- Page 1 AU-D3-192 Coaxial/Optical to Left/Right Stereo Audio Converter - 192kHz OPERATION MANUAL...
- Page 2 Table of Contents Introduction Features Operation Controls and Functions Front Panel Diagram Rear Panel Diagram Connection Diagram...
- Page 3 1. Introduction The AU-D3-192 is designed to convert either Coaxial or Optical signals from a digital stereo signal to analogue stereo audio. With an advanced 192kHz sampling rate, this unit is particularly useful for enhancing sound reproduction when connecting digital sources to analogue amplifiers.
-
Page 4: Operation Controls And Functions
3. Operation Controls and Functions Front Panel OPTICAL DC 5V COAX 3.1 Front Panel 1. Input Selection: Use this switch to select input from Coaxial or Optical input ports. 2. Power: Plug the power supply into AU-D3 unit and connect the adaptor to AC wall outlet. COAX OPTICAL 3.2 Rear Panel... -
Page 5: Connection And Installation
4. Connection and Installation Input Ports 1 x Coaxial RCA jack and 1 x Optical (Toslink) port Output Ports 1 x Left & Right Stereo RCA ports Power Supply Dimensions (mm) 42(W) x 40.5(D) x 22(H) Weight (g) Chassis Material Plastic Colour Black...
