INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or death.
FOR YOUR SAFETY
Installation and service must be performed by
a qualifi ed installer, service agency or the gas
supplier.
What To Do If You Smell Gas
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier
from a neighbour's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier
call the fi re department.
Do not store or use gasoline or other fl ammable
vapors and liquids in the vicinity of this or any
other appliance.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA only)
or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a
certifi ed kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Visit www.townandcountryfi replaces.com for the most recent version of this manual
150817-40
TCWS54D
INSTALLATION
MANUAL
MODEL: TCWS54
SERIES D
MODULAR DIRECT VENT
FIREPLACE
TCWS54_D.Ver2
- Version 2
5056.4252155D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TCWS54D and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TCWS54D

Summary of Contents for Town & Country Fireplaces TCWS54D

  • Page 1 FOR YOUR SAFETY Installation and service must be performed by a qualifi ed installer, service agency or the gas supplier. TCWS54D - Version 2 What To Do If You Smell Gas INSTALLATION • Do not try to light any appliance.

  • Page 2: Table Of Contents

    Vent Pipe Sealant ..............25 Removing LED light wire retaining clip ......9 Vent Restrictor Adjustment ............. 26 TCWS54D Minimum Combustible Framing Dimensions ..10 Roof Termination Kit ..............27 Non - combustible board area ......... 10 Vent Pipe Dimensions ............. 28 Steel Stud Framing Kit ............

  • Page 3: Caution

    Caution FOR YOUR SAFETY - Do not install or operate your Town & Country replace without rst reading and understanding this manual. Any installation or operational deviation from the following instructions voids the Town & Country Fireplaces Warranty and may prove hazardous. This appliance and its individual shut off valve must be disconnected from gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5 kPa).

  • Page 4: Important Note For The Commonwealth Of Massachusetts

    Important Note for the Commonwealth of Massachusetts From Massachusetts Rules and Regulations 248 CMR 5.08: For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above nished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satis ed.

  • Page 5: Fireplace Dimensions

    Mantel support ............. 4 in. (102 mm) 29 3/4" E A R T H Vertical vent pipe .......... 1 3/4" in. (45 mm) S T I B L E H C O M B U Figure 3: TCWS54D Minimum mantel clearances. 5056.4252155D TCWS54_D 021216-40...

  • Page 6: Installation Requirements

    Installation Requirements The Town & Country Fireplace installation and venting must conform to the current CAN/CGA-B149 installation code (in Canada) or the current National Fuel Gas Code, ANSI Z223.1 (in the USA), and approved per local codes. Only quali ed (licensed or trained) personnel should install this product.

  • Page 7: Top Standoffs

    TOP STANDOFFS HANDLE CONTROL Figure 7: TCWS54D Stand offs. Locating The Fireplace In planning the installation for the replace, it is necessary to determine where the unit is to be installed, location of vent system and where gas supply piping may be plumbed. Various installations are possible, such as, into an existing wall, a corner, a built-in wall or a wall projection (Figure 9).

  • Page 8: Framing And Finishing

    Flat side of frame 55 1/16" NOTE: After frame is assembled, make sure to have the side of the frame without the screw holes facing toward the inside of the room. Figure 9: TCWS54D with steel frame. TCWS54_D 150817-40 5056.4252155D...

  • Page 9: Removing Led Light Wire Retaining Clip

    Removing LED light wire retaining clip NOTE: This fi replace ships with the light wiring secured in retaining clips. Remove light NOTE: This fi replace ships with the light wiring secured in retaining clips. Remove light wiring from the retaining clip before installing and walling up the fi replace. wiring from the retaining clip before installing and walling up the fi...

  • Page 10: Tcws54D Minimum Combustible Framing Dimensions

    Finishing material must not pro- trude past framing anges under ANY circumstance. The safety screen and the window, with trim tted, must be able to move freely. Figure 12: TCWS54D Reccessed installation details. Figure 13: Non-combustible board location. 81 11/16" 31 1/2"...

  • Page 11: Steel Stud Framing Kit

    Steel Stud Framing Kit BEND OUT FRAMING TABS TO FRONT SLOPED SIDE DOWN SCREW INTO SIDE Figure 15: TCWS54D Framing kit. FRONT VIEW (slightly angled) Each Kit Contains: Item Description Qty. Item Description Qty. SCREW, WAFER #8 x 1/2 INNER CROSS BRACE...

  • Page 12: Frame Assembly

    Frame Assembly 1. On a at surface, place 2 upper/lower studs (#4). One is to become the top-most horizontal stud and one is to become the bottom-most horizontal stud. Stand all pieces up on their narrow ends throughout assembly. 2. Place 3 center studs (#6) perpendicular to, and below the above horizontal beam at the beams 3 middle-most securing points.

  • Page 13: Fixed Lintel

    Attach the Assembled Frame and fireplace to the combustible framing. Bend out the tabs 90 degrees before inserting the unit into its framed housing (Figure 17). Attach the assembled framing kit to the Fireplace. Secure the frame assembly to the wood frame through the tabs (Figure 18). Install Non-Combustible Board Use drywall screws, to install the non-combustible board.

  • Page 14: Fireplace Facing Allowance

    NON-COMBUSTIBLE FINISH MATERIAL installed with a 4 1/2 inch recess, See BUILDING MATERIAL MAY NOT “Figure 12: TCWS54D Reccessed installation EXTEND PAST THIS POINT details.” on page 10. The replace can accommodate facing material thickness from 1/2 of an inch to 2 1/4 inches if installing ush.
  • Page 15 Lift the control box heat shield from the bottom opening to clear the location tabs and pull inwards. Lower the heat shield to clear the top tab. Lift the heat shield and locate on the screw above the opening. Note: The flex lines may have to be pushed down to allow the shield to be lowered enough to clear the top tab. Connect 110 V.

  • Page 16: Wall Switch And Remote Control

    Wall Switch and Remote Control TO FIREPLACE Figure 29: Wall switch - battery side. Figure 28: Wall switch - interface side. Figure 27: Town and Country 4. Press the ON/OFF button of the wall switch. remote unit. Once the wall unit Insert a straightened paper clip beeps 3 times, the remote is pro- Linking the remote control...

  • Page 17: Selecting Natural Vent And Power Vent Modes

    Selecting Natural Vent and Power Vent Modes The NV / PV (Natural Vent / Power Vent) switch (Figure 30) on the interface board (Figure 26) is set according to which type of evacuating vent system is present. If the replace is vented with- out the assistance of a power vent, the switch must be set to “NV”.

  • Page 18: Home Automation

    Home Automation The home automation feature supplied with this replace is capable of controlling the ame and light on/off function with the use of a dry contact relay common to home automation systems. Furthermore, the ame and light level may be modu- lated from high to low using the 0 - 10 volt analog output avail- able on most home automation systems.

  • Page 19: Gas Supply

    Gas Supply Caution: The gas line should be installed by a quali ed service person in accordance with all building codes. This section is intended as a guide for quali ed technicians installing this appliance. Consult local and / or national building codes before proceeding.

  • Page 20: Venting

    Venting Before installing venting for this unit, the installer should read these instructions to insure that the proper vent con guration has been selected. Use only Town and Country Termination kits #: TCVT.RTA - Roof Termination Kit For vent system components approved for use with the Town and Country Fireplace, See “Vent System Components”...

  • Page 21: Roof Termination Venting

    Roof Termination Venting Ceiling Opening: 14 1/2” 1. Determine the exact position of the replace so that the vent pipe is cen- tered (if possible) between two building framing members. Lay out the vent system path, minimizing the number of elbows and length of vent. Consult your local building codes prior to proceeding.

  • Page 22: Roof Termination Venting Chart

    Roof Termination Venting Chart This replace can be roof terminated using either the TCVT. PVCV power vent kit or the TCVT.RTA direct vent kit. Please see the instructions supplied with the kit forinstallation details. Various combinations of vent runs may be used. Refer to Figure 36 MAX.

  • Page 23: Roof Vent Terminal

    Roof Vent Terminal: 1. Place the roof ashing over top of the vent pipe and seal it to the roof using the methods and materials appropriate for the type of roof on the building. Shingle roof example shown (Figure 37). 2.

  • Page 24: Vent Terminal Minimum Clearances

    Vent Terminal Minimum Clearances FIXED CLOSED OPEN- FIXED ABLE CLOSED OPEN- ABLE AREA WHERE TERMINAL GAS METER VENT TERMINAL AIR SUPPLY INLET IS NOT PERMITTED *12 inches (30 cm) min. Clearances above grade, veranda, porch, deck, or balcony *12 inches (30 cm) min. Clearance to window or door that may be opened 12 inches (30 cm) min.

  • Page 25: Vent Terminal Clearance

    SELF-ADHESIVE TAPE (SUPPLIED) Figure 40: TCWS54D Sealing vent joints. All outer joints of the vent pipe must be sealed with the approved "High Temperature" self-adhesive alumin- ium tape provided. Wrap the tape completely around the joint and press rmly in place. Inner pipe does not need to be sealed.

  • Page 26: Vent Restrictor Adjustment

    Vent Restrictor Adjustment The vent restrictor is located on the underside of the rebox top. The unit leaves the factory with the vent restrictor open. The restrictor is WALL AND ROOF built into the appliance for secondary air ow adjustment. Adjustment TERMINATION enables tuning the air ow for optimum ame appearance and perfor- RESTRICTOR POSITION...

  • Page 27: Roof Termination Kit

    Roof Termination Kit VERTICAL 16 1/2" TERMINATION CAP TCVT.9365 9" STORM COLLAR TC42.90665 CEILING FIRESTOP TCVT.THIMA ROOF SUPPORT BRACKET TCVT.93915 Figure 43: Roof terminator kit. 5056.4252155D TCWS54_D 021216-40...

  • Page 28: Vent Pipe Dimensions

    Vent Pipe Dimensions 11" 12" PIPE ..10 1/4" 18" PIPE ..16 1/4" 24" PIPE ..22 1/4" 48" PIPE ..46 1/4" 10 15/16" 9 1/2" TCVT.811X12ADJ 11 1/8" TCVT.811X _ _ 13 13/16" 12 9/16" 8 5/16" 1 5/16"...

  • Page 29: Vent Offset Chart

    Vent Offset Chart 10 7/8” 12" PIPE 18 5/8" 18" 18" PIPE 22 7/8" 22 3/8" 24" PIPE 27 1/8" 26 1/2" 48" PIPE 44 1/16" 43 1/2" 1 1/4” 11 3/8” ADDING AN ADJUSTABLE SECTION TO PIPE WILL INCREASE OFFSET BY 1 1/4”...

  • Page 30: Firebox Panels Installation

    Firebox Panels Installation Installation note: The panel set comes with an upper panel. When installing firebox panels into a “C” series fireplace, use this upper panel. When installing firebox panels into a “D” series fireplace, do not install the upper panel as this panel will obscure the LED light fixtures.

  • Page 31: Finishing Touch Trim Kit Instructions

    Finishing Touch Trim Kit Instructions 1. Place two smaller magnets on back of each side rail. 2. Place two larger magnets on back of the top and bottom rails. 3. Attach the side rails. Even the ends up with the door frame. 4.

  • Page 32: Linking Remote Handset To The Fireplace

    Linking Remote Handset to the Fireplace Town & Country Fireplaces can be operated remotely by using the remote handset that came with the re- place, and by using a BlueTooth enabled apple mobile device and the “TC Fire” app which can be down- ®...

  • Page 33: Step 2: Procedure For Linking / Pairing The Wall Switch To Remote Handset

    Step 2: Procedure for linking / pairing the wall switch to remote handset 1. Press and release Program button on the wall switch once (Figure 51). 2. You will hear 3 beeps from the wall switch. 3. Press and release the on/off button (Figure 52) on the remote handset (within 60 sec.) 4.

  • Page 34: Maintenance

    Maintenance CAUTION: PILOT Turn off gas and electrical power supply (if applicable) and allow ample time for unit to cool before servicing appliance. It is recommended that the replace and its venting should be inspected at least once a year by a quali ed service person. Glass Panel: FLAME SENSOR PILOT FLAME...

  • Page 35: Tcws.54D Replacement Parts

    TCWS.54D Replacement Parts (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. #1 TCWS BODY ASSEMBLY ........TCWS.54D *#5 FINISHING TOUCH TRIM KIT ....... TCWS.8265-A #2 GLASS ASSEMBLY (c/w gasket) ..... GLAS.2062ASSY #6 ORIFICE (2pcs) ............ 5022.78-A #3 FRAMING KIT ..........TCWS.8267-B #7 MAIN GAS SUPPLY TUBES (3pcs) .......

  • Page 36: Replacement Parts - Valve Control System

    Replacement Parts – Valve Control System (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. #1 CONTROL ASSEMBLY KIT ......TCCV.95755-B #4 TEST FITTING ............5019.104 #2 BULKHEAD ASSEMBLY KIT ......TCRP.8133 #5 WALL SWITCH ASSEMBLY KIT ......TCRP.WSA #3 COMMUNICATION CABLE KIT ......

  • Page 37: Wiring Diagram

    Wiring Diagram 5056.4252155D TCWS54_D 021216-40...

  • Page 38: Quick Panel Removal For Valve Service

    Quick Panel Removal for Valve Service 1. Remove front panel base (Figure 54). Also remove rear panel base if Black Diamond Burner is tted. 2. Push up on the heat shield, at the right end of the unit near the middle, enough to clear the securing tab (Figure 55). FRONT PANEL BASE Figure 54: Front panel base.

  • Page 39: Rating Label

    Rating Label NOTE: The Rating Label is located on a plate found in a slot between the left hand side lintel and the left hand side window frame. This plate is attached to the lintel with a cable. VENTED GAS FIREPLACE - NOT FOR USE WITH SOLID FUEL FOYER AU GAZ À...
  • Page 40 © 2017 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright law. For technical support, please contact your retailer. Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
