66 to do so will overheat and cause premature failure of the control. Fig. #67 TCWS.54CE3 270313-44...
  • Page 40 TCWS.54CE3 2/0313-44...
  • Page 41 TCWS.54CE3 270313-44...
  • Page 42 TCWS.54CE3 2/0313-44...
  • Page 43: Safety Label Location

    Fireplace Products Ltd. des dommages matériels ou des blessures. Voir la notice de l’utilisateur qui accompgne l’appareil. Pour de l’aide ou des renseignements supplémentaires, consultez un installateur, un technicien agréé ou le fournisseur de gaz. 291012 5050.720378.CE3 1-TCWS.54CE3 TCWS.54CE3 270313-44...
  • Page 44 Technical support: 1-250-748-1184 Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
