INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly, a fi re or
explosion may result causing property damage,
personal injury or death.
FOR YOUR SAFETY
Installation and service must be performed
by a qualifi ed installer, service agency or the
gas supplier.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier call
the fi re department.
Do not store or use gasoline or other fl ammable
vapors and liquids in the vicinity of this or any
other appliance.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certifi ed kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room.
TCWS.54.CE2 200810-40
TCWS.54CE2
INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL
TCWS.54CE2
SERIES C
MODULAR DIRECT VENT
FIREPLACE
5056.42521.1
Advertisement
Table of Contents
Related Manuals for Town & Country Fireplaces TCWS.54CE2
Summary of Contents for Town & Country Fireplaces TCWS.54CE2
- Page 1 FOR YOUR SAFETY Installation and service must be performed by a qualifi ed installer, service agency or the TCWS.54CE2 gas supplier. INSTALLATION WHAT TO DO IF YOU SMELL GAS AND OPERATING •...
-
Page 2: Table Of Contents
Maestro Control System ............... 26 Remote Control Initial Setup ............26 Maestro Control System - Operation ..........27 Maintenance ................. 30 TCWS.54CE2 Replacement Parts ..........31 Replacement Parts – Maestro Control System ......32 Wiring Diagram ................33 Roof Termination Kit ..............34 Vent Pipe Dimensions .............. -
Page 3: Caution
This appliance must not be connected to a chimney fl ue serving a separate solid fuel burning appliance. TCWS.54CE2 200810-40... -
Page 4: Important Note For The Commonwealth Of Massachusetts
Important Note for the Commonwealth of Massachusetts: From Massachusetts Rules and Regulations 248 CMR 5.08: For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above fi nished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfi ed. -
Page 5: Fireplace Dimensions
S T I B L E H C O M B U Mantel support ............4 in. (102 mm) Vertical vent pipe ..........1 3/4" in. (45 mm) UNIT MAY BE RECESSED UP TO 6” WITH NONCOMBUSTIBLE MASONRY TYPE MATERIAL TCWS.54CE2 200810-40... -
Page 6: Installation Requirements
Installation Requirements The Town & Country Fireplace installation and venting must conform to the current CAN/CGA-B149 installation code (in Canada) or the current National Fuel Gas Code, ANSI Z223.1 (in the USA), and approved per local codes. Only qualifi ed (licensed or trained) personnel should install this product. -
Page 7: Standoffs
The minimum clearances from the fi replace to combustible surfaces must be adhered to and are shown in Fig. #2 and Fig. #3. Fig. #7 EXAMPLES OF COMMON LOCATIONS SEE FIG #11 FOR DIMENSIONS TCWS.54CE2 200810-40... -
Page 8: Framing And Finishing
Framing and Finishing Note: The fi replace should be in place position. Secure the steel frame to the framing Chase Insulation: When installing this and venting installed before framing in or brackets on each side of the unit. Ensure that fi replace against a non-insulated exterior wall building an enclosure around the unit. - Page 9 (NOT INCLUDED IN KIT) Fig. #11 MINIMUM COMBUSTIBLE 80 5/8" FRAMING DIMENSIONS 33" 46 1/4" 74 1/4" INCLUDING SHEETROCK 74 1/4" 55 1/4" 114" 22 1/16" 11 5/16" 5/8" 74 1/4" NOTE: FIREPLACE SHOULD BE IN ITS FINAL LOCATION BEFORE FRAMING. TCWS.54CE2 200810-40...
-
Page 10: Steel Stud Framing Kit
Steel Stud Framing Kit TCWS.54FRKIT Each Kit Contains: Item Part # Description Qty. 5049.9912 SCREW, WAFER #8 x 1/2 8293.4 STUD, SIDES 55” L 8293.2 STUD, OUTER SIDES 55” L 8293 STUD, UPPER/LOWER 37 5/8” L 8293.6 INNER CROSS BRACE 56 5/8”... - Page 11 Turn the framing kit over and secure all studs from the back. Fig. #12 FRONT VIEW (slightly angled) SCREW THROUGH 3 LAYERS BEND OUT FRAMING TABS TO FRONT LONG EDGE UP WIDE FACE FORWARD SLOTS UP SCREW INTO SIDE TCWS.54CE2 200810-40...
- Page 12 2. Attach the Assembled Frame to the Fig. #13 Unit • Align the assembled frame to the unit framing brackets. (Fig #13) Attach at the fastening points through the access holes in the outer side studs (3). 3. Secure to Existing Framing •...
-
Page 13: Maestro Control
(Part # 5005.064) available from your dealer). WARNING: The control box heat shield and access panel must be replaced. Failure to do so will overheat and cause premature failure of the control. OUTLET A/C ADAPTER GAS CONNECTION TCWS.54CE2 200810-40... -
Page 14: Standing Pilot Function
Fig. #20 9. Route the communication cable as required to the wall control electrical box. 10. Attach the communication cable to the wall control. (Fig. #20) 11. Insert the 4 supplied “AA” batteries into the battery pack and connect to wall control. (Fig. -
Page 15: Gas Pressure Check
Correct gas pressure requirement: SUPPLY Natural Gas Propane PRESSURE MANIFOLD Min. Pressure 5.0" WC 12.5" WC PRESSURE (For purpose of input adjustment) Max. Pressure 13.9" WC 13.9" WC Manifold Pressure Maximum 3.8" WC 11" WC Minimum 2.1" WC 5.5" WC TCWS.54CE2 200810-40... -
Page 16: Venting
Venting Before installing venting for this unit, the installer should read these instructions to insure that the proper vent confi guration has been selected. Use only Town and Country Termination kits #: TCVT.RTA - Roof Termination Kit Vent system components approved for use with the Town and Country Fireplace are shown in Fig. -
Page 17: Roof Termination Venting Chart
1 3/4 inches from any part of the vent pipe. Only 45º elbows can be used in this vent system. Maximum number of elbows is 2. MINIMUM VENT HEIGHT 4' MAX. 18” MIN BEFORE ELBOW TCWS.54CE2 200810-40... - Page 18 Fig. #27 Ceiling Opening: Determine the exact position of the fi replace so that the vent pipe is centred (if possible) between two building framing members. Lay out the vent system path, minimizing the number of elbows and length of vent. Consult your local building codes prior to proceed- 14 1/2"...
-
Page 19: Roof Vent Terminal
(Fig. #29) Seal screw heads and joint with caulking to prevent any moisture entering the venting system. Fig. #29 VERTICAL TERMINATION CAP (TCVT.9365) VENT PIPE MASTIC STORM COLLAR (TC42.90665) FLASHING NOTE: ADJUSTABLE FOR VARIOUS ROOF PITCHES, FROM FLAT ROOF TO 12/12 PITCH ROOF. TCWS.54CE2 200810-40... -
Page 20: Vent Terminal Clearance
Vent Terminal Clearance Fig. #30 Minimum clearances to the vent terminal must be maintained as shown VENT TERMINAL MINIMUM CLEARANCES in fi gure #30. Measure clearances to the nearest edge of termination TO ADJACENT STRUCTURES hood. NOTE: Vent terminal must not be recessed NOTE: LOCAL CODES OR REGULATIONS MAY REQUIRE... -
Page 21: Vent Pipe Sealant
All outer joints of the vent pipe must be sealed with the approved "High Temperature" self- adhesive aluminium tape provided. Wrap the tape completely around the joint and press fi rmly in place. Inner pipe does not need to be sealed. TCWS.54CE2 200810-40... -
Page 22: Vent Restrictor Adjustment
Vent Restrictor Adjustment The vent restrictor is located on the underside of the fi rebox top. The unit leaves the fac- Fig. #33 tory with the vent restrictor open. The restrictor is built into the appliance for secondary air WALL AND ROOF fl ow adjustment. -
Page 23: Firebox Panels Installation
(Fig. #39)(Proceed to step #7 if you are installing a TCWS.54NG03.C2 Black Diamond burner with this unit.) Place the other front panel piece at the rear of the fi rebox with the wide fl ange facing to the rear against the back panel. TCWS.54CE2 200810-40... -
Page 24: Finishing Touch Trim Kit Instructions
Finishing Touch Trim Kit Instructions Place two smaller magnets on back of each side rail. Place two larger magnets on back of the top and bottom rails. Attach the side rails. Even the ends up with the door frame. Attach the top and bottom rails and adjust so mitres are even at the corners. Place TC magnetic logo in bottom right corner. -
Page 25: Lighting Instructions
It is normal for fi replaces fabricated of steel to give off some expansion and/or contraction noises during the start up or cool down cycle. Similar noises are found with your furnace heat exchanger or cook stove oven. TCWS.54CE2 200810-40... -
Page 26: Maestro Control System
Maestro Control System Remote Control Initial Setup Fig. #40 This fi replace is supplied with a wall control Fig. #41 and hand held remote control. Please note only genuine Town & Country Fireplace wall controls and hand held remote controls can be used on this fi replace. -
Page 27: Maestro Control System - Operation
3. Press the OK button and the timer is set and the control is in countdown timer mode. 4. To exit the timer mode press the Program, Manual or Thermostat buttons. Please note that the fi rst press of the Manual button will turn the fi replace off. TCWS.54CE2 200810-40... - Page 28 Fig. #45 Program Mode Fig. #47 (To preset up to two on and off periods per day) The program mode has two settings for weekdays and two for weekends. The hand held remote comes with the following pre programmed settings: Weekday Program (Monday through Friday) Program one (P1) turns ON at 7:00am and...
- Page 29 5. The fi replace is now in thermostatic mode. To exit the thermostatic mode press the program, manual or timer buttons. Please note that the fi rst press of the manual button will turn the fi replace off. TCWS.54CE2 200810-40...
-
Page 30: Maintenance
APPENDIX Maintenance CAUTION: Turn off gas and electrical power supply (if applicable) and allow ample time for unit to cool before servicing appliance. It is recommended that the fi replace and its venting should be inspected at least once a year by a qualifi ed service person. Glass Panel: Warning: Do not operate fi replace with glass panel removed, cracked or broken. -
Page 31: Tcws.54Ce2 Replacement Parts
TCWS.54CE2 Replacement Parts (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. TCWS BODY ASSEMBLY ......TCWS.54CE FINISHING TOUCH TRIM KIT..TCRP.54WSTRIMKIT GLASS ASSEMBLY (c/w gasket) ..GLAS.2062ASSY ORIFICE (2pcs) ........5021.87 FRAMING KIT .........TCWS.54FRKIT MAIN GAS SUPPLY TUBES (3pcs) ..5019.223 PANEL SETS BURNER SUPPORT ........9498... -
Page 32: Replacement Parts - Maestro Control System
Replacement Parts – Maestro Control System (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM ..DESCRIPTION ..........PART NO. ITEM ..DESCRIPTION ..........PART NO. #1..CONTROL ASSEMBLY KIT ....TCRP.9271A #5..COMMUNICATION CABLE KIT ..5005.06 #2..BULKHEAD ASSEMBLY KIT ....TCRP.9284 #6.. -
Page 33: Wiring Diagram
Wiring Diagram Fig. #54 TCWS.54CE2 200810-40... -
Page 34: Roof Termination Kit
Roof Termination Kit TCVT.RTA Fig. #55 16 1/2" VERTICAL TERMINATION CAP TCVT.9365 9" STORM COLLAR TC42.90665 CEILING FIRESTOP ROOF SUPPORT TCVT.THIMA BRACKET TCVT.93915 TCWS.54CE 200810-40... -
Page 35: Vent Pipe Dimensions
Fig. #56 11" 12" PIPE ..10 1/4" 18" PIPE ..16 1/4" 24" PIPE ..22 1/4" 48" PIPE ..46 1/4" 10 15/16" 9 1/2" TCVT.811X12ADJ 11 1/8" TCVT.811X _ _ 12 9/16" 13 1/8" TCVT.811XLB45 TCWS.54CE2 200810-40... -
Page 36: Vent Offset Chart
Vent Offset Chart Fig. #57 12" PIPE 18 5/8" 18" 18" PIPE 22 7/8" 22 3/8" 10 7/ 24" PIPE 27 1/8" 26 1/2" 48" PIPE 44 1/16" 43 1/2" 1 1/4Ó 11 3/8" ADDING AN ADJUSTABLE SECTION TO PIPE WILL INCREASE OFFSET BY 2 1/8"... -
Page 37: Quick Panel Removal For Valve Service
Pg. 6. Reassemble in reverse order. WARNING: The control box shield, access Fig. #60 panel and gasket must be replaced. Failure to do so will overheat and cause premature failure of the control. Fig. #61 TCWS.54CE2 200810-40... - Page 38 TCWS.54CE 200810-40...
-
Page 39: Safety Label Location
Fireplace Products Ltd. des dommages matériels ou des blessures. Voir la notice de l’utilisateur qui accompgne l’appareil. Pour de l’aide ou des renseignements supplémentaires, consultez un installateur, un technicien agréé ou le fournisseur de gaz. 280710 5050.720371 1-TCWS.54CE2 TCWS.54CE2 200810-40... - Page 40 Technical support: 1-250-748-1184 Web site: www.townandcountryfi replaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
