Town & Country Fireplaces TCWS.54STOK Installation And Operating Instructions Manual
  1. Manuals
  2. Brands
  3. Town & Country Fireplaces Manuals
  4. Indoor Fireplace
  5. TCWS.54STOK
  6. Installation and operating instructions manual

Town & Country Fireplaces TCWS.54STOK Installation And Operating Instructions Manual

Series d power vented fireplace see thru fireplace
Hide thumbs Also See for TCWS.54STOK:
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly, a re or
explosion may result causing property damage,
personal injury or death.
FOR YOUR SAFETY
Installation and service must be performed
by a qualifi ed installer, service agency or the
gas supplier.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier call
the fi re department.
Do not store or use gasoline or other
fl ammable vapors and liquids in the vicinity
of this or any other appliance.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by local
codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a
certifi ed kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Visit www.townandcountryfi replaces.net for the most recent version of this manual
170316-60
TCWS.54STOK
Indoor/outdoor Fireplace
installation and operating
instructions.
MODEL: TCWS.54STOK
SERIES D
POWER VENTED FIREPLACE
SEE THRU FIREPLACE
TCWS54.STOK
SERIAL #
5055.545-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TCWS.54STOK and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TCWS.54STOK

Summary of Contents for Town & Country Fireplaces TCWS.54STOK

  • Page 1 • If you cannot reach your gas supplier call installation and operating the fi re department. instructions. Do not store or use gasoline or other MODEL: TCWS.54STOK fl ammable vapors and liquids in the vicinity SERIES D of this or any other appliance. POWER VENTED FIREPLACE...

  • Page 2: Table Of Contents

    Annual Inspection: ............49 Venting Con gurations ............22 Periodically: ..............49 Power Venting Options ............22 Replacement parts-TCWS.54STOK ........50 Minimum Vent Length Chart ............ 23 Replacement Parts - TCWS.54DST ........51 Vent Terminal Minimum Clearances ........23 Replacement Parts - Tranquility Burner ........52 Venting Components ...............

  • Page 3: R - Value Statement

    R - Value Statement It has been determined that the Town and Country model TCWS.54STOK indoor/outdoor Fireplace has an R value of 5.8. This determination has been arrived at by the calculation of the typical R value of two layers of 5mm Ceramic glass, combined with 17 inches of ventilated air gap.

  • Page 4: Important Note For The Commonwealth Of Massachusetts

    Important Note for the Commonwealth of Massachusetts From Massachusetts Rules and Regulations 248 CMR 5.08: For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above nished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satis ed.

  • Page 5: Fireplace Dimensions

    Fireplace Dimensions 54 1/16" 74 3/4" Front view 74 3/4" 54 1/16" variable adjustment (see page 13) Top view 3 3/16" 1/2" Pro le view Figure 1: TCWS54STOK Dimensions. TCWS54STOK_170316-60 5055.545-A...

  • Page 6: Minimum Clearances To Combustible Material

    Minimum Clearances to Combustible Material NON-COMBUSTIBLE ZONE. STEEL FRAMING DO NOT INSTALL ANY COMBUSTIBLE MATERIAL, COMBUSTIBLE FRAMING AND FINISH WALL ABOVE STANDOFFS ELECTRICAL WIRING OR GAS PLUMBING IN THIS AREA. MAY USE COMBUSTIBLE FACING MATERIAL IN THIS AREA MANTEL CLEARANCE CHART NON-COMBUSTIBLE FINISH MATERIAL...

  • Page 7: Installation Requirements

    Installation Requirements The Town & Country Fireplace installation and venting must conform to the current CAN/CGA-B149 installation code (in Canada) or the current National Fuel Gas Code, ANSI Z223.1 (in the USA), and approved per local codes. Only qualified (licensed or trained) personnel should install this product. In the state of Massachusetts, only a licensed Plumber and Gas Fitter may install this product.

  • Page 8: Standoffs

    Standoffs The framing kit, once assembled and attached, are used as the top and side standoffs. Figure 7: TCWS54STOK Frame as standoffs. Locating The Fireplace In planning the installation for the replace, it is necessary to determine where the unit is to be installed, location of vent system and where gas supply piping may be plumbed.

  • Page 9: Framing And Finishing

    Framing and Finishing Note: The fireplace should be in place *The finishing material must not inter- and venting installed before framing If the backer board is not to be nished fere with glass frame access.* in or building an enclosure around the with other non-combustible material such unit.

  • Page 10: Removing Led Light Wire Retaining Clip

    Removing LED light wire retaining clip NOTE: This fi replace ships with the light wiring secured in retaining clips. Remove light NOTE: This fi replace ships with the light wiring secured in retaining clips. Remove light wiring from the retaining clip before installing and walling up the fi replace. wiring from the retaining clip before installing and walling up the fi...

  • Page 11: Building Envelope Sealing Procedure

    Building envelope sealing procedure Exterior wall sheathing Seal joint with ashing tape prior to applying house wrap barrier lm (not supplied) 1/2" OSB board (factory installed) Outer window trim Stainless steel ashing Wall Use supplied double sided tape to adhere house wrap barrier lm to stainless steel ashing...

  • Page 12: Building Materials - Outer Trim Pro Le View

    Building materials - Outer trim profile view Siding material - Must not interfere with outer window trim removal Sheathing Panel House wrap barrier lm Exterior wall stud Additional flashing may be required. Check local building codes Outer window trim 1 1/2 inch air space required from the bottom of the window trim...
  • Page 13 Double sided tape is factory installed over stainless steel anges. Peel backing from double sided tape prior to applying house wrap barrier lm. Double sided tape pre-applied to outdoor box to keep vapour barrier lm rmly in place. Figure 13: Double sided tape for outdoor box. 54 1/16"...

  • Page 14: Non-Combustible Board Detail

    Calcium silicate board If nishing the wall above the unit with Non-combustible board detail paint, the framing kit shipped with the unit should be discarded.Use full sheets of calcium silicate board or equivalent and full length metal studs to nish and NON-COMBUSTIBLE frame around the unit.

  • Page 15: Secure Steel Frame To Combustible Framing

    Secure steel frame to combustible framing • Bend out the tabs 90 degrees before inserting the unit into its framed housing (Figure 19). • Secure the frame assembly to the wood frame through the tabs (Figure 20). Install Non-Combustible Board (not supplied) • Use drywall screws 8 to install the non-combustible board.

  • Page 16: Lintel Adjustment

    Lintel Adjustment 1. The adjustable lintel assem- bly has two orientations for desired nishing. The anged edge and the hemmed edge (Figure 22). The lintel comes factory installed with the ange edge out . If the desired edge is different from the factory setting, use the following steps to change it.

  • Page 17: Electrical

    Electrical Note: Installation must be performed by a qualified installer, service agency or gas supplier. The gas control system is located on the right hand side of the rebox behind an access panel and the decorative rebox panel (if installed). The replace is operated via a wall control and a hand held remote control unit. This entire length of the supplied cable MUST be used.

  • Page 18: Wall Switch And Remote Control

    Wall Switch and Remote Control Note: The wall switch for the TCWS54STOK must not have batteries installed in it. The batteries are for back up in case of a power outage. This fireplace must not operate with a battery back up. TO FIREPLACE DO NOT install batteries in the wall switch...

  • Page 19: Home Automation

    Home Automation The home automation feature supplied with this replace is capable of controlling the ame and light on/off function with the use of a dry SUPPLIED CABLE contact relay common to home automation systems. Furthermore, the FROM FIREPLACE ame and light level may be modulated from high to low using the 0 - 10 volt analog output available on most home automation systems.

  • Page 20: Gas Supply

    Gas Supply Servicing of the appliance can be performed from inside the unit and through the access panel located in the rebox bottom. Caution: The gas line should be installed by a quali ed service person in accordance with all building codes. This section is intended as a guide for quali ed technicians installing this appliance.

  • Page 21: Venting - Wall Power Vent Kit Only

    Venting - Wall Power Vent Kit Only For Power Venting this replace, see “Venting Con gurations and “Power Venting Options” on page 22 VENT SUPPORTS: A minimum of 1 support every 4’ must be used. CAUTION: UNDER NO CONDITION SHOULD COMBUSTIBLE MATERIAL BE CLOSER THAN 1 ½ INCHES FROM ANY PART OF THE VENTING PIPE.

  • Page 22: Venting Con Gurations

    Venting Configurations VENTING CONFIGURATIONS The power vent is mandatory on this indoor/outdoor replace and Vertical must conform to the following power vent venting variables: • Venting can consist of any Horizontal combination of rise and run power vent up to a total of 110’ includ- ing up to 3 ft below the unit and a 66’...

  • Page 23: Minimum Vent Length Chart

    Minimum Vent Length Chart TCWS54STOK Minimum Rise Pipe Min. From Floor to Length Pipe Flue Center Length 58 7/16” 0” 36” Figure 35: Minimum pipe length. Vent Terminal Minimum Clearances FIXED CLOSED OPEN- FIXED ABLE CLOSED OPEN- ABLE AREA WHERE TERMINAL GAS METER VENT TERMINAL AIR SUPPLY INLET...

  • Page 24: Venting Components

    Venting Components SIMPSON DURAVENT COMPONENTS SECURE VENT COMPONENTS Number Description Number Description 1208 6” Pipe Length SV5L6 6” Pipe Length 1207 9” Pipe Length SV5L12 12” Pipe Length 1206 12” Pipe Length SV5L24 24” Pipe Length 1204 24” Pipe Length SV5L36 36”...

  • Page 25: Vent Pipe Sealant

    Vent Pipe Sealant APPROVED “HIGH TEMP.” VENT PIPE SELF-ADHESIVE TAPE (SUPPLIED) Figure 37: Taping vent pipe. All outer joints of the vent pipe must be sealed with the approved "High Temperature" self-adhesive aluminium tape provided. Wrap the tape completely around the joint and press rmly in place. Inner pipe does not need to be sealed.

  • Page 26: Optional Tranquility Burner

    Optional Tranquility Burner Contents of Package: Figure 38: Tranquility kit components. Figure 39: NGST04 Media contents. 3.4 lbs sand Hardware pack Pilot rock Burner assemblies Burner tray assembly Pebble sets Secondary oor halves without lights Tray legs 5055.545-A TCWS54STOK_170316-60...

  • Page 27: Installation

    Installation: If converting to propane see conversion ATTACH HERE AND ON OPPOSITE SIDE instructions on “Propane Conversion” on page 32 before proceeding. Install one side of the secondary oor as shown. Repeat with the other side but do not put in the two center screws until you put the center tray leg in place (Figure 40 and Figure 41).
  • Page 28 NOTE: CHECK AIR SHUTTER FOR CORRECT FUEL SETTING BEFORE PROCEEDING FURTHER. BOTH BURNERS ARE THE SAME. FULLY CLOSED FOR NATURAL GAS.13/64 (0.2)” OPEN FOR LP. Install burners as shown in Figure 43. Be sure to engage the venturis onto the ori ces in the manifold and rest burners together on the center tray leg.
  • Page 29 Install burner tray as shown in Figure 46 using 8 screws. Secure tray around pilot rst then the other 6 screws. SECURE PILOT HERE FIRST Figure 46: ng04 Securing pilot. Place sand into the burner tray and brush smooth. Use caution not to get sand near the burner ports (Figure 47).
  • Page 30 Each rock has a slot in it’s base and is marked with a letter and an arrow (Figure 48). The rocks must be positioned so that the arrows face the same way. Figure 49: Single set of rocks. Figure 48: Bottom of rock with arrow. Place each rock as per the following photographs, start from the right hand side of the...
  • Page 31 Repeat the sequence of placing the rocks three more times until the burner is covered. Place the fth set of rocks randomly around the burners in the sand as desired. Figure 57: Rock H. Figure 56: Rock G. Place the pilot rock over the pilot with the opening facing the center of the burner .

  • Page 32: Propane Conversion

    Propane Conversion If the unit is to be used on propane convert as follows using the components supplied with the burner: CAUTION The gas supply and electrical power shall be shut off before proceeding with the conversion. MAIN BURNER 1.78mm ORIFICES Note: P/N (5022.72) Factory supplied components must be used to ensure correct input.
  • Page 33 Slide the pilot adjustment band over and ensure that the hole in the ori ce band is showing. Figure 68 shows NG position Figure 69 shows LP position. LP POSITION NG POSITION Fill in the date and the name of the person who performed the conversion in the white area on Figure 68: Pilot adjustment band in...

  • Page 34: Optional Twilight Diamond Burner

    Optional Twilight Diamond Burner Contents of Package: IMPORTANT: THESE INSTRUCTIONS ARE TO REMAIN WITH THE HOMEOWNER These instructions are supplementary to the Installation and Operating Instructions supplied with the replace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions.

  • Page 35: Installation

    Installation: PILOT HOLE If converting to propane see “Propane Conversion” on page 32 before proceeding. Install the secondary oor on the side away from the gas connections rst. Insert the wires leading from the secondary oor half through one of the grommets in the bulkhead plate.
  • Page 36 Remove the panel retainer clips from both sides of the upper rebox (Figure 73) Insert both side panels (Figure 74). PANEL RETAINER CLIP. Figure 73: Panel retainer clip. NOTE: PROCEED TO AND FOLLOW INSTRUCTIONS IN “Gas Pressure Check” on page 38 BEFORE INSTALLING BURNER TRAY AND MEDIA.
  • Page 37 11. Place the two porcelain strips, sup- plied with the panel set, into the replace as shown in Figure 76 with the narrow edge facing the center of the replace. 12. Spread the glass media evenly over the entire mesh tray, leaving the small protrusion above the pilot clear of glass.

  • Page 38: Gas Pressure Check

    Gas Pressure Check Note: To test the gas pressure, turn off the gas supply before removing the plug from the supply pressure test port or manifold pressure test port. Verify gas pressures with the fireplace lit and on the highest setting. If installed, remove all media and the burner tray.

  • Page 39: Burner Flame Adjustment

    Burner Flame Adjustment The air shutter on the burner tube controls the primary combustion air. It is set to the closed position at the factory for natural gas fuel. If using liquid propane, see “Propane Conversion” on page 32. Some adjustment may be necessary to obtain desired ame and to eliminate carbon deposits.

  • Page 40: Firebox Panels Installation

    Firebox Panels Installation RETAINING CLIP Remove side panel securing tabs for both sides in upper rebox (Figure 80). Place bottom of side panel in rst then tip up into vertical position Figure 80: Retaining clip. (Figure 81). Attach the side panel securing tabs previously removed. Repeat steps 2 & 3 with other side panel.

  • Page 41: Finishing Touch Trim Kit Instructions

    Finishing Touch Trim Kit Instructions Place two smaller magnets on back of each side rail. Place two larger magnets on back of the top and bottom rails. Attach the side rails. Even the ends up with the door frame. Attach the top and bottom rails and adjust so mitres are even at the corners. Place TC magnetic logo in bottom right corner.

  • Page 42: Lighting Instructions

    Lighting Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: - Immediately call your gas supplier from a neighbour's phone. Follow If you do not follow these instructions exactly, a the gas supplier's instructions. fire or explosion may result causing property damage, - If you cannot reach your gas supplier, call the fire department.

  • Page 43: First Fire

    First Fire When lit for the rst time, the replace will emit a slight odor for a couple of hours. This is due to the cur- ing of paints, sealants and lubricants used in the manufacturing process. This condition is temporary. Open doors and windows to ventilate area.
  • Page 44 TRANSMISSION KEY LOCK LOW BATTERY ALARM THERMOSTAT OFF/ ON/SMART ROOM TEMPERATURE * SEE NOTICE REGARDING * SEE NOTICE REGARDING * SEE NOTICE REGARDING THERMOSTAT USE THERMOSTAT USE SMART CPI MODE SET POINT: TEMPERATURE/LEVEL/STATE DIMMER ON DIMMER ON Figure 86: Pro ame 2 LCD screen details. NOTICE: The thermostat function is disabled by default.

  • Page 45: Fireplace Description

    Fireplace Description The Pro ame 2 Remote Control Fireplace consists of three elements: Pro ame 2 Remote Control Transmitter (Figure 85) Pro ame Integrated Fireplace Control (IFC) board and a wiring harness to connect the IFC to the gas valve and stepper motor (Figure 27 on page 17) Wall mounted Remote Control Receiver (Figure 89).

  • Page 46: Using The Remote Control Transmitter

    Program button Figure 87: Wall switch - interface side. Figure 90: Pro ame 2 remote battery holder. Figure 89: Town and Country wall switch. Figure 88: Wall switch no batteries. Using the Remote Control Transmitter Temperature indication Display With the remote control transmitter in the “OFF” position, press the thermostat and mode keys at the same time.

  • Page 47: Remote Flame Control

    Remote Flame Control The Pro ame 2 has six (6) ame levels. With the replace turned on, and the ame level at maximum height, press the down arrow key once to reduce the ame height by one step until the ame is turned off. Flame level Max Flame level 5 The up arrow key will increase the ame height each time it is pressed.

  • Page 48: Remote Dimmer Control (Light)

    Remote dimmer control (Light) The auxiliary function controls the AUX power outlet by the dimmable light control. To activate this function use the Mode Key (Figure 85) to index to the light bulb icon (Figure 97). The intensity of the output can be adjusted through six (6) levels. Use the Up/Down Arrow Keys on the handset to adjust the output level.

  • Page 49: Maintenance

    Maintenance CAUTION: Turn off gas and electrical power supply (if applicable) and allow ample time for unit to cool before servicing appliance. It is recommended that the fireplace and its venting should be inspected at least once a year by a qualified service person.

  • Page 50: Replacement Parts-Tcws.54Stok

    Replacement parts-TCWS.54STOK indoor/outdoor Installation kit TRIM INNER GLASS ASSEMBLY TRIM OUTER Part # Part Description TCWS.847718 TC Widescreen 54 See Through Outdoor kit Trim Inner TCWS.847804 TC Widescreen 54 See Through Outdoor kit Trim Outer TCWS.8478 TC Widescreen 54 See Through Outdoor kit Glass Assy.

  • Page 51: Replacement Parts - Tcws.54Dst

    Replacement Parts - TCWS.54DST (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. #1 TCWS BODY ASSEMBLY ......TCWS.54CSTE *#5 FINISHING TOUCH TRIM KIT .....TCRP.54WSTRIMKIT #2 GLASS ASSEMBLY (c/w gasket) ..... GLAS.2062ASSY #6 ORIFICE (2pcs) ............5021.332A #3 FRAMING KIT .........

  • Page 52: Replacement Parts - Tranquility Burner

    Replacement Parts - Tranquility Burner (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. TRANQUILITY BURNER KIT ....TCWS.54NGST04D PEBBLE ASSEMBLY(5 boxes) ......5096.921 SAND (Two Bags) ..........TC42.SAND34 PILOT ROCK, BLACK ........5096.995BLK PILOT ROCK, GREY ........5096.995GRY PILOT ROCK, PLAIN ..........5096.995 NOT SHOWN KIT CONTENTS: 5055.545-A...

  • Page 53: Replacement Parts - Twilight Diamond Burner

    Replacement Parts - Twilight Diamond Burner (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. #1 Twilight DIAMOND BURNER ....TCWS.54NGST03D #2 GLASS MEDIA (3 required) ......TCRP.501201 #3 LIGHT BULB ............5033.713 NOT SHOWN KIT CONTENTS: TCWS54STOK_170316-60 5055.545-A...

  • Page 54: Replacement Parts - Valve Control System

    Replacement Parts – Valve Control System (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. #4 TEST FITTING ............5019.104 #1 CONTROL ASSEMBLY KIT ......TCCV.95755-B #5 WALL SWITCH ASSSEMBLY KIT ...... TCRP.WSA #2 BULKHEAD ASSEMBLY KIT ......TCRP.8133 #6 REMOTE TRANSMITTER .......

  • Page 55: Wiring Diagram

    Wiring Diagram TCWS54STOK_170316-60 5055.545-A...

  • Page 56: Rating Label

    Rating Label VENTED GAS FIREPLACE - NOT FOR USE WITH SOLID FUEL FOYER AU GAZ À ÉVACUATION - NE PAS UTILISER AVEC DU COMBUSTIBLE SOLIDE ANSI Z21.50-2014 / CSA 2.22-2014 Vented Gas Fireplaces CAN/CGA 2.17-M91 Gas-Fired Appliance For Use At High Altitudes. ANSI Z21.97-2014 Outdoor decorative gas fireplace CSA 2.41-2014 Outdoor gas fireplace This Appliance is Equipped For Use With /...
  • Page 57 TCWS54STOK_170316-60 5055.545-A...
  • Page 58 5055.545-A TCWS54STOK_170316-60...
  • Page 59 TCWS54STOK_170316-60 5055.545-A...
  • Page 60 © 2016 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer Web site: www.townandcountry replaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
