5.4 Ordering codes

Order codes are given for the Polish operator Orange. Another operator can be selected
by changing two digits according to Table 3 Version of firmware module on page 6.
Expansion port
Version without expansion port
Version with Ethernet exp. port
Version with RS232 exp. port
Version with RS485 exp. port
Version with MBUS exp. port
Version with CNT exp. port
Version with SWITCH exp. port
Version with WIFI exp. port
Version with WMBUS exp. port
Version with SDH exp. port
Second expansion port is written after first expansion port in the ordering code.
Example:
Full version with Ethernet and RS232 port: UCR11 v2F-01 ETH RS232 set.
Full version with Ethernet and RS232 port in metal cover:
UCR11 v2F-01 ETH RS232 SL set.
Router is standardly fitted with a diversity antenna for HSPA+. However, UCR11 v2 can be
fitted with a diversity antenna for CDMA on customer's request. In this case, it is necessary to
write capital letter D behind two digits indicating the operator in ordering code.
Example:
UCR11 v2F-01D ETH RS485 set.
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Possible participation
PORT1
PORT1 a PORT2
PORT1 a PORT2
PORT1 a PORT2
PORT1
PORT1 + PORT2
PORT2
PORT2
PORT2
Table 4: Ordering codes
7
5. ROUTER DESIGN
Ordering code
UCR11 v2F-01 set
UCR11 v2F-01 ETH set
UCR11 v2F-01 RS232 set
UCR11 v2F-01 RS458 set
UCR11 v2F-01 MBUS set
UCR11 v2F-01 CNT set
UCR11 v2F-01 SWITCH set
UCR11 v2F-01 WIFI set
UCR11 v2F-01 WMBUS set
UCR11 v2F-01 SDH set
