Printhead Replacement, cont.
7
Connect the two cables to the
replacement printhead.
9
Turn the printhead lift lever counter-
clockwise so the magnet engages the
printhead bracket.
Intermec EasyCoder PM4i—User's Guide (IPL version)
Chapter 10— Maintenance
8
Put back the printhead in reverse order
and check that the printhead cables run
freely.
10
Load a new supply of media and ribbon,
as described earlier in this manual.
77
