Sea Tel ST24 Operation And Installation Manual

Satellite tv receive-only antenna
Hide thumbs
Table of Contents

Advertisement

Quick Links

Antenna Model:
Sea Tel, Inc.
4030 Nelson Avenue
Concord, CA 94520
Tel: (925) 798-7979
Fax: (925) 798-7986
Web: :
www.cobham.com\seatel
Sea Tel Inc is also doing business as Cobham Antenna Systems
September 26, 2011
OPERATION AND INSTALLATION
ST24 SATELLITE TV RECEIVE-ONLY ANTENNA
Please record your Antenna Serial Number Here;
_______
Serial Number:
FOR SEA TEL MODEL
_______________
Sea Tel Europe
Unit 1, Orion Industrial Centre
Wide Lane, Swaythling
Southampton, UK S0 18 2HJ
Tel: 44 (0)23 80 671155
Fax: 44 (0)23 80 671166
Web:
Document. No. 132816 Revision C
www.cobham.com\seatel

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sea Tel ST24

Summary of Contents for Sea Tel ST24

  • Page 1 Southampton, UK S0 18 2HJ Fax: (925) 798-7986 Tel: 44 (0)23 80 671155 Web: : www.cobham.com\seatel Fax: 44 (0)23 80 671166 Web: www.cobham.com\seatel Sea Tel Inc is also doing business as Cobham Antenna Systems September 26, 2011 Document. No. 132816 Revision C...
  • Page 2 All Rights Reserved. The information contained in this document is proprietary to Sea Tel, Inc.. This document may not be reproduced or distributed in any form without prior consent of Sea Tel, Inc. The information in this document is subject to change without notice. Copyright © 2010 Sea Tel, Inc is doing business as Cobham SATCOM.

  • Page 3: Table Of Contents

    3.3.1. Determine your Cables ................................3-6 3.4. BDE C : ....................................3-7 ABLES 3.5. BDE C ........................................3-7 ABLES 3.5.1. ST24 US/DLA/AUSSAT: ................................3-7 3.5.2. ST24 DiSEqC: ....................................3-7 3.5.3. ST24 Euro:...................................... 3-7 3.6................................3-8 NTENNA ADOME NSTALLATION 3.7.
  • Page 4 Table of Contents ST24 Ku-Band TVRO 6.3..............................6-4 AULT SOLATION ROUBLE SHOOTING 6.4. LNB ....................................... 6-5 EPLACING AN 6.5........................... 6-7 ANUAL OL TO ONVERSION ROCEDURE 7. ST SERIES TECHNICAL SPECIFICATIONS ..........................7-1 7.1......................................7-1 NSTALLED EIGHT 7.2.

  • Page 5: Quick Start

    Quick Start Quick Start Operation of the ST24 Series antenna is accomplished via the Graphic Antenna Control Panel (GACP). Once properly configured, the antenna will automatically search for and identify the last targeted satellite held in memory. Because of programming requirements or changing of geographic locations, you may be required to change what satellite you wish to track..
  • Page 6 Quick Start ST24 Ku-Band TVRO THIS PAGE INTENIONALLY LEFT BLANK...

  • Page 7: Installation

    Installation Installation of the ST24 Antenna system will be presented into two major sections, the Above Decks Equipment (ADE) and the Below Decks Equipment (BDE). This installation must be performed by or under the direct supervision of an authorized Sea Tel Dealer for the limited warranty policy to be valid and enforced.
  • Page 8 Installation ST24 Ku-Band TVRO Figure 2 ST24 US/DLA/AUSSAT Simplified Block Diagram...

  • Page 9: Verify System Components

    Before beginning it is critical that you inventory all system components. Refer to the appropriate packing list for your Model antenna. Any discrepancies should be immediately reported to the Sea Tel service department so that a Service Call may be filed and the required parts be shipped out.

  • Page 10: Prepare The Antenna Radome Mounting Location

    Align the radome “bow” mark on the template to be parallel to the bow of the boat. By default the orientation of the “Sea Tel” logo is oriented towards BOW. You may as you see fit, adjust the position of the “Bow” marker on template to orient the LOGO where you want it. When you are...

  • Page 11: Prepare The Antenna Control Panel Mounting Location

    132766-1 ST24 US, AutoPol 132766-2 ST24 DLA, AutoPol 132766-3 ST24 DiSEqC, AutoPol 132766-4 ST24 Aussat, AutoPol 132766-5 ST24, Euro, Manual Pol 132766-6 ST24 US, Manual Pol 132766-7 ST24 DLA, Manual Pol 132766-8 ST24 DiSEqC, Manual Pol 132766-9 ST24 Aussat, AutoPol...

  • Page 12: Determine Your Cables

    Installation ST24 Ku-Band TVRO 3.3.1. Determine your Cables In addition to the required Coaxial cable that will interconnect the above decks equipment with the below decks equipment, you will need to determine what cables are going to be used to interconnect satellite receivers to the televisions and if installed the surround sound system.

  • Page 13: Ade To Bde Cables

    6 inches (10cm) of cable extending out of the antenna control panel mounting surface. ST24 Euro Systems require 4 ADE to BDE Coax cables in addition to the Antenna M&C Coax. (Horizontal High Band IF is stacked onto the Antenna M&C Coax) ST24 US/DLA Systems require 2 ADE to BDE Coax Cables in addition to the Antenna M&C Coax.

  • Page 14: Antenna/Radome Installation

    Installation ST24 Ku-Band TVRO 3.5.3.2. DC Power Cable (All Models) 3.5.3.2.1. Supply to GACP Route the DC Power cable assembly from the Vessel Power Source to the GACP mounting location. 3.5.3.2.2. Supply to Optional Power Switch Perform the following step only if installing the optional power switch.
  • Page 15 ST24 Ku-Band TVRO Installation From below the mounting surface, apply Loctite thread locker to the four M8 mounting studs. Install the fender washers and the M8 nut and Torque to 15 N-m. NOTE: Graphic to the right is shown with the radome mounting pad (normally installed flush with mounting adapter) removed for clarity.

  • Page 16: Graphic Antenna Control Panel

    Installation ST24 Ku-Band TVRO Locate and disengage the Azimuth Stowage lock. Refer to the Maintenance section of this manual for complete procedures to stow and un-stow your antenna. Perform range of motion check on antenna. Verify free range in Azimuth, Elevation and Polarization drive.
  • Page 17 ST24 Ku-Band TVRO Installation Carefully install the GACP into the mounting location while placing the excess cables into the void of the mounting location and secure using 4 self tapping screws. Reinstall the GACP front lid to the enclosure. 3-11...
  • Page 18 Installation ST24 Ku-Band TVRO THIS PAGE INTENIONALLY LEFT BLANK 3-12...

  • Page 19: Setup

    Setup As a part of initial commissioning of the ST24 you will be required to configure and optimize the system to the clients specific needs. An easy to use Setup Wizard will aid in this configuration process. Use the below procedures and flowcharts as a guide to accomplish these tasks.
  • Page 20 Setup ST24 Ku-Band TVRO Select the Antenna’s Polarization type, choose Auto if your feed assembly is fitted with a drive motor otherwise choose Manual. Select the satellite switching mode. Choose "Active" to enable DiSEqC based satellite switching or choose Inactive for manual satellite switching mode. NOTE: DiSEqC switches and compatible EchoStar based...
  • Page 21 ST24 Ku-Band TVRO Setup (Skip to the next step if you have selected “Inactive” in the previous screen) Select the amount of satellites required as specified by your service provider. Press the Right Arrow to begin the Satellite Preset selection process. The chosen presets will be displayed on the Satellite Target, Edit, and View menus.
  • Page 22 Setup ST24 Ku-Band TVRO Using the same procedure in step 7, select and save your desired satellite for presets 2-6. If no additional satellite presets are required set to Unused. 10. Select a text line to enter/edit the installing dealer contact information.
  • Page 23 ST24 Ku-Band TVRO Setup 13. Select the Screen Blank Timeout parameter to define in whole minutes when the panel will go into Blank Mode. 14. Select the Screen Brightness Control to adjust the screen brightness. 15. Select the Time Zone Selection parameter to define the vessels current GMT time zone offset.
  • Page 24 Setup ST24 Ku-Band TVRO 16. After all the Panel Settings Parameters have been defined press the Right Arrow. 17. Press the Right Arrow to confirm the completion of the Setup Wizard and save to memory.

  • Page 25: Operation

    Used to perform software updates to the ST24 GACP RS232 Antenna M&C Port RS232 Serial M&C Port, used to perform software updates to the ST24 PCU, or as a communication port w/ a DiSEqC Switch Optional NMEA Interface Port Future Use...

  • Page 26: Gacp Home Page

    Operation ST24 Ku-Band TVRO 5.2. GACP Home Page Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Tracking, Identifying or Unwrapping. Time Stamp Current time stamp, based on the antenna’s on–board GPS. System Signal Strength in AGC counts with visual signal bar.

  • Page 27: Satellites Page

    ST24 Ku-Band TVRO Operation 5.3. Satellites Page Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Tracking, Identifying or Unwrapping. Time Stamp Current time stamp, based on the antennas on –board GPS. System Signal Strength in AGC counts with visual signal bar.

  • Page 28: Satellite Target

    Operation ST24 Ku-Band TVRO 5.3.1. Satellite Target Page 1 Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Identifying, Tracking, or Unwrapping. Time Stamp Current time stamp, based on the antenna’s on –board GPS.

  • Page 29: Satellite Target

    ST24 Ku-Band TVRO Operation 5.3.2. Satellite Target Page 2 Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Identifying, Tracking, or Unwrapping. Time Stamp Current time stamp, based on the antenna’s on –board GPS.

  • Page 30: Satellite Edit

    Operation ST24 Ku-Band TVRO 5.3.3. Satellite Edit Page 1 Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Identifying, Tracking, or Unwrapping. Time Stamp Current time stam, based on the antenna’s on –board GPS.

  • Page 31: Satellite Edit

    ST24 Ku-Band TVRO Operation 5.3.4. Satellite Edit Page 2 Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Tracking, or Unwrapping. Time Stamp Current time stamp in UTC, based on the antenna’s on –board GPS.

  • Page 32: 5.3.1. Satellite Preset Edit Page

    Operation ST24 Ku-Band TVRO 5.3.1. Satellite Preset Edit Page Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Tracking, or Unwrapping. Time Stamp Current time stamp in UTC, based on the antenna’s on –board GPS.

  • Page 33: Satellite View

    ST24 Ku-Band TVRO Operation 5.3.2. Satellite View Page 1 Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Identifying, Tracking, or Unwrapping. Time Stamp Current time stamp, based on the antenna’s on –board GPS.

  • Page 34: Satellite View

    Operation ST24 Ku-Band TVRO 5.3.3. Satellite View Page 2 Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Identifying, Tracking, or Unwrapping. Time Stamp Current time stamp, based on the antennas on –board GPS.

  • Page 35: Current Settings

    ST24 Ku-Band TVRO Operation 5.4. Current Settings Page 1 Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Identifying, Tracking, or Unwrapping. Time Stamp Current time stamp, based on the antenna’s on –board GPS.
  • Page 36 Operation ST24 Ku-Band TVRO 5.4.1. Current Settings Page 2 Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Identifying, Tracking, or Unwrapping. Time Stamp Current time stamp, based on the antennas on –board GPS.

  • Page 37: Antenna Page

    ST24 Ku-Band TVRO Operation 5.5. Antenna Page Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Identifying, Tracking, or Unwrapping. Time Stamp Current time stamp, based on the antenna’s on –board GPS. System Signal Strength in AGC counts with visual signal bar.

  • Page 38: Antenna Advanced Options

    Operation ST24 Ku-Band TVRO 5.5.1. Antenna Advanced Options Page 1 Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Identifying, Tracking, or Unwrapping. Time Stamp Current time stamp, based on the antennas on –board GPS.

  • Page 39: Antenna Advanced Options

    ST24 Ku-Band TVRO Operation 5.5.2. Antenna Advanced Options Page 2 Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Identifying, Tracking, or Unwrapping. Time Stamp Current time stamp, based on the antennas on –board GPS.
  • Page 40 Operation ST24 Ku-Band TVRO 5.5.2.1. Manual Control Page Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Identifying, Tracking, or Unwrapping. Click to drive feed assembly (Polang) CW or CCW. Time Stamp Current time stamp, based on the antennas on –board GPS.
  • Page 41 ST24 Ku-Band TVRO Operation 5.5.2.2. System Test Page Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Identifying, Tracking, or Unwrapping. Time Stamp Current time stamp, based on the antennas on –board GPS. System Signal Strength in AGC counts with visual signal bar.

  • Page 42: Position

    Operation ST24 Ku-Band TVRO 5.6. Position Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Tracking, or Unwrapping. Time Stamp Current time stamp in UTC, based on the antenna’s on –board GPS. System Signal Strength in AGC counts with visual signal bar.

  • Page 43: System Information Page

    ST24 Ku-Band TVRO Operation 5.7. System Information Page Description Function System Status Rolling text indicating the systems current status of: Initializing, Searching, Targeting, Identifying, Tracking, or Unwrapping. Time Stamp Current time stamp, based on the antennas on –board GPS. System Signal Strength in AGC counts with visual signal bar.
  • Page 44 Operation ST24 Ku-Band TVRO THIS PAGE INTENIONALLY LEFT BLANK 5-20...

  • Page 45: Maintenance

    6.1. Warranty Information Sea Tel Inc. supports its ST24 Series systems with a warranty program unsurpassed in the industry. These systems are backed by a TWO YEAR full warranty on parts and a ONE YEAR warranty on labor. What’s Covered by the Limited Warranty? The Sea Tel ST24 Series Limited Warranty is applicable for parts and labor coverage to the complete antenna system, including all above-decks equipment (radome, pedestal, antenna, motors, electronics, wiring, etc.) and the antenna...

  • Page 46: Touch Screen Calibration

    Install a straight 9 wire serial cable from the GACP’s M&C port to an available com port on a computer/laptop with Sea Tel Program Terminal (ProgTerm) Installed. If not already, apply power to the GACP. Open up ProgTerm and select Coastal PCU to Panel Translation mode.
  • Page 47 ST24 Ku-Band TVRO Maintenance Press the circle located in the bottom right corner of screen. Press on an area of the screen near circled number one and then continue to drag your finger towards the middle of the circle. Repeat for process for circles 2 -4.

  • Page 48: Fault Isolation/Trouble-Shooting

    Maintenance ST24 Ku-Band TVRO 6.3. Fault Isolation/Trouble-shooting The following table is provided to help isolate problems in the ST24 Series Antenna systems. Symptom Possible Fault GACP icons are non responsive Touch screen requires calibration. Refer to the “Touch Screen Calibration” procedure in the maintenance section of this manual.

  • Page 49: Replacing An Lnb

    Replacing an LNB Follow the procedure below to install and align a replacement Ku-Band circular receive LNB. Unless otherwise noted, apply adhesive to all hardware per Sea Tel Specification Document 121730 Turn the DC supply power Off to the GACP.
  • Page 50 Maintenance ST24 Ku-Band TVRO Using an Allen Wrench, loosen the three set screws used to secure the LNB to mounting cuff. Remove LNB and place aside. Install replacement LNB into mounting collar as close to the orientation prior to removal and then tighten down the set screws loosened earlier.

  • Page 51: Manual Pol To Autopol Conversion Procedure

    Manual Pol to AutoPol Conversion Procedure Follow the procedure below to retrofit an existing ST24 with a Ku-Band Manual Polarization Feed assembly to an Auto Polarization feed assembly. Please read through this entire procedure and verify the contents of conversion kit part number 133235 prior to performing retrofit.
  • Page 52 Maintenance ST24 Ku-Band TVRO Using a 2.5mm Allen head wrench, remove the hardware securing feed tube to reflector/feed assembly. Carefully remove Feed tube and set aside for future use. Using a 4mm Allen Head Wrench, remove the hardware securing the feed assembly to the reflector.
  • Page 53 ST24 Ku-Band TVRO Maintenance Carefully install Auto Polarization assembly into rear of reflector as shown to the right. Apply Loctite thread locker to the hardware provided in kit, and using an 8mm driver secure feed assembly to reflector.
  • Page 54 Maintenance ST24 Ku-Band TVRO Install feed tube with the alignment notch in the vertical axis as shown to the right. Secure using a 2.5mm Allen Wrench. DO NOT OVERTIGHTEN Front view of the reflector showing a secured feed tube. CAUTION: DO NOT ATTEMPT TO ROTATE...
  • Page 55 ST24 Ku-Band TVRO Maintenance Using snips carefully cut the tie wrap that secures the (previously unused) IF coaxes to the GPS Antenna Cable service loop. Route the four coaxes up to and secure to LNB. Using a tie wrap secure coaxes and Motor/Encoder Harness to the LNB.
  • Page 56 Maintenance ST24 Ku-Band TVRO Using caution as to not pinch, kink or otherwise damage the IF coaxes and/or interface harnesses, re- install and secure the PCU PCB cover. Remove the counter balance weight(s) located in the bottom side of right EL Pan.

  • Page 57: St Series Technical Specifications

    4 x M8 fasteners equally spaced on 12.73” D.B.C. (9” pattern) 4 x M8 fasteners equally spaced on 16.97” D.B.C. (12” pattern) Wind: Withstand relative average winds up to 125MPH from any direction. Ingress Protection Rating All Sea Tel radomes have an IP rating of 56 7.3. Antenna ST24 Type...

  • Page 58: 7.4.2. Dla Circular Lnb

    ST Series Technical Specifications ST24 Ku-Band TVRO 7.4.2. DLA Circular LNB Sea Tel Part Number: 115075-2 Type: Dual output RF Frequencies: 11.45 - 12.2 GHz IF Frequency: 950 - 1700 MHz LO Frequency: 10.5 GHz Polarization modes: LHCP or RHCP circular...

  • Page 59: Stabilized Pedestal

    ST24 Ku-Band TVRO ST Series Technical Specifications 7.6. Stabilized Pedestal Type Two-axis positioning (Elevation & Azimuth) and Polarization Stabilization 3 Dimensional Velocity mode Servo Stab Accuracy 1.5 degrees MAX, 0.7 degrees RMS in presence of specified ship motions for pointing accuracy (see below).

  • Page 60: 7.6.1. Dvb Compliant Tracking Receiver

    ST Series Technical Specifications ST24 Ku-Band TVRO 7.6.1. DVB Compliant Tracking Receiver Internal Satellite Identification Receiver Tuning range 950 to 2150 MHz in 1 MHz increments in DVB Mode. Input RF Level -85 to -25 dBm typical Output RF Level...

  • Page 61: Power Requirements

    ST24 Ku-Band TVRO ST Series Technical Specifications 7.8. Power Requirements Voltage 10-30 VDC normal operating range Current 3.0 Amps nominal @ 13.8 VDC Transient Protection Load Dump 60 Volts Inductive coupling +/- 200V @1µSecond Reverse Battery Indefinite 24V Jump Start Indefinite 7.9.
  • Page 62 ST Series Technical Specifications ST24 Ku-Band TVRO THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 63: Drawings

    The following drawings have been provided as a reference tool. Should you have any questions or concerns please notify the Sea Tel Service Department. Drawing Title 132500 System, ST24, 132370 General Assembly, ST24, 132766 System Block Diagram, ST24, 132765 Antenna System Schematic, ST24 8-12 132903 Installation Template, 29 inch radome 8-13 132230-1 Installation Template, GACP...
  • Page 64 Drawings ST24 Ku-Band TVRO THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 65 REFERENCE DESIGNATOR 1 EA 132370-1 GENERAL ASS'Y, ST24, AUTO POL PL C1 AntSys_Crate 1 EA 132542-1 RADOME ASS'Y, GA INSTALL, 29 IN, ST24 PL C1 AntSys_Crate 1 EA 132463-1 LNBF, QUAD, KU, INVERTO, MODIFIED PL C1 I1 SN w/132370-1,1 AntSys_Crate...
  • Page 66 REFERENCE DESIGNATOR 1 EA 132370-1 GENERAL ASS'Y, ST24, AUTO POL PL C1 AntSys_Crate 1 EA 132542-1 RADOME ASS'Y, GA INSTALL, 29 IN, ST24 PL C1 AntSys_Crate 1 EA 127444-1 LNBF MOD, DUAL DBS, CAL AMP PL C1 I1 SN w/132370-1,1...
  • Page 67 REFERENCE DESIGNATOR 1 EA 132370-1 GENERAL ASS'Y, ST24, AUTO POL PL C1 AntSys_Crate 1 EA 132542-1 RADOME ASS'Y, GA INSTALL, 29 IN, ST24 PL C1 AntSys_Crate 1 EA 115075-2 G2 LNB MOD, DUAL DLA PL C1 I1 SN w/132370-1,1 AntSys_Crate...
  • Page 68 REFERENCE DESIGNATOR 1 EA 132370-1 GENERAL ASS'Y, ST24, AUTO POL PL C1 AntSys_Crate 1 EA 132542-1 RADOME ASS'Y, GA INSTALL, 29 IN, ST24 PL C1 AntSys_Crate 1 EA 130210 A1 LNB, DISHPRO, SINGLE, MODIFIED PL C1 I1 SN w/132370-1,1 AntSys_Crate...
  • Page 69 REFERENCE DESIGNATOR 1 EA 132370-1 GENERAL ASS'Y, ST24, AUTO POL PL C1 AntSys_Crate 1 EA 132542-1 RADOME ASS'Y, GA INSTALL, 29 IN, ST24 PL C1 AntSys_Crate 1 EA 131492-1 LNB, KU-BAND ACER LNBFTUP, MODIFIED PL C1 I1 SN w/132370-1,1 AntSys_Crate...
  • Page 70 REFERENCE DESIGNATOR 1 EA 132370-2 GENERAL ASS'Y, ST24, MANUAL POL PL C1 AntSys_Crate 1 EA 132542-1 RADOME ASS'Y, GA INSTALL, 29 IN, ST24 PL C1 AntSys_Crate 1 EA 132463-1 LNBF, QUAD, KU, INVERTO, MODIFIED PL C1 I1 SN w/132370-1,1 AntSys_Crate...
  • Page 71 REFERENCE DESIGNATOR 1 EA 132370-2 GENERAL ASS'Y, ST24, MANUAL POL PL C1 AntSys_Crate 1 EA 132542-1 RADOME ASS'Y, GA INSTALL, 29 IN, ST24 PL C1 AntSys_Crate 1 EA 127444-1 LNBF MOD, DUAL DBS, CAL AMP PL C1 I1 SN w/132370-1,1...
  • Page 72 REFERENCE DESIGNATOR 1 EA 132370-2 GENERAL ASS'Y, ST24, MANUAL POL PL C1 AntSys_Crate 1 EA 132542-1 RADOME ASS'Y, GA INSTALL, 29 IN, ST24 PL C1 AntSys_Crate 1 EA 115075-2 G2 LNB MOD, DUAL DLA PL C1 I1 SN w/132370-1,1 AntSys_Crate...
  • Page 73 REFERENCE DESIGNATOR 1 EA 132370-2 GENERAL ASS'Y, ST24, MANUAL POL PL C1 AntSys_Crate 1 EA 132542-1 RADOME ASS'Y, GA INSTALL, 29 IN, ST24 PL C1 AntSys_Crate 1 EA 130210 A1 LNB, DISHPRO, SINGLE, MODIFIED PL C1 I1 SN w/132370-1,1 AntSys_Crate...
  • Page 74 SIZE SCALE: DRAWING NUMBER SURFACE ROUGHNESS: 132765 ANTENNA SYSTEM ASS'Y, ST24 authorization of Cobham PLC. This restriction 132500 is applicable regardless of the source from which 132766 SYSTEM BLOCK DIAGRAM, ST24 the document is obtained. Any violation of this policy...
  • Page 75 EXTRA LOW POWER SMART GPS SENSOR, 1 EA 132675-36YEL CABLE ASS'Y, RG-179, COAX, F(RA) TO F (NOT SHOWN) 1 EA 132635 HARNESS ASSEMBLY, RX INTERFACE, ST24 (NOT SHOWN) 2 IN 124077-5 TAPE, 3M VHB #4991, SYNTHETIC ADHESIV 8 EA 122782 CABLE TIE, HOLDER, .281 DIA PUSH MOUN...
  • Page 76 5 EA 120089-251 NUT, HEX, M6, S.S. 5 EA 126264-13 A1 WASHER, STAR, INTERNAL TOOTH, NARROW 5 EA 119967 A1 NUT, HEX, PANEL, 3/8-32 GENERAL ASS'Y, ST24, AUTO POL PROD FAMILY EFF. DATE DRAWING SHT 2 OF SERIES 98 10/6/2011...
  • Page 77 EXTRA LOW POWER SMART GPS SENSOR, 1 EA 132675-36YEL CABLE ASS'Y, RG-179, COAX, F(RA) TO F (NOT SHOWN) 1 EA 132635 HARNESS ASSEMBLY, RX INTERFACE, ST24 (NOT SHOWN) 2 IN 124077-5 TAPE, 3M VHB #4991, SYNTHETIC ADHESIV 10 EA 122782 CABLE TIE, HOLDER, .281 DIA PUSH MOUN...
  • Page 78 5 EA 120089-251 NUT, HEX, M6, S.S. 5 EA 126264-13 A1 WASHER, STAR, INTERNAL TOOTH, NARROW 5 EA 119967 A1 NUT, HEX, PANEL, 3/8-32 GENERAL ASS'Y, ST24, MANUAL POL PROD FAMILY EFF. DATE DRAWING SHT 2 OF SERIES 98 10/6/2011...
  • Page 79 Sea Tel - Strictly Confidential & Proprietary. Do Not Copy, Distribute or Disclose Without Prior 132370 Written Approval From Sea Tel. 3rd ANGLE ST24 1 OF 2 Copyright c Sea Tel, Inc 2011 - Unpublished Work FIRST USED: SHEET NUMBER PROJECTION...
  • Page 80 70 78 78 79 SIZE SCALE: DRAWING NUMBER 132370 2 OF 2 SHEET NUMBER...
  • Page 81 (REF ONLY, USE DASH #) MULTISWITCH, D (ACCESSORY OPTION / CFE) 1 EA 130922-1 A1 ENCLOSURE ASS'Y, GACP 1 EA 132877 HARNESS ASS'Y, DC POWER GACP SYSTEM BLOCK DIAGRAM, ST24, EURO, AUTO POL PROD FAMILY EFF. DATE DRAWING SHT 1 OF 10/6/2011...
  • Page 82 A2 MULTI-SWITCH, 4/8/12 OUTPUT, (REF. US (ACCESSORY OPTION / CFE) 1 EA 130922-1 A1 ENCLOSURE ASS'Y, GACP 1 EA 132877 HARNESS ASS'Y, DC POWER GACP SYSTEM BLOCK DIAGRAM, ST24, US, AUTO POL PROD FAMILY EFF. DATE DRAWING SHT 1 OF 10/6/2011 NUMBER...
  • Page 83 A2 MULTI-SWITCH, 4/8/12 OUTPUT, (REF. US (ACCESSORY OPTION / CFE) 1 EA 130922-1 A1 ENCLOSURE ASS'Y, GACP 1 EA 132877 HARNESS ASS'Y, DC POWER GACP SYSTEM BLOCK DIAGRAM, ST24, DLA, AUTO POL PROD FAMILY EFF. DATE DRAWING SHT 1 OF 10/6/2011 NUMBER...
  • Page 84 1 EA 120643-25 CABLE ASS'Y, RS232, 9-WIRE, STRAIGHT, 1 EA 129734 ENCLOSURE ASSY, DISEQC VOLTAGE SWITCH 1 EA 132877 HARNESS ASS'Y, DC POWER GACP SYSTEM BLOCK DIAGRAM, ST24, DISEQC, AUTO POL PROD FAMILY EFF. DATE DRAWING SHT 1 OF 10/6/2011 NUMBER...
  • Page 85 (REF ONLY, USE DASH #) MULTISWITCH, D (ACCESSORY OPTION / CFE) 1 EA 130922-1 A1 ENCLOSURE ASS'Y, GACP 1 EA 132877 HARNESS ASS'Y, DC POWER GACP SYSTEM BLOCK DIAGRAM, ST24, AUSSAT, AUTO POL PROD FAMILY EFF. DATE DRAWING SHT 1 OF 10/6/2011...
  • Page 86 (REF ONLY, USE DASH #) MULTISWITCH, D (ACCESSORY OPTION / CFE) 1 EA 130922-1 A1 ENCLOSURE ASS'Y, GACP 1 EA 132877 HARNESS ASS'Y, DC POWER GACP SYSTEM BLOCK DIAGRAM, ST24, EURO, MAN POL PROD FAMILY EFF. DATE DRAWING SHT 1 OF 10/6/2011...
  • Page 87 A2 MULTI-SWITCH, 4/8/12 OUTPUT, (REF. US (ACCESSORY OPTION / CFE) 1 EA 130922-1 A1 ENCLOSURE ASS'Y, GACP 1 EA 132877 HARNESS ASS'Y, DC POWER GACP SYSTEM BLOCK DIAGRAM, ST24, US, MAN POL PROD FAMILY EFF. DATE DRAWING SHT 1 OF 10/6/2011 NUMBER...
  • Page 88 A2 MULTI-SWITCH, 4/8/12 OUTPUT, (REF. US (ACCESSORY OPTION / CFE) 1 EA 130922-1 A1 ENCLOSURE ASS'Y, GACP 1 EA 132877 HARNESS ASS'Y, DC POWER GACP SYSTEM BLOCK DIAGRAM, ST24, DLA, MAN POL PROD FAMILY EFF. DATE DRAWING SHT 1 OF 10/6/2011 NUMBER...
  • Page 89 1 EA 120643-25 CABLE ASS'Y, RS232, 9-WIRE, STRAIGHT, 1 EA 129734 ENCLOSURE ASSY, DISEQC VOLTAGE SWITCH 1 EA 132877 HARNESS ASS'Y, DC POWER GACP SYSTEM BLOCK DIAGRAM, ST24, DISEQC, MAN POL PROD FAMILY EFF. DATE DRAWING SHT 1 OF 10/6/2011 NUMBER...
  • Page 99 REVISION HISTORY REV ECO# DATE DESCRIPTION 8152 11/16/10 RELEASED TO PRODUCTION. WAS REVISION X1. 0.76 139.37 4.80 4X R.03 MAX 5.49 .189 87.05 100.00 3.43 3.937 140.00 NOTES: UNLESS OTHERWISE SPECIFIED MINIMUM 6" CLEARANCE DEPTH 5.512 REQUIRED FOR GACP ENCLOSURE AND CABLES.
  • Page 100 Sea Tel - Strictly Confidential & Proprietary. Do Not Copy, Distribute or Disclose Without Prior 133491 BOTTOM VIEW Written Approval From Sea Tel. ST24 3rd ANGLE 1 OF 2 Copyright c Sea Tel, Inc 2011 - Unpublished Work FIRST USED: SHEET NUMBER PROJECTION...
  • Page 101 12 INCH MOUNTING PATTERN 4X M8 SET SCREW CUSTOMER MOUNTING SURFACE FENDER WASHER 12.0 304.8 M8 HEX NUT 12.0 304.8 SIZE SCALE: DRAWING NUMBER 133491 BOTTOM VIEW 2 OF 2 SHEET NUMBER...
