Sea Tel ST144-21 Installation And Operation Manual

Dual c/quad ku-band tvro
Hide thumbs
Table of Contents

Advertisement

Quick Links

Sea Tel, Inc.
4030 Nelson Avenue
Concord, CA 94520
Tel: (925) 798-7979
Fax: (925) 798-7986
Web:
http://www.cobham.com/seatel
Sea Tel Inc is also doing business as Cobham Antenna Systems
August 2, 2012
INSTALLATION AND OPERATION MANUAL
FOR SEA TEL MODEL
ST144-21 DUAL C/QUAD KU-BAND TVRO ANTENNA
Sea Tel Europe
Unit 1, Orion Industrial Centre
Wide Lane, Swaythling
Southampton, UK S0 18 2HJ
Tel: 44 (0)23 80 671155
Fax: 44 (0)23 80 671166
Web:
http://www.cobham.com/seatel
Document. No. 135635 Revision B
