Coding Transmitter
Returning to main screen
The "Code Transmitter" menu will now be shown.
Press EXIT to return to the MAIN SCREEN and test the
transmitter.
NOTE: To edit the other settings, refer to Transmitter
editing.

Transmitter editing

Display transmitter record
Using one of the methods below, display the required
transmitters details.
Step 1. Navigating to "edit transmitter" menu
1. Press NEXT to navigate to the Menu 1 (Fig. 20).
2. Press SET to enter the transmitter edit procedure.
3. Press NEXT to enter transmitter list and edit mode.
Step 2. Editing button function fi eld
1. Press NEXT or PREV to move the cursor to the left or
right and between the top and bottom lines to select
the desired fi eld.
2. Press UP or DOWN to change the displayed value
(Fig. 25). The available functions are shown below.
Selecting OFF will prevent the opener responding to
that button.
Available functions
VAC (Vacation Mode) LGT (Courtesy Light)
STP (Stop) OPN (Open)
CLS (Close) SWP (Swipe)
PED (Pedestrian access) OSC (Open/Stop/Close)
OFF (No action)
3. Press SET to save changes or press NEXT or PREV to
move to next fi eld. The example in (Fig. 25) shows
that PED is assigned to the transmitter button 2. The
transmitter in the example is transmitter number 12
which has the ID label AB Smith.
NOTE: If all button functions are set to OFF, when
SET is pressed, the opener will prompt to confi rm if
the transmitter is to be deleted. Press SET to delete or
EXIT to continue editing.
Owner Installation Instructions NeoSlider™ - Sliding Gate Opener NES-24V1
fi g 25
fi g 26
fi g 27
fi g 28
