INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly, a re or
explosion may result causing property damage,
personal injury or death.
FOR YOUR SAFETY
Installation and service must be performed
by a quali ed installer, service agency or the
gas supplier.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier call
the re department.
Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any
other appliance.
Visit www.townandcountryfireplaces.net for the most up-to-date version of this manual
041115-36
CARBON MONOXIDE HAZARD
This appliance can produce carbon mon-
oxide which has no odor.
using it in an enclosed space can kill
you.
Never use this appliance in an enclosed
space such as a camper, tent, car or
home.
TCWS54 OUTDOOR GAS
FIREPLACE INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL
TCWS.54OD
SERIES C
MODULAR DIRECT VENT
WARNING: For Outdoor Use Only
Installation and service must be performed
by a quali ed installer, service agency or the
gas supplier.
TCWS.54CODE
SERIAL #
5055.5401-A
Advertisement
Table of Contents
Related Manuals for Town & Country Fireplaces TCWS.54CODE
Summary of Contents for Town & Country Fireplaces TCWS.54CODE
- Page 1 Never use this appliance in an enclosed space such as a camper, tent, car or home. Installation and service must be performed by a quali ed installer, service agency or the gas supplier. Visit www.townandcountryfireplaces.net for the most up-to-date version of this manual 041115-36 TCWS.54CODE 5055.5401-A...
-
Page 2: Table Of Contents
Fireplace Dimensions ........... 7 First Fire .............. 25 Minimum Clearances to Combustible Material ..7 Maintenance ............26 Installation Requirements ........8 TCWS.54CODE Replacement Parts ....27 Window Frame Removal ........8 Honeywell Control System Standoffs .............. 9 Replacement Parts ..........28 Locating The Fireplace ......... -
Page 3: Caution
Caution FOR YOUR SAFETY - Do not install or operate your Town & Country re- place without rst reading and understanding this manual. Any installation or operational deviation from the following instructions voids the Town & Country FireplacesTM Warranty and may prove hazardous. This appliance and its individual shut off valve must be disconnected from gas supply piping system during any pressure testing of that system at test pres- sures in excess of 1/2 psig (3.5 kPa). -
Page 4: Important Note For The Commonwealth Of Massachusetts
Important Note for the Commonwealth of Massachusetts: From Massachusetts Rules and Regulations 248 CMR 5.08: For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above nished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satis ed. -
Page 5: This Fireplace Is Intended For Outdoor Use Only
This Fireplace Is Intended For Outdoor Use Only! • The replace must be located inside of a weatherproof enclosure. • Flashing must be installed around the replace opening in accordance with local building codes in order to prevent moisture from entering the enclosure. -
Page 6: Propane Conversion
Propane Conversion Note: This replace comes with a pre-installed Honeywell pilot. When installing the burner assembly, remove the pilot that came attached to the burner and discard. DO NOT USE ANY OTHER PILOT WITH YOUR OUTDOOR UNIT ORIFICE OTHER THAN THE HONEYWELL HOUSING PILOT THAT CAME INSTALLED IN THE FIREPLACE. -
Page 7: Fireplace Dimensions
Fireplace Dimensions 73 7/8” 73 7/8” 22 11/16” 55” 28 5/8” 17 3/4” 29 3/4” 11 1/2” 53 9/16” 53 9/16” Figure 5: TCWS.54 CODE dimensions. Minimum Clearances to Combustible Material NON-COMBUSTIBLE ZONE. STEEL FRAMING COMBUSTIBLE FRAMING AND DO NOT INSTALL ANY COMBUSTIBLE MATERIAL, FINISH WALL ABOVE STANDOFFS ELECTRICAL WIRING OR GAS PLUMBING IN THIS AREA. -
Page 8: Installation Requirements
Installation Requirements The Town & Country Fireplace installation and venting must conform to the current CAN/CGA-B149 installation code (in Canada) or the current National Fuel Gas Code, ANSI Z223.1 (in the USA), and approved per local codes. Only quali ed (licensed or trained) personnel should install this product. -
Page 9: Standoffs
Standoffs The standoffs are shipped loose inside the replace and must be installed on the top and the side of the replace as shown in (Figure 10). Do this once the replace is on site and in position. TOP STANDOFFS SIDE STANDOFF (THIS SIDE ONLY) -
Page 10: Framing And Finishing
Framing and Finishing Note: The fireplace should be in place of this manual. Attach the steel frame to Fabricate and install appropriate ashing and venting installed before framing the replace once the replace is in its to local building code. in or building an enclosure around the nal position. - Page 11 NON-COMBUSTIBLE BOARD DETAIL IF FINISHING THE WALL ABOVE THE UNIT WITH PAINT, THE FRAMING KIT SHIPPED WITH THE UNIT SHOULD BE DISCARDED. NON-COMBUSTIBLE IT IS RECOMMENDED TO USE FULL BOARD SHEETS OF CALCIUM SILICATE BOARD OR ITS EQUIVALENT AND 12” FULL LENGTH METAL STUDS TO FINISH AND FRAME AROUND THE UNIT.
-
Page 12: Steel Stud Framing Kit
Steel Stud Framing Kit Each Kit Contains: Item Part # Description Qty. 5049.9912 SCREW, WAFER #8 x 1/2 8293.4 STUD, SIDES 55” L 8293.2 STUD, OUTER SIDES 55” L 8293 STUD, UPPER/LOWER 75 1/4” L 8293.6 INNER CROSS BRACE 56 5/8” L 8293.8 STUD, CENTER 25”... -
Page 13: Frame Assembly
1. Frame assembly 1. On a at surface, lay one 75 1/4” (#4) stud on its end and at the top of your working area. This will be the top most horizontal stud. 2. Position all three 25” studs (#6) vertically with the center stud aligning with the center of the above (#4) horizontal stud. - Page 14 2. Attach the assembled frame to the fireplace • Align the assembled frame to the replace framing brack- ets (Figure 19) Attach at the fastening points through the access holes in the outer side studs (3). 3. Secure to Existing Framing • Bend out the tabs 90 degrees before inserting the unit into its framed housing (Figure 20).
-
Page 15: Adjustable Lintel
Adjustable Lintel The adjustable lintel assembly has two orientations for desired nishing. A anged edge and a hemmed edge. The lintel comes factory installed with the ange edge out. If the desired edge is different from the factory setting, use the following steps to change it. -
Page 16: Honeywell Control Valve Plumbing And Electrical
Honeywell Control Valve Plumbing and Electrical The gas control system is located on the right hand side of the rebox behind an access panel ACCESS PANEL and the decorative rebox panel (if installed). The replace is operated via a wall switch. The wall control is connected to the replace by a 14-2 AWG wire, not supplied with the replace. -
Page 17: Gas Supply
Gas Supply Caution: The gas line should be installed by a quali ed service person in accordance with all building codes. This sec- tion is intended as a guide for quali ed technicians installing this appliance. Consult local and/or national building codes before proceeding. -
Page 18: Venting
Venting Before installing venting for this unit, the installer should read these instructions to insure that the proper vent con gura- tion has been selected. Use only Town and Country Termination kits #:TCVT.RTA - Roof Termination Kit Vent system components approved for use with the Town and Country Fireplace are shown on page 21. Various combinations of vent runs may be used. - Page 19 Ceiling Opening: 1. Determine the exact position of the replace so that the vent pipe is cen- tered (if possible) between two building framing members. Lay out the vent 14 1/2" system path, minimizing the number of elbows and length of vent. Consult your local building codes prior to proceeding.
- Page 20 Roof Vent Terminal: 1. Place the roof ashing over the vent pipe, secure and seal it to the roof using the methods and materials appro- priate for the type of roof on the building. Shingle roof example shown (Figure 32). 2.
-
Page 21: Vent Terminal Clearance
Vent Terminal Clearance Minimum clearances to the vent terminal must be maintained VENT TERMINAL MINIMUM CLEARANCES as shown in (Figure 33). Measure clearances to the nearest TO ADJACENT STRUCTURES edge of termination hood. NOTE: Vent terminal must not be recessed NOTE: LOCAL CODES OR REGULATIONS MAY REQUIRE 36"... -
Page 22: Vent Pipe Sealant
Vent Pipe Sealant APPROVED “HIGH TEMP.” VENT PIPE SELF-ADHESIVE TAPE (SUPPLIED) Figure 34: Sealing the vent with tape. All outer joints of the vent pipe must be sealed with the approved "High Temperature" self-adhesive aluminium tape pro- vided. Wrap the tape completely around the joint and press rmly in place. Inner pipe does not need to be sealed. 5055.5401-A TCWS.54CODE_041115-36... -
Page 23: Vent Restrictor Adjustment
Vent Restrictor Adjustment The vent restrictor is located on the underside of the rebox top. The unit leaves the factory with the vent restrictor open. The restrictor is built into WALL AND ROOF the appliance for secondary air ow adjustment. Adjustment enables tun- TERMINATION ing the air ow for optimum ame appearance and performance for a wide RESTRICTOR POSITION... -
Page 24: Firebox Panels Installation
Firebox Panels Installation 1. Remove the 2 inner screws from the upper heat shield (Figure 37). 2. Slip the top porcelain panel into the lip at the front of the rebox and tip the panel up to align with the screw holes. -
Page 25: Lighting Instructions
Lighting Instructions FOR YOUR SAFETY READ BEFORE LIGHTING - Do not touch any electric switch; do not use any phone in your WARNING: If you do not follow these instructions building. - Immediately call your gas supplier from a neighbour's phone. exactly, a fire or explosion may result causing Follow the gas supplier's instructions. -
Page 26: Maintenance
APPENDIX Maintenance CAUTION: Turn off gas and electrical power supply (if applicable) and allow ample time for unit to cool before servicing appliance. It is recommended that the fireplace and its venting should be inspected at least once a year by a qualified service person. -
Page 27: Tcws.54Code Replacement Parts
ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. #1 TCWS BODY ASSEMBLY ....TCWS.54CODE #6 ORIFICE (2pcs) ..........5022.87 #2 GLASS ASSEMBLY (c/w gasket) ..GLAS.2062ASSY #7 MAIN GAS SUPPLY TUBES (3pcs) ....5019.223 #3 FRAMING KIT ........TCWS.54FRKIT #8 BURNER SUPPORT ..........9498 #4 PANEL SETS #9 PILOT ASSEMBLY ...... -
Page 28: Honeywell Control System Replacement Parts
APPENDIX Honeywell Control System Replacement Parts (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. #1 CONTROL ASSEMBLY KIT ....TCRP.9000 #2 BULKHEAD ASSEMBLY KIT ..... TCRP.8133 #3 CONTROL BOX KIT ....TCRP.92762WLD #4 TEST FITTING ........5019.104 KIT CONTENTS: #1 CONTROL ASSEMBLY KIT VALVE C/W FITTINGS... -
Page 29: Wiring Diagram
APPENDIX Wiring Diagram VR8204M1091 S86 VALVE MODULE HONEYWELL VALVE BLACK WHITE PV/MV PV/MV ORANGE GREEN GAS CONTROL TERMINAL 24VAC 24VAC 24VAC TRANSFORMER SPARK/FLAME SENSOR WIRE PILOT WHITE BLACK BURNER SWITCH (NOTSUPPLIED) 115VAC HOT 60Hz 115VAC COMMON 60Hz (STANDAR AWG 14-2 WIRE OR EQUIVALENT) (NOT SUPPLIED) TCWS.54CODE_041115-36 5055.5401-A... -
Page 30: Roof Termination Kit
APPENDIX Roof Termination Kit 16 1/2" VERTICAL TERMINATION CAP TCVT.9365 9" STORM COLLAR TC42.90665 CEILING FIRESTOP ROOF SUPPORT TCVT.THIMA BRACKET TCVT.93915 Figure 43: Vent terminal kit. 5055.5401-A TCWS.54CODE_041115-36... -
Page 31: Vent Pipe Dimensions
APPENDIX Vent Pipe Dimensions 11" 12" Pipe ....10 1/4" 18" Pipe ....16 1/4" 24" Pipe ....22 1/4" 48" Pipe ....46 1/4" 10 15/16" 9 1/2" TCVT.811X12ADJ 11 1/8" TCVT.811X _ _ 12 9/16" 13 1/8" TCVT.811XLB45 Figure 44: Pipe dimensions. -
Page 32: Vent Offset Chart
APPENDIX Vent Offset Chart 12" PIPE 18 5/8" 18" 18" PIPE 22 7/8" 22 3/8" 24" PIPE 27 1/8" 26 1/2" 10 7/8" 48" PIPE 44 1/16" 43 1/2" 1 1/4Ó 11 3/8" ADDING AN ADJUSTABLE SECTION TO PIPE WILL INCREASE OFFSET BY 2 1/8"... -
Page 33: Quick Panel Removal For Valve Service
APPENDIX Quick Panel Removal for Valve Service FRONT PANEL BASE Figure 46: Front panel base. Figure 47: Clearing the securing tab. Figure 49: Access panel. Figure 48: Right panel. 1. Remove front panel base. Also remove rear panel base if Black Diamond Burner is tted (Figure 46). 2. -
Page 34: Rating Label Location
Rating Label Location NOTE: The Safety Label is located on a plate found in a slot between the left hand side lintel and the left hand side window frame. This plate is attached to the side casing with a cable. 5055.5401-A TCWS.54CODE_041115-36... - Page 35 TCWS.54CODE_041115-36 5055.5401-A...
- Page 36 © 2015 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For Technical Support, please contact your retailer. www.townandcountry replaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
