5. ROUTER DESIGN
Figure 17: Ethernet connector
ATTENTION! Port ETH is not POE (Power Over Ethernet) compatible!
Ethernet cable plug into the RJ45 connector labeled as ETH (see figure below).
Figure 18: Connection of ethernet cable
Example of the ETH router connection:
Figure 19: Example of router connection
17
