- Page 1 TOTOLINK Wireless Router (A2004NS) User’s Guide HKBN_SETUP_ROUTER_TOTOLINK_160415...
-
Page 2: Table Of Contents
1 Get to know TOTOLINK (A2004NS) Wireless Router ............2 Tech Specs - Connections and Expansion ..............2 System Requirements (bb500/ FibreHome500/ bb1000/ FibreHome1000) ....3 2 Connecting to TOTOLINK Router ..................4 3 Switching your broadband Internet service to HKBN ............16 4 Factory default reset of TOTOLINK Router ............... -
Page 3: Get To Know Totolink (A2004Ns) Wireless Router
Get to know TOTOLINK (A2004NS) Wireless Router 路由器 Get to know TOTOLINK (A2004NS) Wireless Router A. Tech Specs - Connections and Expansion USB LED LAN LED WAN LED 5G LED 2.4G LED CPU LED Power LED WPS Button Power Reset... -
Page 4: System Requirements (Bb500/ Fibrehome500/ Bb1000/ Fibrehome1000)
Get to know TOTOLINK (A2004NS) Wireless Router 路由器 Get to know TOTOLINK (A2004NS) Wireless Router B. System Requirements (bb500/ FibreHome500/ bb1000/ FibreHome1000) To ensure that you have a stable and speedy network, please refer to the following as a recommended minimum system requirement: Central Processing Unit (CPU) Intel Core2 Duo P8700/2.5 (3 GHz or above) -
Page 5: Connecting To Totolink Router
Make sure you have a LAN cable connected from the HKBN wall plate/ONT to the WAN port of your TOTOLINK (A2004NS) wireless router. Using a second LAN cable, connect it from the router LAN port to the computer LAN port. Once finished, switch on the power supply for the router and turn on the computer. - Page 6 Connecting to TOTOLINK Router Connecting to TOTOLINK Router Choose [Manual Internet configuration] then click [Next]. Choose [DHCP method] then click [Next]. HKBN_SETUP_ROUTER_TOTOLINK_160415...
- Page 7 Connecting to TOTOLINK Router Connecting to TOTOLINK Router Choose [No MAC clone] and tick the box of [Allow a private internt IP address], click [Next]. Click [Save and Close]. HKBN_SETUP_ROUTER_TOTOLINK_160415...
- Page 8 Connecting to TOTOLINK Router Connecting to TOTOLINK Router Choose [Wireless Wizard] at main menu. Click [Next]. HKBN_SETUP_ROUTER_TOTOLINK_160415...
- Page 9 Connecting to TOTOLINK Router Suggest to select [Others] as the country, then click [Next]. TOTOLINK (A2004NS) supports both 2.4GHz and 5GHz wireless connections. Create a Wireless Network Name [SSID] for 2.4GHz network, click [Check SSID] to confirm the SSID is available, then click [Next].
- Page 10 Internal Wi-Fi Network setup of TOTOLINK Router Internal Wi-Fi Network setup of TOTOLINK Router Click [Search best channel], when the search result show up, pick one of the [Best channel] or [Available] channel, click [Next]. Confirming all settings are correct, click [Next]. HKBN_SETUP_ROUTER_TOTOLINK_160415...
- Page 11 Connecting to TOTOLINK Router Connecting to TOTOLINK Router Under wireless security setup, choose [WPAPSK/WPA2PSK] then click [Next]. Choose [AES] then click [Next]. HKBN_SETUP_ROUTER_TOTOLINK_160415...
- Page 12 Connecting to TOTOLINK Router Connecting to TOTOLINK Router Create a wireless password under [Network Key] and re-enter the password under [Confirm the Network key], click [Next]. Confirm all settings are correct, click [Apply and Set 5GHz Wireless Network]. HKBN_SETUP_ROUTER_TOTOLINK_160415...
- Page 13 Connecting to TOTOLINK Router Connecting to TOTOLINK Router Suggest to select [Others] as the country, then click [Next]. Create a Wireless Network Name [SSID] for 5GHz network, click [Check SSID] to confirm the SSID is available, then click [Next]. HKBN_SETUP_ROUTER_TOTOLINK_160415...
- Page 14 Connecting to TOTOLINK Router Connecting to TOTOLINK Router Click [Search best channel], when the search result show up, pick one of the [Best channel] or [Available] channel, click [Next]. Confirm all settings are correct, click [Next]. HKBN_SETUP_ROUTER_TOTOLINK_160415...
- Page 15 Connecting to TOTOLINK Router Connecting to TOTOLINK Router Under wireless security setup, choose [WPAPSK/WPA2PSK] then click [Next]. Choose [AES] then click [Next]. HKBN_SETUP_ROUTER_TOTOLINK_160415...
- Page 16 Connecting to TOTOLINK Router Connecting to TOTOLINK Router Create a wireless password under [Network Key] and re-enter the password under [Confirm the Network key], click [Next]. Confirm all settings are correct, click [Finish]. HKBN_SETUP_ROUTER_TOTOLINK_160415...
-
Page 17: Switching Your Broadband Internet Service To Hkbn
Switch your broadband Internet service to HKBN Switching your broadband Internet service to HKBN After logging into the router through your browser, click [Setup Tool]. Enter [admin] as the default username and password, click [OK]. HKBN_SETUP_ROUTER_TOTOLINK_160415... - Page 18 Switch broadband service from other ISP to HKBN Switch broadband service from other ISP to HKBN Choose [Internet Setup] under [Basic Setup]. HKBN_SETUP_ROUTER_TOTOLINK_160415...
- Page 19 Switch broadband service from other ISP to HKBN Switch broadband service from other ISP to HKBN Choose [DHCP User], tick the box of [Allow private IP] and [Restart DHCP client if the physical WAN link is reconnected.], then click [Apply]. Click [OK] to save the changes.
- Page 20 Switch broadband service from other ISP to HKBN Switch broadband service from other ISP to HKBN Click [Internet Status] under [Network] tab of [Advanced Setup]. Confirm the [Connection Type] has changed to [DHCP User (Dynamic IP)], click [Save] at right top corner. Click [OK] to save all configurations.
-
Page 21: Factory Default Reset Of Totolink Router
Factory default reset of TOTOLINK Router Factory default reset of TOTOLINK Router If the device is not accessible from the router setting page, you can reset to the factory default setting by pressing the reset button: 1. Confirm your TOTOLINK router is switched on. 2.
