Town & Country Fireplaces TCWS.54CE SERIES C Installation And Operating Instructions Manual

Series c modular direct vent fireplace
Hide thumbs Also See for TCWS.54CE SERIES C:
Table of Contents

Advertisement

Quick Links

INSTAllER: leave this manual with the appliance.
CONSUmER: Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly, a fire or
explosion may result causing property damage,
personal injury or death.
FOR YOUR SAFETY
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
WhAT TO DO IF YOU SmEll GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier call
the fire department.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certified kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room.
TCWS.54.CE 110110-40
TCWS.54CE
INSTAllATION
AND OPERATING
INSTRUCTIONS
mODEl
TCWS.54CE
SERIES C
mODUlAR DIRECT VENT
FIREPlACE
5056.42521

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TCWS.54CE SERIES C and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TCWS.54CE SERIES C

Summary of Contents for Town & Country Fireplaces TCWS.54CE SERIES C

  • Page 1 INSTAllER: leave this manual with the appliance. CONSUmER: Retain this manual for future reference. WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. FOR YOUR SAFETY Installation and service must be performed by a qualified installer, service agency or the TCWS.54CE...

  • Page 2: Table Of Contents

    Table of Contents Caution ................... 3 Safety ..................... 3 Important Note for the Commonwealth of Massachusetts: ..... 4 Fireplace Dimensions ..............5 Minimum Clearances to Combustible Material ....... 5 Installation Requirements ............... 6 Manufactured (Mobile) Home ............6 Window Frame Removal ..............6 Standoffs..................

  • Page 3: Caution

    Caution FOR YOUR SAFETY - Do not install or operate your Town & Country fireplace without first reading and understanding this manual. Any installation or operational deviation from the following instructions voids the Town & Country Fireplaces Warranty and may prove hazardous.

  • Page 4: Important Note For The Commonwealth Of Massachusetts

    Important Note for the Commonwealth of massachusetts: From Massachusetts Rules and Regulations 248 CMR 5.08: For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied.

  • Page 5: Fireplace Dimensions

    Fireplace Dimensions Fig. #1 73 7/8” 73 7/8” 22 5/8” 55” 28 5/8” 17 3/4” 29 3/4” 11 3/8” 53 5/8” 53 5/8” minimum Clearances to Combustible material Fig. #2 NON-COMBUSTIBLE ZONE. COMBUSTIBLE FRAMING AND STEEL FRAMING DO NOT INSTALL ANY COMBUSTIBLE MATE- FINISH WALL ABOVE STANDOFFS RIAL, ELECTRICAL WIRING OR GAS PLUMBING STANDOFFS...

  • Page 6: Installation Requirements

    Installation Requirements The Town & Country Fireplace installation and venting must conform to the current CAN/CGA-B149 installation code (in Canada) or the current National Fuel Gas Code, ANSI Z223.1 (in the USA), and approved per local codes. Only qualified (licensed or trained) personnel should install this product.

  • Page 7: Standoffs

    Standoffs The standoffs are shipped loose Fig. #6 inside the fireplace and must be TOP STANDOFFS installed on the top and the side of the fireplace as shown in Fig. #6. Do this once the fireplace is on site and in position. SIDE STANDOFF (THIS SIDE ONLY)

  • Page 8: Framing And Finishing

    Framing and Finishing Note: The fireplace should be in place Chase Insulation: position. Secure the steel frame to the framing When installing this and venting installed before framing in or brackets on each side of the unit. Ensure that fireplace against a non-insulated exterior wall building an enclosure around the unit.
  • Page 9 Fig. #9 Fig. #9A NON-COmBUSTIBlE BOARD DETAIl IF THE BACKER BOARD IS NOT TO BE FINISHED WITH OTHER NON-COMBUS- TIBLE MATERIAL SUCH AS TILES, IT IS NON-COMBUSTIBLE RECOMMENDED THAT TOP SECTIONS BOARD OF BOARD SUPPLIED WITH FRAMING KIT BE REPLACED WITH A SINGLE SHEET OF NON-COMBUSTIBLE BOARD.

  • Page 10: Steel Stud Framing Kit

    Steel Stud Framing Kit TCWS.54FRKIT Each Kit Contains: Item Part # Description Qty. 5049.9912 SCREW, WAFER #8 x 1/2 8293.4 STUD, SIDES 55” L 8293.2 STUD, OUTER SIDES 55” L 8293 STUD, UPPER/LOWER 37 5/8” L 8293.6 INNER CROSS BRACE 56 5/8”...
  • Page 11 NOTE: Sheet metal parts have sharp edges, use caution when handling. 1. Frame Assembly • Place 2 of #4 together as a top. • Place 1 of #6 into the joint with the long edge facing up. Align the 3 holes and screw together with wafer screw #1. •...
  • Page 12 2. Attach the Assembled Frame to the Fig. #13 Unit • Attach the framing kit to the unit. (Fig. #13). • Align the assembled frame to the unit framing brackets. (Fig #14) Attach at the fastening points through the access holes in the outer side studs (3).

  • Page 13: Maestro Control

    Fig. #16 maestro Control – Plumbing and Electrical The gas control system is located on the right hand side of the firebox behind an access panel and the decorative firebox panel (if installed). The fireplace is operated via a wall switch and a hand held remote control unit.

  • Page 14: Standing Pilot Function

    9. Route the communication cable as required to the wall control electrical box. Fig. #20 10. Attach the communication cable to the wall control. (Fig. #20) 11. Insert the 4 supplied “AA” batteries into the battery pack and connect to wall control. (Fig.

  • Page 15: Gas Pressure Check

    Gas Supply Caution: The gas line should be installed by a qualified service person in accordance with all building codes. This section is intended as a guide for qualified technicians installing this appliance. Consult local and/or national building codes before proceeding. GAS VALVE INLET Gas supply line access holes are located at the top and left sides of the Control Box.

  • Page 16: Venting

    Venting Before installing venting for this unit, the installer should read these instructions to insure that the proper vent configuration has been selected. Use only Town and Country Termination kits #: TCVT.RTA - Roof Termination Kit Vent system components approved for use with the Town and Country Fireplace are shown in Fig.

  • Page 17: Roof Termination Venting Chart

    Roof Termination Venting Chart Various combinations of vent runs may be Fig. #26 used. Refer to Fig. #26 for details. For op- timum performance and flame appearance, MAX. keep the vent length to a minimum and limit the number of elbows. Connections between each vent system component must be tightly joined, secured with sheet metal screws and sealed.
  • Page 18 Ceiling Opening: Fig. #27 Determine the exact position of the fireplace so that the vent pipe is centred (if possible) between two building framing members. Lay out the vent system path, minimizing the number of elbows and length of vent. Consult your local building codes prior to proceed- 14 1/2"...

  • Page 19: Roof Vent Terminal

    Roof Vent Terminal: Place the roof flashing over top of the vent pipe and seal it to the roof using the meth- ods and materials appropriate for the type of roof on the building. Shingle roof example shown. (Fig. #29) Place the storm collar down over the vent pipe until it is level.

  • Page 20: Vent Terminal Clearance

    Vent Terminal Clearance Fig. #30 Minimum clearances to the vent terminal must be maintained as shown VENT TERmINAl mINImUm ClEARANCES in figure #33 & 34. Measure clearances to the nearest edge of termina- TO ADJACENT STRUCTURES tion hood. NOTE: Vent terminal must not be recessed NOTE: lOCAl CODES OR REGUlATIONS mAY REQUIRE...

  • Page 21: Vent Pipe Sealant

    Vent Pipe Sealant Fig. #32 APPROVED “HIGH TEMP.” VENT PIPE SELF-ADHESIVE TAPE (SUPPLIED) All outer joints of the vent pipe must be sealed with the approved "High Temperature" self- adhesive aluminium tape provided. Wrap the tape completely around the joint and press firmly in place.

  • Page 22: Vent Restrictor Adjustment

    Vent Restrictor Adjustment The vent restrictor is located on the underside of the firebox top. The unit leaves the fac- Fig. #33 tory with the vent restrictor open. The restrictor is built into the appliance for secondary air WAll AND ROOF flow adjustment.

  • Page 23: Firebox Panels Installation

    Firebox Panels Installation Fig. #35 Remove the 2 inner screws from the upper heat shield. (Fig. #35) Fig. #36 Slip the top porcelain panel into the lip at the front of the firebox and tip the panel up to align with the screw holes. Secure with the previously removed screws.

  • Page 24: Finishing Touch Trim Kit Instructions

    Finishing Touch Trim Kit Instructions Place two smaller magnets on back of each side rail. Place two larger magnets on back of the top and bottom rails. Attach the side rails. Even the ends up with the door frame. Attach the top and bottom rails and adjust so mitres are even at the corners. Place TC magnetic logo in bottom right corner.

  • Page 25: Lighting Instructions

    lighting Instructions FOR YOUR SAFETY READ BEFORE LIGHTING - Do not touch any electric switch; do not use any phone in your WARNING: If you do not follow these instructions building. - Immediately call your gas supplier from a neighbour's phone. exactly, a fire or explosion may result causing Follow the gas supplier's instructions.

  • Page 26: Maestro Control System

    maestro Control System Remote Control Initial Setup This fireplace is supplied with a wall control Fig. #40 Fig. #41 and hand held remote control. Please note only genuine Town & Country Fireplace wall controls and hand held remote controls can be used on this fireplace.

  • Page 27: Maestro Control System - Operation

    Childproof lock Fig. #43 An additional feature of this remote control is the childproof lock. To activate this system press and hold the timer and thermostat buttons for approx. 5 seconds until the “lock” symbol appears on the remote display. (Fig. #43) The remote control hand set buttons are now locked and the lock symbol will reappear every time a button is pressed on the remote control until the timer and thermostat buttons are pressed and held again.
  • Page 28 Program mode Fig. #45 Fig. #47 (To preset up to two on and off periods per day) The program mode has two settings for weekdays and two for weekends. The hand held remote comes with the following pre programmed settings: Weekday Program (Monday through Friday) Program one (P1) turns ON at 7:00am and...
  • Page 29 Thermostatic mode Fig. #49 Fig. #51 THERMOSTATIC MODE THERMOSTATIC BUTTON (Only for use where permitted) BUTTON (Operates the fireplace within a set tem- perature range) The fireplace is shipped with thermostatic mode function deactivated. If this function is permitted for use in your area it can be activated by depressing the recessed button on the underside of the hand held remote.

  • Page 30: Maintenance

    APPENDIX maintenance CAUTION: Turn off gas and electrical power supply (if applicable) and allow ample time for unit to cool before servicing appliance. It is recommended that the fireplace and its venting should be inspected at least once a year by a qualified service person. Glass Panel: Warning: Do not operate fireplace with glass panel removed, cracked or broken.

  • Page 31: Tcws.54Ce Replacement Parts

    TCWS.54CE Replacement Parts (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEm DESCRIPTION PART NO. ITEm DESCRIPTION PART NO. TCWS BODY ASSEmBlY ......TCWS.54CE PANEl SETS BLACK PORCELAIN ......TCPN.775.C FRAmE & GlASS ASSEm .....TCWS.8220 BROWN PORCELAIN ....TCPN.775CB.C FRAmING KIT .........TCWS.54FRKIT FINIShING TOUCh TRIm KIT ..TCWS.8122 *NOT SHOWN MAESTRO CONTROL ASSEMBLY - See Page 32 KIT CONTENTS:...

  • Page 32: Replacement Parts - Maestro Control System

    Replacement Parts – maestro Control System (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEm ..DESCRIPTION ..........PART NO. ITEm ..DESCRIPTION ..........PART NO. #1..CONTROl ASSEmBlY KIT ....TCRP.9271A #5..COmmUNICATION CABlE KIT ..5005.062 #2..BUlKhEAD ASSEmBlY KIT ....TCRP.9284 #6..

  • Page 33: Wiring Diagram

    Wiring Diagram Fig. #54 TCWS.54CE 110110-40...

  • Page 34: Roof Termination Kit

    Roof Termination Kit TCVT.RTA Fig. #55 16 1/2" VERTICAL TERMINATION CAP TCVT.9365 9" STORM COLLAR TC42.90665 CEILING FIRESTOP ROOF SUPPORT TCVT.THIMA BRACKET TCVT.93915 TCWS.54CE 110110-40...

  • Page 35: Vent Pipe Dimensions

    Vent Pipe Dimensions Fig. #56 11" 12" PIPE ..10 1/4" 18" PIPE ..16 1/4" 24" PIPE ..22 1/4" 48" PIPE ..46 1/4" 10 15/16" 9 1/2" TCVT.811X12ADJ 11 1/8" TCVT.811X _ _ 12 9/16" 13 1/8" TCVT.811XLB45 TCWS.54CE 110110-40...

  • Page 36: Vent Offset Chart

    Vent Offset Chart Fig. #57 12" PIPE 18 5/8" 18" 18" PIPE 22 7/8" 22 3/8" 10 7/8" 24" PIPE 27 1/8" 26 1/2" 48" PIPE 44 1/16" 43 1/2" 1 1/4Ó 11 3/8" ADDING AN ADjUSTABLE SECTION TO PIPE WILL INCREASE OFFSET BY 2 1/8"...

  • Page 37: Quick Panel Removal For Valve Service

    Quick Panel Removal for Valve Service Fig. #58 1. Remove front panel base. Also remove FRONT PANEl BASE rear panel base if Black Diamond Burner is fitted.(Fig. #58) 2. Push up on the heat shield, at the right end of the unit near the middle, enough to clear the securing tab.
  • Page 38 TCWS.54CE 110110-40...

  • Page 39: Safety Label Location

    Safety label location NOTE: The Safety Label is located on a plate found in a slot between the left hand side lintel and the left hand side window frame. This plate is attached to the lintel with a cable. TCWS.54CE 110110-40...
  • Page 40 Technical support: 1-250-748-1184 Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9l 6V8 Printed in Canada...
