- Page 1 SL11B & S1500 CONSTRUCTION HEATERS October 14, 2003 SERVICE AND MAINTENANCE MANUAL No. 934-6644 PLEASE RETAIN FOR FUTURE REFERENCE PRODUCTS A DIVISION OF HAUL-ALL EQUIPMENT LTD. LETHBRIDGE, ALBERTA...
- Page 2 SL11B & S1500 Manual 934-6644 - Page 2...
- Page 3 WARNING Not for home or recreational vehicle use SL11B & S1500 Manual 934-6644 - Page 3...
- Page 4 Your local authority can advise you about these. FOR YOUR SAFETY DO NOT USE THIS HEATER IN A SPACE WHERE GASOLINE OR OTHER LIQUIDS HAVING FLAMMABLE VAPOURS ARE STORED OR USED. SL11B & S1500 Manual 934-6644 - Page 4...
-
Page 5: Table Of Contents
S1500 Connection Wiring Diagram ............20 S1500 Ladder Wiring Diagram ............. 21 Lpg - Propane Fuel Vaporization Rate ..........22 Maximum Btu Content (Propane) ............22 Pressure & Flow Equivalents ..............22 SL11B & S1500 Manual 934-6644 - Page 5... -
Page 6: Specifications
(Minimum inlet pressure is for purpose of input adjustment) Gas Supply: S1500 Inlet Pressure Manifold Pressure Max.W.C. Min.W.C. Max.W.C. Min.W.C Propane 14 inch 8 inch 2.7 inch 0.75 inch Natural 14 inch 8 inch 7.2 inch 2.0 inch SL11B & S1500 Manual 934-6644 - Page 6... -
Page 7: Installation
INSTALLATION The Sure Flame Models SL11B & S1500 are direct fired gas heaters intended to be used primarily for the temporary heating of buildings under construction, alteration, or repair. Since all the products of combustion are released into the area being heated, it is imperative that adequate ventila- tion be provided. -
Page 8: Installation Using Apropane Supply Tank
1/2 psi inlet pressure. The installation of this heater to a natural gas supply must conform with all applicable local codes or, in the absence of local codes, with the CAN/CGA-B149.1 Natural Gas Installation Code. SL11B & S1500 Manual 934-6644 - Page 8... -
Page 9: Operating Instructions
General criteria for the use of construction heaters may be found in the applicable sections of the National Standard of Canada Propane Installa- tion Code CAN/CGA-B149.2. THE INSTALLATION AND MAINTENANCE OF THE HEATER MUST BE ACCOMPLISHED BY A QUALIFIED SERVICE PERSON. SL11B & S1500 Manual 934-6644 - Page 9... -
Page 10: Sequence Of Operation
Usually a result of supply pressure being too high because of improper or lack of regulation. 5 DIRTY GAS SUPPLY Dirty gas can cause strainers to plug or form a build-up in the burner orifice. SL11B & S1500 Manual 934-6644 - Page 10... -
Page 11: Safety Features
SAFETY FEATURES Servicing of Sure Flame Construction Heaters normally involves one of several built-in safety features. The Models SL11B & S1500 incorporate devices to detect the following: 1 LOSS OF FLAME Gas supply is shut off if flame is lost to prevent raw gas from leaving the heater. -
Page 12: Design Related Additional Safety Features
Sure Flame Heaters are designed to have a low skin temperature. This provides added safety in the workplace. 3 DURABLE CONSTRUCTION The Models SL11B & S1500 use a stainless steel burner for long life and consistent performance. In order to maintain the highly efficient combustion of the Sure Flame Heater, the combustion chamber must remain as manufactured. -
Page 13: Preventive Maintenance
Also check that all electrical connections are snug and tight. D MOTOR The electric motor on the SL11B & S1500 Heaters is fitted with sealed bearings and no oiling is required. Keep the motor clean by blowing or wiping off dust or dirt in order to prevent it from over heating. - Page 14 First check if either the upstream or down stream airtubes are plugged. b) If both are free then check alignment ( tubes must be positioned parallel to the direction of airflow ). SL11B & S1500 Manual 934-6644 - Page 14...
- Page 15 If there is no power at the high flame side of the 2 stage regulator then the thermostat is faulty. c) If there is power at the high flame side of the 2 stage regulator then the valve is faulty. SL11B & S1500 Manual 934-6644 - Page 15...
-
Page 16: Sl11B/S1500 Heater Parts
SL11B/S1500 HEATER PARTS SL11B & S1500 Manual 934-6644 - Page 16... - Page 17 2506 Red Light 5988 10-Second Delay On Break Timer 2446 HI Limit Thermoswitch 6440 Relay Clip 4512 Control Relay with clip 5355 Air Switch (0.5" W.C.) 2526 1-1/2" Appliance Regulator (SL11B only) SL11B & S1500 Manual 934-6644 - Page 17...
-
Page 18: Sl11B Connection Wiring Diagram
SL11B CONNECTION WIRING DIAGRAM SL11B & S1500 Manual 934-6644 - Page 18... -
Page 19: Sl11B Ladder Wiring Diagram
SL11B LADDER WIRING DIAGRAM STOP BUTTON RELAY 1 POWER LIGHT TIMER RELAY 2 POWER RELAY AIR SWITCH HI LIMIT SWITCH SOLENOID VALVE SOLENOID VALVE ERROR LIGHT FENWALL #35-70XXX-XXX VALVE TRAIN PILOT LIGHT SL11B & S1500 Manual 934-6644 - Page 19... -
Page 20: S1500 Connection Wiring Diagram
S1500 CONNECTION WIRING DIAGRAM SL11B & S1500 Manual 934-6644 - Page 20... -
Page 21: S1500 Ladder Wiring Diagram
START BUTTON STOP BUTTON RELAY 1 POWER LIGHT TIMER RELAY 2 THERMOSTAT POWER RELAY AIR SWITCH HI LIMIT SWITCH SOLENOID VALVE TWO STAGE REGULATOR ERROR LIGHT FENWALL #35-70XXX-XXX VALVE TRAIN PILOT LIGHT SL11B & S1500 Manual 934-6644 - Page 21... -
Page 22: Lpg - Propane Fuel Vaporization Rate
1 lb./sq. in. (psig) = 27.71" W.C. = 0.0689 bar 1" Mercury = 0.49 psig = 33.86 millibar 1 Std. Cubic Ft./Hr. = 2,500 BTU/Hr. = 0.02832 cu. m/hr. 1 BTU/Hr. = 0.2931 Watts SL11B & S1500 Manual 934-6644 - Page 22... - Page 23 SL11B & S1500 Manual 934-6644 - Page 23...
