INSTALLATION AND OPERATION MANUAL
FOR SEA TEL MODEL
14400MK2-21 DUAL C/QUAD KU-BAND TVRO ANTENNA
Sea Tel Europe
Unit 1, Orion Industrial Centre
Wide Lane, Swaythling
Southampton, UK S0 18 2HJ
Tel: 44 (0)23 80 671155
Fax: 44 (0)23 80 671166
Web:
www.cobham.com\seatel
Document. No. 135635 Revision A
