7. Technical parameters

7.1 Technical parameters of router

UCR11 v2
Complies with standards
Temperature range
Protection
Supply voltage
Consumption
Dimensions
Weight
Antenna connector
User interface

7.2 Technical parameters of UMTS module

UMTS modul
HSPA+ parameters
UMTS parameters
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
EN 301 511, v9.0.2,
EN 301 908-1 & -2: v3.2.1,
ETSI EN 301 489-1 V1.8.1,
EN 60950-1:06 ed.2 + A11:09 + A1:10
Function -30 C to +60 C
Storage -40 C to +85 C
Freely IP20
In switch board IP56
10 to 30 V DC
Reception 2,6 W
CDMA to 4 W
UMTS to 5,5 W
42 x 87 x 113 mm (DIN 35 mm)
280 g
SMA – 50 Ohm
ETH Ethernet (10/100 Mbit/s)
USB USB 2.0
PORT1 On customer's request
PORT2 On customer's request
Table 12: Technical parameters of router
Bit rate 21,1 Mbps (DL) / 5,76 Mbps (UL)
3GPP rel. 7 standard
UE CAT. 1 to 6, 8, 10, 12, 14
3GPP data compress
PS bit rate 384 kbps (DL) / 384 kbps (UL)
CS bit rate 64 kbps (DL) / 64 kbps (UL)
W-CDMA FDD standard
25
